EVOC PPC-1561 User Manual

15″ industrial panel pc with atom d525 platform
Table of Contents

Advertisement

Quick Links

特种计算机
Industrial Computer
产品说明书
User Manual
PPC-1561
凌动 D525 平台 15"工业平板电脑
15" Industrial Panel PC with Atom D525
Platform
Version: C05

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPC-1561 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EVOC PPC-1561

  • Page 1 特种计算机 Industrial Computer 产品说明书 User Manual PPC-1561 凌动 D525 平台 15″工业平板电脑 15″ Industrial Panel PC with Atom D525 Platform Version: C05...
  • Page 2 法律资讯 警告提示 为了您的人身安全以及避免财产损失,必须注意本手册中的提示。人身安全 的提示用一个警告三角表示,仅与财产损失有关的提示不带警告三角。警告提示 根据危险等级由高到低如下表示。 危险 表示如果不采取相应的小心措施,将会导致死亡或者严重的人身伤害。 警告 表示如果不采取相应的小心措施,可能导致死亡或者严重的人身伤害。 小心 带有警告三角,表示如果不采取相应的小心措施,可能导致轻微的人身伤害。 注意 表示如果不注意相应的提示,可能会出现不希望的结果或状态。 合格的专业人员 本文件所属的产品/系统只允许由符合各项工作要求的合格人员进行操作。 其操作必须遵照各自附带的文件说明,特别是其中的安全及警告提示。 由于具 备相关培训及经验,合格人员可以察觉本产品/系统的风险,并避免可能的危险。 EVOC产品 请注意下列说明: 警告 EVOC产品只允许用于目录和相关技术文件中规定的使用情况。如果要使用其他 公司的产品和组件,必须得到EVOC推荐和允许。正确的运输、储存、组装、装 配、安装、调试、操作和维护是产品安全、正常运行的前提。必须保证允许的环 境条件。必须注意相关文件中的提示。...
  • Page 3 免责声明 本公司保留对此手册更改的权利,产品后续相关变更时,恕不另行通知。 对于任何因安装、使用不当而导致的直接、间接、有意或无意的损坏及隐患概不 负责。 订购产品前,请向经销商详细了解产品性能是否符合您的需求。 EVOC 是研祥智能科技股份有限公司的注册商标。本手册所涉及到的其他商 标,其所有权为相应的产品厂家所拥有。 研祥智能科技股份有限公司©2012,版权所有,违者必究。未经许可,不得 以机械、电子或其它任何方式进行复制。 保修条款: 产品保修期一年。用户如另有要求,以双方签署的合同为准。 欲获更多信息请访问: 研祥网站:http://www.evoc.com 研祥技术支持邮箱:support@evoc.com(国际) 、support@evoc.cn(国内) 免费客服热线: 4008809666...
  • Page 4 文档说明 本文档适用范围 本文档适用于EVOC PPC-1561型号。 约定 在本文档中,术语“整机”或“产品”有时特指EVOC PPC-1561产品。 说明 安全相关注意事项 为避免财产损失以及出于个人安全方面的原因, 请注意本入门指南中关于安 全方面的信息。 文中使用警告三角来指示这些安全信息,警告三角的出现 取决于潜在危险的程度。...
  • Page 5: Table Of Contents

    目 录 1.产品介绍 ........................1 1.1 产品概述 .......................1 1.2 产品规格 .......................1 2.应用规划 ........................4 2.1 运输.......................4 2.2 贮存.......................4 2.3 开箱及检查交付的设备 ................4 3.产品安装说明 ......................5 3.1 安装方式 .......................5 3.1.1 VESA标准支撑臂安装 ................5 3.1.2 嵌入式面板安装 ..................6 3.2 产品外形尺寸图 ..................7 3.3 安装尺寸图 ....................8 3.3.1 产品安装尺寸图 ..................8 3.3.2 推荐开孔尺寸图 ..................9 4.设备连接...
  • Page 6 6.1 整体装配图 ....................18 6.2 主板拆装 .....................19 6.2.1 主板安装 ....................19 6.2.2 主板拆卸 ....................20 6.3 驱动器拆装 ....................21 6.4 风扇拆装与维护 ..................22 6.4.1 风扇安装 ....................22 6.4.2 风扇拆卸 ....................22 6.5 特殊功能安装说明 ..................23 6.5.1 CF卡安装 ....................23 6.5.2 扩展卡安装 .....................23 7.EVOC一键还原操作说明..................24 7.1 EVOC一键还原操作说明 ................24 8.附录 .........................28 8.1 常见故障分析与解决 .................28...
  • Page 7: 产品介绍

    了 Intel® Atom™ D525 1.8GHz 的处理器,板载 2G DDR3 内存,6 个串口(其中 4 个支持 RS-232/RS-422/RS-485) 、5 个 USB2.0(其中内置 1 个,加密狗使用,机 箱引出 4 个) ,同时配置两个千兆网口,1 个 1×8 凤凰端子(8 路 GPIO) ,1 个 VGA 接口,1 个标准的 PCI 扩展插槽,可满足部分现场用户对外部业务卡的扩展 功能。产品采用 9~30VDC 宽压供电方式。另外,在软件方面,本产品支持系统 一键还原功能、MBR 杀毒功能和 EVOC BPI 功能。 该产品具有低功耗、双千兆网口、多串口、带扩展的功能,接口丰富,非 常适合太阳能、工厂信息化、现场测控设备等领域对 HMI 应用需求。 1.2 产品规格 项目...
  • Page 8 主 外形尺寸 外形尺寸:400mm(长)× 300 mm(宽)×86.1 mm(高) 要 性 重量 约 7.35 Kg 能  工作温度: 0℃~50℃ 温度 指  存储温度: -20℃~60℃ 标 湿度 5%~95%(非凝结状态)  无线电骚扰限值符合 GB9254-2008 标准 A 级 电磁兼容性  抗扰度符合 GB/T 17618-1998 标准的限值 - 2 - PPC-1561...
  • Page 9  抗振动: 5-19Hz/1.0mm 振幅; 19-200Hz/1.0g 加速度;  抗冲击:10g 加速度,11ms 周期; 应性  系统一键还原功能(详见本说明书中第 7 章)  软件功能 MBR 杀毒功能(详见本说明书中第 7 章)  EVOC BPI 功能(详见光盘上主板说明书)  输入电压/频率:220VAC/50Hz(有适配器) ;输入电 压/电流:9~30VDC(无适配器,整机直接输入) 电源特性  整机功耗:20.4W(待机状态) ;整机功耗:40.3W(运 行 MAXPOWER 100%)。 PPC-1561 - 3 -...
  • Page 10: 应用规划

    雨、雪或液体物质的淋湿与机械损坏。 2.2 贮存 产品贮存时应存放在原包装箱内,存放产品的仓库环境温度为 0℃~40℃, 相对湿度为 20%~85%。仓库内不允许有各种有害气体、易燃、易爆炸的产品及 有腐蚀性的化学物品,并且无强烈的机械振动、冲击和强磁场作用。包装箱应垫 离地面至少 10cm,距离墙壁、热源、冷源、窗口或空气入口至少 50cm。 小心 损坏设备的风险! 在寒冷天气状况下运输 PC 时,应注意温度的极端变化。 这种情况下,请确保 设备上或设备内部没有形成水滴(凝露)。如果设备上形成了凝露,请在接通设 备前至少等待12个小时。 2.3 开箱及检查交付的设备 设备开箱 设备开箱时请注意以下几点: ● 建议您不要丢弃原包装材料。 请保留原包装材料以备再次运输设备时使用。 ● 请将文档存放在安全的地方。 初始调试设备时需用到该文档,并且它是设备 的一部分。 ● 检查交付的设备,查看是否在运输途中造成了任何明显的损坏。 ● 验证所运货物是否包含完整的设备以及您单独订购的附件。 如有任何不符或 存在运输损坏,请联系客户服务人员。 - 4 - PPC-1561...
  • Page 11: 产品安装说明

    产品安装说明 3.产品安装说明 3.1 安装方式 □19″上架式 □桌面式(台面式) ■嵌入面板式 □壁挂式 ■VESA 标准支撑臂 □手提便携式 □其他方式___________ 3.1.1 VESA标准支撑臂安装 步骤:如左图所示,用螺钉 把机器固定在支撑臂上 注意事项:安装时须用随机 器配备螺钉或按说明书要 求选用螺钉 警告 VESA支臂的承重能力,要至少是整机重量的2倍以上。 PPC-1561 - 5 -...
  • Page 12: 嵌入式面板安装

    产品安装说明 3.1.2 嵌入式面板安装 步骤 1:如左图所示,把机 器放入安装面板的开孔内; 步骤 2:如左图所示,把附 件中的挂钩挂入机器挂孔 内,用 M4 的螺钉锁入挂钩 的螺孔内直至抵紧安装面 板; 警告 安装面板的承重能力,要至少是整机重量的2倍以上。 - 6 - PPC-1561...
  • Page 13: 产品外形尺寸图

    产品安装说明 3.2 产品外形尺寸图 备注:此机型分带 PCI 扩展与不带 PCI 扩展,其外形区别仅在于侧面板和扩 展盖有无通风孔,带扩展时有,不带扩展时无。 单位:mm PPC-1561 - 7 -...
  • Page 14: 安装尺寸图

    产品安装说明 3.3 安装尺寸图 3.3.1 产品安装尺寸图 单位:mm - 8 - PPC-1561...
  • Page 15: 推荐开孔尺寸图

    产品安装说明 3.3.2 推荐开孔尺寸图 单位:mm PPC-1561 - 9 -...
  • Page 16: 设备连接

    警告 所连接或内置的外围设备不得接入极性相反的设备。 警告 本设备只能在接地电源网络上运行。禁止在未接地或阻抗接地的电源网络上进 行操作。 警告 使用的设备额定电压必须符合本产品电源特性。 注意 只能连接经认可适合工业应用的外围设备。 PC 运行时, 可以连接热插拔 I/O 模 块(USB)。无热插拔功能的 I/O 设备只能在设备断开电源后进行连接。 4.2 产品接地 接地端子 接 地 线 接 于 整 机 接 地 螺 针 上。 最小导线横截面不能小 于5mm ,接地电阻最大不能 大于0.1Ω。 - 10 - PPC-1561...
  • Page 17: 将设备连接到电源

    设备连接 4.3 将设备连接到电源 将设备连接到电源的步骤 将电源线连接到插口1 危险 雷暴雨期间断开电源和数据电缆。 注意 必须断开电源连接器才能将设备与电源完全隔离。 PPC-1561 - 11 -...
  • Page 18: 使用说明

    使用说明 5.使用说明 5.1 产品外观图 备注:此机型分带 PCI 扩展与不带 PCI 扩展,其外形区别仅在于侧面板和扩 展盖有无通风孔,带扩展时有,不带扩展时无。 5.2 外部控制接口图 P OW E R S W DC 9-30 IN 下侧面接口图 - 12 - PPC-1561...
  • Page 19: 产品接口定义

    载板提供 1 个 3P 卧式凤凰端子插座,支持单电源输入,电压输入范围:9~ 30 VDC,管脚定义如下: 管脚 信号名称 PWR1 5.3.2 VGA接口: 载板提供 1 个标准 DB15VGA 接口,管脚定义如下: 管脚 信号名称 管脚 信号名称 Green Blue VGA1 DDCDATA HSYNC VSYNC DDCCLK 载板用到 VGA 插座型号为研达,DB15P 孔型 母 高架插座 蓝 30.81x31.6。 PPC-1561 - 13 -...
  • Page 20: Ps/2 键盘鼠标接口

    接口,其中 LILED 和 ACTLED 是以太网接口两边的 LED,它们显示着 LAN 的网络 速度指示状态和网络活动指示状态。请参考以下每一个 LED 的状态描述。 J7(LAN1) ,J8(LAN2) LILED 网络速度 ACTLED 网络活动 (双色:橙绿双色) 指示状态 (单色:绿色灯) 指示状态 绿色 1000Mbps 闪烁 有数据传输 橙色 100Mbps 灭 无数据传输 灭 10Mbps 注:千兆网卡不管有/无 Link 信号,左边的 ACTLED 灯表示的是有无数据传输, 有数据传输时,左边的绿色灯应为“闪烁”状态;只连接网络未收发数据时,绿 - 14 - PPC-1561...
  • Page 21: Usb接口

    5.3.5 USB接口 管脚 信号名称 USB_Data- J7(USB1,USB2) USB_Data+ J8(USB3,USB4) USB5 5.3.6 标准DB9 串口 载板提供 6 个 COM 口,接口为双层叠层组合插座,J9(COM1,COM2),J10 (COM3,COM4)支持 RS-232/RS-422/RS-485 模式,管脚定义如下: 信号名称 管脚 RS-232 RS-422 RS-485 (Default) DCD# DATA- DATA+ DTR# J9,J10(COM1~COM4) DSR# RTS# CTS# J11(COM5,COM6)支持 RS-232 模式,管脚定义如下: PPC-1561 - 15 -...
  • Page 22: Gpio接口

    DSR# RTS# CTS# 载板用到 COM 组合插座型号为纳特康,DB9M 针式 D 型 双层 带六角螺柱。 5.3.7 GPIO接口 管脚 信号名称 管脚 信号名称 GPIO1 GPIO2 GPIO3 GPIO4 GPIO1 GPIO5 GPIO6 (脚距:3.81mm) GPIO7 GPIO8 注:出厂 Default 值为连接器的第 1、2、3、4 脚默认为输入,第 5、6、7、8 脚 默认为输出,出厂默认状态为高电平,输入输出信号的电压范围为 0-5V。 - 16 - PPC-1561...
  • Page 23: 操作控件

    使用说明 5.4 操作控件 警告 开/关按钮信号不会切断 PC 电源! 小心 PC 执行硬件复位时可能会丢失数据。 控件按钮 项目 描述 用于开关设备的开 ① /关按钮。 复位按钮 例如,使用尖物或 回形针可操作复位 ② 按钮。 按钮信号将 触发硬件复位。 PC 执行重启动(冷启 动) PPC-1561 - 17 -...
  • Page 24: 拆装与维护

    拆装与维护 6.拆装与维护 6.1 整体装配图 备注:此机型分带 PCI 扩展与不带 PCI 扩展,其外形区别仅在于侧面板和扩展盖 有无通风孔,带扩展时有,不带扩展时无。 1、铝合金面板 2、触摸屏或钢化玻璃 3、显示屏 4、屏支架 5、扩展支架 6、硬盘组件 7、箱体组件 8、PCI 转接板(带扩展时) 9、扩展盖 10、箱盖 11、风扇(带扩展时) 12、散热块 1 13、散热块 2 14、主板 15、底板 16、 触摸控制板(带触摸屏时使用) 17、升压板 - 18 - PPC-1561...
  • Page 25: 主板拆装

    拆装与维护 6.2 主板拆装 6.2.1 主板安装 主板 底板 螺钉 1. 如上图所示把底板和主板按对应槽位插好,用螺钉固定; PPC-1561 - 19 -...
  • Page 26: 主板拆卸

    3. 插好屏与箱体连接的线材,并把箱体组件与屏组件组合,用螺钉固定; 4. 把 PCI 转接板插入对应槽位,用螺钉固定; (不带 PCI 扩展忽略此步骤) 5. 盖上扩展盖,用螺钉固定。 6.2.2 主板拆卸 1. 如上图所示,取下固定扩展盖的螺钉,取下扩展盖(不带 PCI 扩展忽略 此步骤) ; 2. 取下固定 PCI 转接板的螺钉,把 PCI 转接板从对应槽位中拔出(不带 PCI 扩展忽略此步骤) ; 3. 取下固定扩展盖的螺钉, 把箱体组件与屏组件分开, 拔下相连接的线材; 4. 取下固定主板组件的螺钉,把主板组件从箱体组件内取下; 主板 底板 螺钉 - 20 - PPC-1561...
  • Page 27: 驱动器拆装

    拆装与维护 6.3 驱动器拆装 硬盘安装: 1.先将硬盘按相应位置放入硬盘支架内,用螺钉固定; 2.然后按图示将其锁付固定安装于正确位置,插上对应线材; 3.盖上扩展盖,用螺钉固定。 硬盘拆卸: 1. 如上图所示,取下扩展盖螺钉,取下扩展盖; 2.然后拔下硬盘连接线,取掉固定硬盘组件的螺钉,取出硬盘组件; 3.取下固定硬盘的螺钉,取出硬盘。 PPC-1561 - 21 -...
  • Page 28: 风扇拆装与维护

    拆装与维护 6.4 风扇拆装与维护 6.4.1 风扇安装 把风扇按对应位置放入箱体,用螺钉从外向内锁入;把风扇端子插在底板 对应连接器上。 备注:不带扩展时无风扇。 注意 由于风扇的转速较快,所以在风扇停止转动之前,禁止用手触摸风扇。 6.4.2 风扇拆卸 把风扇端子从底板对应连接器上拔下,取下固定风扇的螺钉,把风扇按图 示方向取出。 备注:不带扩展时无风扇。 注意 由于风扇的转速较快,所以在风扇停止转动之前,禁止用手触摸风扇。 - 22 - PPC-1561...
  • Page 29: 特殊功能安装说明

    拆装与维护 6.5 特殊功能安装说明 6.5.1 CF卡安装 拆下 CF 卡盖上的螺钉,取下 CF 卡盖,按对应位置把 CF 卡插入,盖上 CF 卡盖,锁上螺钉。 6.5.2 扩展卡安装 拆下扩展盖上的螺钉,取下扩展盖,按对应位置把扩展卡插入,盖上扩展 盖,锁上螺钉。 PPC-1561 - 23 -...
  • Page 30: Evoc一键还原操作说明

    在 PPC-1561 中, 当同时存在 CF 存储卡和硬盘时, CF 存储卡默认作为整机 的主盘,最后一个硬盘则是整机的从盘;当仅有两个硬盘时,第一个硬盘 默认作为整机的主盘,最后一个硬盘则是整机的从盘。 在 PPC-1561 中,每个存储设备需要有两个分区,确保备份还原操作成功。 备份盘分区的文件系统与还原盘的文件系统可以不相同,但两者均不能使 用 FAT32/NTFS/EXT2/EXT3/EXT4 以外的文件系统。 第一次还原时,必须确保有备份好的镜像文件(即此前须按上述规则备份 数据) ,否则,还原动作无效。 二、操作步骤: 1. 开启或关闭研祥一键还原功能。 在开机画面起来后,按“Del”键进入 BIOS Setup 配置界面。 (1) 在 BIOS Setup 配置界面中找到 BOOT 项,配置 EVOC Backup 选项开启 - 24 - PPC-1561...
  • Page 31 EVOC 一键还原操作说明 [Enable]或关闭[Disabled],来启用或关闭 EVOC 一键还原功能。 (2) 对于涉及到操作 SATA 硬盘的,需设置 SATA 硬盘的工作模式。进入 Advanced->IDE Configuratioin->ATA/IDE Cconfiguration 设 置 为 Enhanced 模式。该设置主要是提高 EVOC 一键还原功能的备份及还原的 硬盘操作速度。当备份或还原后,请恢复此项设置。 (3) 按“F10”保存并重启。 2. 进入系统备份还原界面。 当开启 EVOC 一键还原功能后,在主板开机时将在显示器上提示“Please Press button<RCV> for System Recovery within 3 Seconds!!”处,此时在 3 秒内按下整机背面的按键<RCV>,将进入系统还原备份界面。 3. 进行系统备份...
  • Page 32 EVOC 一键还原操作说明 待。 2) 备份时间在 2~10 分钟不等,取决于系统盘的大小。 3) 若系统提示“Save system success!”说明备份成功,并在 5 秒后系统将自动 重启。 4) 重启后可以设置 BIOS 中的 Boot 项,关闭 EVOC 一键还原功能。 若在 10 秒内输入 restore 并按回车键,则进行系统还原操作。输入 restore 并按回车键,则出现如下信息: restore (注:此处为命令输入行,以下的信息为命令输入回车确认后显示) RestoreNTFS 10% completely Syncing… 当数据还原操作完毕后,将出现如下信息,并在 5 秒后自动重启: Restore system success! After 5 seconds to reboot! 注意:...
  • Page 33 EVOC 一键还原操作说明 a)Disabled:关闭清除 MBR 病毒功能; b) Manual:检测到硬件系统存在 MBR 病毒时候会在 Post 阶段提示用户是 否清除 MBR 病毒,选择“Y”清除病毒,选择“N”不清除病毒; c) Quiet:检测到硬件系统存在病毒的时候自动清除病毒,没有任何提示 信息。 本产品的驱动程序安装及主板详细信息请参考整机配套光盘,在此不做介绍。 PPC-1561 - 27 -...
  • Page 34: 常见故障分析与解决

    通过亮度控件提高亮度。 有关 亮度控件被设置为黑暗状 详细信息, 可参考显示器操作说 态 明。 外接显示器不亮 1、检查电源线是否正确地连接 到显示器和系统单元或接地 出口。 未连接电源线或显示器电 2、检查显示器电缆是否正确地 缆 连接到系统单元和显示器。 3、如果执行这些检查后显示器 屏幕仍不亮,请与技术支持 联系。 根据开机画面提示的按键, 打开 PC 上的时间或日 BIOS 设置不正确 BIOS Setup,在 BIOS Setup 中 期不正确。 调整时间和日期。 BIOS 设置正确, 备用电池电量不足 更换电池 时间和日期不对。 - 28 - PPC-1561...
  • Page 35 开 机 提 示 找 不 到 系统盘 用可引导的光盘进入系统 (常用 winpe 系统) ,检查硬盘系统是 硬盘系统文件损坏 否已损坏, 有必要时最好重新安 装系统。 即插即用 I/O 卡 一般是由于 PCI 或 ISA 卡频繁的 设备,再次使用时 拔插、固定不稳、 防尘措施不好 插槽接触不良 检 测 不 到 或 不 能 等造成插槽接触不良所致, 可反 正常使用。 复拔插几次或者换个槽插。 PPC-1561 - 29 -...
  • Page 36 Please pay attention to the following instructions: Warning EVOC product can only be used according to the descriptions within the manual, including the contents and the relevant technical documents. If the products or components from other companies are required, please get the recommendation and grant from EVOC first.
  • Page 37 Trademarks EVOC is a registered trademark of EVOC Intelligent Technology Co., Ltd. Other product names mentioned herein are used for identification purposes only and may be trademark and/or registered trademarks of their respective companies.
  • Page 38 About this manual Scope of the Manual The manual is appropriate for EVOC PPC-1561. Convention The term “the PC” or “the Product” within the manual usually stands for EVOC PPC-1561. Instructions Safety instructions To avoid property losses or individual injury, please pay attention to the safety instructions within the manual.
  • Page 39 C o n t e n t s 1. Product Introduction ....................1 1.1 Overview .......................1 1.2 Product Specifications ...................1 2. Application Scheme ....................5 2.1 Transportation....................5 2.2 Storage......................5 2.3 Opening the Box and Initial Examination............6 3. Installation ........................7 3.1 Mounting Method..................7 3.1.1 VESA Standard Supporting Arm Mounting..........7 3.1.2 Embedded Panel Installation ..............8 3.2 Outer Appearance and Dimensions..............9...
  • Page 40 6.4.2 Removing the Fan..................24 6.5 Installation of Special Functions..............25 6.5.1 CF Card Installation..................25 6.5.2 Installing the Expansion Card..............26 7. EVOC One-Button-Recovery Operating Instructions..........27 7.1 EVOC One-Button-Recovery Operating Instructions........27 Instructions for Anti-virus Function ..............30 8. Appendix.........................31 8.1 Troubleshooting and Solutions ..............31...
  • Page 41: Product Introduction

    Product Introduction 1. Product Introduction 1.1 Overview PPC-1561 is an industrial panel PC with 15″ high luminance touch screen. The product contains Intel® Atom™ D525 1.8GHz processor on-board; supports 2G DDR3 memory, six COM ports (four support RS-232/RS-422/RS-485), five USB2.0...
  • Page 42 LCD: 15″ TFT LCD  Resolution: 1024 x 768  Luminance: 350cd/m2 LCD Features  Contrast ratio: 400:1  Viewing angle (CR≥10)  Horizontal: -70~70°; Vertical: -65~60°  Connector type: USB type Touch Screen  Type:5-wire resistive PPC-1561 - 2 -...
  • Page 43 GB9254-2008, Class A;  Limits of immunity are compliant with the threshold of GB/T 17618-1998.  MTBF≥50000h Reliability  MTTR≤0.5h  Safety Meets basic requirements of GB4943. Protection  Screen surface complies with IP65 grade. Grade PPC-1561 - 3 -...
  • Page 44 Chapter 7 of the manual for detailed information) Software  MBR anti-virus function (please refer to Chapter 7 of the manual for detailed information) Function  EVOC BPI function (please refer to the manual enclosed in the CD)  Input voltage/frequency: 220VAC/50Hz (with adapter);...
  • Page 45: Application Scheme

    Under this circumstance, please make sure no water drop (condensation) is formed on the surface or interior of the device. If condensation is formed on the device, please wait for over twelve hours before connecting the device. PPC-1561 - 5 -...
  • Page 46: Opening The Box And Initial Examination

    ● Please check whether the delivery contains the intact device and all of the independently ordered accessories. Please contact the customer service when any unconformity or transportation damages occur. PPC-1561 - 6 -...
  • Page 47: Installation

    Note: During the installation, please use screws enclosed with the PC or select screws according to the instructions of the manual. Warning The weight bearing capacity of VESA arm shall be at least twice the weight of the PPC-1561 - 7 -...
  • Page 48: Embedded Panel Installation

    PC, then drive M4 screws into the hooks until the PC tightly presses against the panel. Warning The weight carrying capacity of the panel should be at least twice the weight of the PC. PPC-1561 - 8 -...
  • Page 49: Outer Appearance And Dimensions

    PCI expansion. The only appearance difference between the two is the ventilation holes on the side panel and expansion cover: the configuration with PCI expansion has the holes, while the other has no holes. Unit: mm PPC-1561 - 9 -...
  • Page 50: Installation Dimensions

    Installation 3.3 Installation Dimensions 3.3.1 Installation Dimensions Drawing Unit: mm PPC-1561 - 10 -...
  • Page 51: Dimensions Drawing For Hole Drilling

    Installation 3.3.2 Dimensions Drawing for Hole Drilling Unit: mm PPC-1561 - 11 -...
  • Page 52: Device Connection

    Ground Terminals The grounding cable shall be connected with the ground screw minimum cross section area of the cable shall be no less than 5mm , and the maximum ground resistance shall be no more than 0.1Ω. PPC-1561 - 12 -...
  • Page 53: Connecting The Device To Power

    Steps to connect the device to power: Connect power cable to the socket 1. Danger Disconnect the power source and data cable during a lightning storm. Attention The PC is completely isolated from the power supply only by disconnecting the power connector. PPC-1561 - 13 -...
  • Page 54: Operating Instructions

    PCI expansion has the holes, while the other has no holes. 5.2 External Control Ports P OW E R S W DC 9-30 IN Under side of the interface Figure PPC-1561 - 14 -...
  • Page 55: Product Port Definition

    The carrier board provides one 3P horizontal Phoenix terminal socket, supporting single power input, voltage input range: 9~30 VDC. Its pin definitions are as follows: Signal Name PWR1 5.3.2 VGA Port: The carrier board provides one standard DB15VGA port. Its pin definitions are as follows: PPC-1561 - 15 -...
  • Page 56: Ps/2 Keyboard/Mouse Port

    LILED and ACTLED are two LEDs on both sides of the Ethernet port, which respectively indicates network speed and network activity status. Please refer to the following for the status description of each LED: PPC-1561 - 16 -...
  • Page 57: Usb Port

    LED on the left is “flashing”; when it is connected to network with no data transmission, the green LED is “off”; when there are broadcasting packages, it is normal if the ACTLED is “flashing”. 5.3.5 USB Port Signal Name USB_Data- J7 (USB1, USB2) USB_Data+ J8 (USB3, USB4) USB5 PPC-1561 - 17 -...
  • Page 58: Standard Db9 Com Ports

    J11 (COM5, COM6) supports RS-232 mode. Its pin definitions are as follows: Signal Name DCD# DTR# J11 (COM5, COM6) DSR# RTS# CTS# The COM combo socket used by the carrier board is a Natconn product: DB9M pin-header D type, double-layer, with hex bolt. PPC-1561 - 18 -...
  • Page 59: Gpio Port

    PC. Reset button A pointed object or a clip can be used to press reset button, and ② the signal will trigger hardware reset. Then the PC will be rebooted (cold boot). PPC-1561 - 19 -...
  • Page 60: Assembly And Maintenance

    9. Expansion cover (with expansion) 10. Chassis cover 11. Fan (with expansion) 12. Heat sink 1 13. Heat sink 2 14. Motherboard 15. Carrier board 16. Touch control pad (used 17. Backlight board when there is touch screen) PPC-1561 - 20 -...
  • Page 61: Removal And Installation Of The Motherboard

    6.2.1 Installing the Motherboard Motherboard Carrier board Screw Insert the carrier board and motherboard into corresponding slots and fasten them with screws, as shown in the above picture; Place the motherboard assembly into the chassis by corresponding holes PPC-1561 - 21 -...
  • Page 62: Removing The Motherboard

    3. Loosen the screws fixing expansion cover, separate the LCD assembly from the chassis assembly, and pull out the cables connecting them; 4. Loosen the screws fixing motherboard assembly and remove the motherboard from the chassis assembly; Motherboard Carrier board Screw PPC-1561 - 22 -...
  • Page 63: Installation/Removal Of Hdd

    1. As shown in the above picture, loosen the screws fixing expansion cover and remove it; 2. Pull out the HDD cable, loosen the screws fixing HDD assembly and remove it; 3. Loosen the screws fixing HDD and remove it. PPC-1561 - 23 -...
  • Page 64: Installation, Removal And Maintenance Of The Fan

    Note: there is no fan if there is no expansion. Attention Do not touch the fan before it stops, because the fan speed is high. 6.4.2 Removing the Fan PPC-1561 - 24 -...
  • Page 65: Installation Of Special Functions

    Do not touch the fan before it stops, because the fan speed is high. 6.5 Installation of Special Functions 6.5.1 CF Card Installation Loosen the screws fixing CF card cover, remove it, insert the CF card, close the cover and tighten the screws. PPC-1561 - 25 -...
  • Page 66: Installing The Expansion Card

    Assembly and Maintenance 6.5.2 Installing the Expansion Card Loosen the screws fixing expansion cover, remove it, insert the expansion card, close the expansion cover and tighten the screws. PPC-1561 - 26 -...
  • Page 67: Evoc One-Button-Recovery Operating Instructions

    When both CF card and hard disk are installed in PPC-1561, the CF card is set as the primary disk of the PC in default and the last hard disk is set as the secondary disk of the PC.
  • Page 68 Press “DEL” key to enter the BIOS Setup interface after the power-on interface appears. Find the BOOT option in BIOS Setup interface, set the EVOC Backup option to [Enable] or [Disabled] the EVOC One-key Recovery Function. As for the implementation on SATA hard disk, please set the operating...
  • Page 69 3) If the system prompts “Save system success!”, it indicates that the system has been backed up successfully and the system will reboot after 5 seconds. 4) After rebooting, set the Boot option in BIOS to disable EVOC One-key Recovery Function.
  • Page 70: Instructions For Anti-Virus Function

    3) If the system prompts “Restore system success!”, it indicates that the system has been recovered successfully and the system will reboot after 5 seconds. 4) After rebooting, set the Boot option in BIOS to disable EVOC One-key Recovery Function.
  • Page 71: Appendix

    2. Please check whether the Power cable or display display cable correctly connected with the display and cable is not connected the system unit. 3. Contact Technique Support if the screen remains black after implementing above measures. PPC-1561 - 31 -...
  • Page 72 The HDD power cable or disk (the hard disk shall be can be found when data cable is not connected installed with operating system powering on well. bootable) well connected. PPC-1561 - 32 -...
  • Page 73 IO Poor contact of the slot. card, unstable fixing or improper card can be used dust-proof measures; please when used again. remove and install the card for a few times or use another slot. PPC-1561 - 33 -...
