特种计算机
Industrial Computer
产品说明书
User Manual
ERC-1004A
轨道交通 AFC 系统终端
AFC Terminal for Metro
Version: C07

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERC-1004A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EVOC ERC-1004A

  • Page 1 特种计算机 Industrial Computer 产品说明书 User Manual ERC-1004A 轨道交通 AFC 系统终端 AFC Terminal for Metro Version: C07...
  • Page 2 法律资讯 警告提示 为了您的人身安全以及避免财产损失,必须注意本手册中的提示。人身安全 的提示用一个警告三角表示,仅与财产损失有关的提示不带警告三角。警告提示 根据危险等级由高到低如下表示。 危险 表示如果不采取相应的小心措施,将会导致死亡或者严重的人身伤害。 警告 表示如果不采取相应的小心措施,可能导致死亡或者严重的人身伤害。 小心 带有警告三角,表示如果不采取相应的小心措施,可能导致轻微的人身伤害。 注意 表示如果不注意相应的提示,可能会出现不希望的结果或状态。 合格的专业人员 本文件所属的产品/系统只允许由符合各项工作要求的合格人员进行操作。 其操作必须遵照各自附带的文件说明,特别是其中的安全及警告提示。 由于具 备相关培训及经验,合格人员可以察觉本产品/系统的风险,并避免可能的危险。 EVOC产品 请注意下列说明: 警告 EVOC产品只允许用于目录和相关技术文件中规定的使用情况。如果要使用其 他公司的产品和组件,必须得到EVOC推荐和允许。正确的运输、储存、组装、 装配、安装、调试、操作和维护是产品安全、正常运行的前提。必须保证允许 的环境条件。必须注意相关文件中的提示。...
  • Page 3 免责声明 本公司保留对此手册更改的权利,产品后续相关变更时,恕不另行通知。 对于任何因安装、使用不当而导致的直接、间接、有意或无意的损坏及隐患概不 负责。 订购产品前,请向经销商详细了解产品性能是否符合您的需求。 EVOC 是研祥智能科技股份有限公司的注册商标。本手册所涉及到的其他商 标,其所有权为相应的产品厂家所拥有。 研祥智能科技股份有限公司©2016,版权所有,违者必究。未经许可,不得 以机械、电子或其它任何方式进行复制。 保修条款: 产品保修期两年。用户如另有要求,以双方签署的合同为准。 欲获更多信息请访问: 研祥网站:http://www.evoc.com 研祥技术支持邮箱:support@evoc.com(国际) 、support@evoc.cn(国内) 免费客服热线: 4008809666...
  • Page 4 文档说明 本文档适用范围 本文档适用于EVOC ERC-1004A型号。 约定 在本文档中,术语“整机”或“产品”有时特指EVOC ERC-1004A产品。 说明 安全相关注意事项 为避免财产损失以及出于个人安全方面的原因, 请注意本入门指南中关于安 全方面的信息。 文中使用警告三角来指示这些安全信息,警告三角的出现 取决于潜在危险的程度。...
  • Page 5: Table Of Contents

    目 录 1.产品介绍 ........................1 1.1 产品概述 .......................1 1.2 产品规格 .......................2 2.应用规划 ........................6 2.1 运输 .......................6 2.2 贮存 .......................6 2.3 开箱及检查交付的设备................6 2.4 安装方式 .......................7 3.设备连接 ........................8 3.1 连接前的注意事项..................8 3.2 产品接地 .......................8 3.3 将设备连接到电源..................9 4.使用说明 .........................10 4.1 产品外观图 ....................10 4.2 产品外形及安装尺寸图................14 4.3 外部结构图 ....................18 4.4 接口定义...
  • Page 6 4.4.8 GPIO接口 ..................36 4.4.9 鼠标键盘接口(采用标准二合一鼠标键盘接口).....41 4.4.10 串口....................42 4.4.11 SATA接口 ..................43 4.5 操作控件 .....................44 4.6 状态指示灯 ....................45 5.拆装与维护 ......................46 5.1 整体装配图 ....................46 5.2 开盖安装 .....................47 5.3 主板拆装 .....................47 5.3.1 主板安装..................47 5.3.2 主板拆卸..................48 5.4 驱动器拆装 ....................50 5.5 电源拆装 .....................50 5.5.1 电源安装..................50 5.5.2 电源拆卸..................51 5.6 壁挂条安装...
  • Page 7: 产品介绍

    产品介绍 1.产品介绍 1.1 产品概述 ERC-1004A是一款无风扇低功耗嵌入式整机,采用Intel® Atom™低功耗CPU, D425/525平台支持WinXP及Linux操作系统, E3845平台支持Win7、 Win7E、 LINUX(内 核2.6)、Fedora (内核3.5.10) 操作系统。 整机采用铝合金材质,外型小巧,结构简单,I/O和扩展接口丰富,具有良 好的防尘、散热、抗振性能。 ERC-1004A 为轨道交通 AFC 系统终端设备主控单元设计,主要用于地铁 AFC 系统自动检票机(AGM) 、自动售票机(TVM)和半自动售票机(BOM)终端设备主 控单元。整机符合 GB 9254-2008,GB/T 17626-2008 行业标准。 ERC-1004A - 1 -...
  • Page 8: 产品规格

    采用 HD 标准,支持 MIC-IN/LINE-OUT 可扩展 1 个不带键仔和 IO 连接器的 PCI 卡;支持高 扩展总线 64.4mm;长 167.6mm;兼容 PCI2.3 标准(可选) ICH8M 平台:支持 SATA DOM、IDE DOM、CF 卡、2.5 寸 SSD 或 HDD 存储支持 Baytrail-I SOC 平台:支持 SATA DOM、CF 卡、2.5 寸 SSD 或 HDD、SATA Slim - 2 - ERC-1004A...
  • Page 9 非光耦隔离 IO 或 36 路光耦隔离 IO, 使用 DB25 接口 可配置为 24 路非光耦隔离,不同配置接口不同,请 以整机实际配置为准)  2 个 CF 卡槽(CF 卡可选,不同配置 CF 卡槽数会有 所调整,请以整机实际配置为准)  1 个 IDE DOM 盘接口(IDE DOM 盘为可选接口,请以 整机实际配置为准)  1 个 LPT 接口  1 个 CFast 卡槽(CFast 卡为可选,请以整机实际配 置为准) ERC-1004A - 3 -...
  • Page 10 产品介绍 外形尺寸: 主 ERC-1004A-11配置: 170mm(宽)×105mm (高) ×235mm (深) 要 外形尺寸 ERC-1004A-31、32、33配置:200mm(宽)×97.3mm(高) 性 (不含挂耳) ×260mm(深) 能 其他配置:200mm(宽)×105mm(高)×260mm(深) 指 标 重量 4.3kg 温度 存储温度:-40℃~80℃ 湿度 5%~95%(非凝结状态)  辐射骚扰:GB 9254-2008 A 级  传导骚扰:GB 9254-2008 A 级  GB/T 17626.2.2006 静电放电(2)级  GB/T 17626.4-2006 脉冲群抗扰度(2)级...
  • Page 11  整机功耗:18 W(待机状态) ;整机功耗:22 W(运 行 Burnintest V6.0 100%)  该软件接口为上层应用软件提供一个统一的硬件封 装接口,进行二次开发。上层应用软件无需关注底 软 层设计。  件 提供看门狗编程接口 EVOC FMI  接 提供硬件监测接口(如 CPU 温度、主板工作电压等)  提供 GPIO 编程接口 口  提供一个可存储的 Flash 编程接口 (注:所提供 FMI 接口取决主板设计所提供的功能) ERC-1004A - 5 -...
  • Page 12: 应用规划

    2.2 贮存 产品贮存时应存放在原包装箱内,存放产品的仓库环境温度为 0℃~40℃, 相对湿度为 20%~85%。仓库内不允许有各种有害气体、易燃、易爆炸的产品及 有腐蚀性的化学物品,并且无强烈的机械振动、冲击和强磁场作用。包装箱应垫 离地面至少 10cm,距离墙壁、热源、冷源、窗口或空气入口至少 50cm。 小心 损坏设备的风险! 在寒冷天气状况下运输 PC 时,应注意温度的极端变化。 这种情况下,请确保 设备上或设备内部没有形成水滴(凝露)。如果设备上形成了凝露,请在接通设 备前至少等待 12个小时。 2.3 开箱及检查交付的设备 设备开箱 设备开箱时请注意以下几点: ● 建议您不要丢弃原包装材料。 请保留原包装材料以备再次运输设备时使用。 ● 请将文档存放在安全的地方。 初始调试设备时需用到该文档,并且它是设备 的一部分。 ● 检查交付的设备,查看是否在运输途中造成了任何明显的损坏。 ● 验证所运货物是否包含完整的设备以及您单独订购的附件。 如有任何不符或 存在运输损坏,请联系客户服务人员。 - 6 - ERC-1004A...
  • Page 13: 安装方式

    应用规划 2.4 安装方式 □19″上架式 ■桌面式(台面式) □嵌入面板式 ■壁挂式 □VESA 标准支撑臂 □手提便携式 □其他方式___________ ERC-1004A - 7 -...
  • Page 14: 设备连接

    行操作。 警告 使用的设备额定电压必须符合本产品电源特性。 注意 只能连接经认可适合工业应用的外围设备。PC 运行时,可以连接热插拔 I/O 模块(USB)。无热插拔功能的 I/O 设备只能在设备断开电源后进行连接。 3.2 产品接地 低阻抗接地连接更有助于将外部电缆、信号电缆或连接 I/O 模块的电缆所 生成的干扰释放到接地系统。 接地端子 设备上的接地端子 ①(大面 积接触)必须与安装有机柜 或 设 备 的 中 央 接 地 母 线 连 ERC-1004A-11/12/13配置 接。 最小导线横截面不能小 于5mm 其他配置 - 8 - ERC-1004A...
  • Page 15: 将设备连接到电源

    设备连接 3.3 将设备连接到电源 将设备连接到电源的步骤 电 源 线 插入 ①时确 保端 子 正负极正确,具体请参考电 源接口定义 ERC-1004A-11配置 将 电 源 线连 接到① 插口 并 将开关②带“点”的丝印端 按下,整机后面板上的绿色 电源 LED亮起,整机开机 其他配置 ERC-1004A - 9 -...
  • Page 16: 使用说明

    使用说明 4.使用说明 4.1 产品外观图 ERC-1004A-01、02、03、04 配置 ERC-1004A-06 配置 ERC-1004A-07 配置 - 10 - ERC-1004A...
  • Page 17 使用说明 ERC-1004A-11 配置 ERC-1004A-12 配置 ERC-1004A-13 配置 ERC-1004A - 11 -...
  • Page 18 使用说明 ERC-1004A-21 配置 ERC-1004A-22 配置 ERC-1004ALA070A、B、C 配置 - 12 - ERC-1004A...
  • Page 19 使用说明 ERC-1004A-31 配置 ERC-1004A-32 配置 ERC-1004A-33 配置 ERC-1004A - 13 -...
  • Page 20: 产品外形及安装尺寸图

    使用说明 4.2 产品外形及安装尺寸图 ERC-1004A-01、02、03、04 配置 单位:mm ERC-1004A-06、07 配置 单位:mm - 14 - ERC-1004A...
  • Page 21 使用说明 ERC-1004A-11 配置 47.5 9.75 R2.25 单位:mm ERC-1004A-12/13 配置 单位:mm ERC-1004A - 15 -...
  • Page 22 使用说明 ERC-1004A-21 配置 单位:mm ERC-1004A-22 配置 单位:mm - 16 - ERC-1004A...
  • Page 23 使用说明 ERC-1004ALA070A、B、C 配置 单位:mm ERC-1004A-31、33 配置 单位:mm ERC-1004A - 17 -...
  • Page 24: 外部结构图

    使用说明 ERC-1004A-32 配置 单位:mm 4.3 外部结构图 ERC-1004A-01、02、03、04 配置的正视图 项目 描述 接地螺钉 USB 5/6 - 18 - ERC-1004A...
  • Page 25 使用说明 ERC-1004A-06、07 配置的正视图 项目 描述 接地螺钉 USB 5/6 ERC-1004A-11 配置的正视图 项目 描述 USB 5/6 COM13 COM14 ERC-1004A-12/13 配置的正视图 备注 面板上无接口 ERC-1004A - 19 -...
  • Page 26 使用说明 ERC-1004A-21 配置的正视图 项目 描述 接地螺钉 USB 5/6 ERC-1004A-22 配置的正视图 项目 描述 接地螺钉 USB 5/6 ERC-1004ALA070A、B、C 配置的正视图 项目 描述 接地螺钉 USB 5/6 - 20 - ERC-1004A...
  • Page 27 使用说明 ERC-1004A-31、33 配置的正视图 项目 描述 接地螺钉 USB 5/6 CFast ERC-1004A-32 配置的正视图 项目 描述 CFast ERC-1004A - 21 -...
  • Page 28 使用说明 ERC-1004A-01、02、03、04、06 配置的后视图 项目 描述 电源输入端子 电源开关 音频接口 LAN2/USB3-4 LAN1/USB1-2 COM2 CF 卡盖 COM1 VGA1 LVDS MS/KB 清 CMOS 按键 RESET 按键 电源指示灯 硬盘指示灯 VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14 - 22 - ERC-1004A...
  • Page 29 使用说明 ERC-1004A-07 配置的后视图 项目 描述 电源输入端子 电源开关 音频接口 LAN2/USB3-4 LAN1/USB1-2 COM2 CF 卡盖 COM1 VGA1 LVDS MS/KB 清 CMOS 按键 RESET 按键 电源指示灯 硬盘指示灯 VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14 电源输出端子 ERC-1004A - 23 -...
  • Page 30 使用说明 ERC-1004A-11 配置的后视图 项目 描述 GPIO 音频接口 接地螺钉 LAN2/USB3-4 LAN1/USB1-2 COM2 CF 卡盖 DOM 盘 COM1 VGA1 LVDS MS/KB 清 CMOS 按键 RESET 按键 电源指示灯 硬盘指示灯 VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 电源输入端子 电源开关 - 24 - ERC-1004A...
  • Page 31 使用说明 ERC-1004A-12 配置的后视图 项目 描述 电源输入端子 电源开关 音频接口 LAN2/USB3-4 LAN1/USB1-2 COM2 CF 卡盖 DOM 盘 COM1 VGA1 LVDS MS/KB 清 CMOS 按键 RESET 按键 电源指示灯 硬盘指示灯 USB5/6 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 VGA2 GPIO VGA3 接地螺钉 ERC-1004A - 25 -...
  • Page 32 使用说明 ERC-1004A-13 配置的后视图 项目 描述 电源输入端子 电源开关 音频接口 LAN2/USB3-4 LAN1/USB1-2 COM2 CF 卡盖 COM1 VGA1 LVDS MS/KB 清 CMOS 按键 RESET 按键 电源指示灯 硬盘指示灯 USB5/6 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 VGA2 GPIO VGA3 接地螺钉 - 26 - ERC-1004A...
  • Page 33 使用说明 ERC-1004A-21 配置的后视图 项目 描述 电源输入端子 电源开关 音频接口 LAN2/USB3-4 LAN1/USB1-2 COM2 CF 卡盖 COM1 VGA1 LVDS MS/KB 清 CMOS 按键 RESET 按键 电源指示灯 硬盘指示灯 VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14 ERC-1004A - 27 -...
  • Page 34 使用说明 ERC-1004A-22 配置的后视图 项目 描述 电源输入端子 电源开关 音频接口 LAN2/USB3-4 LAN1/USB1-2 COM2 CF 卡盖 COM1 VGA1 LVDS MS/KB 清 CMOS 按键 RESET 按键 电源指示灯 硬盘指示灯 VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14 - 28 - ERC-1004A...
  • Page 35 使用说明 ERC-1004ALA070A、B、C 配置的后视图 项目 描述 电源输入端子 电源开关 音频接口 LAN2/USB3-4 LAN1/USB1-2 COM2 CF 卡盖 COM1 VGA1 LVDS MS/KB 清 CMOS 按键 RESET 按键 电源指示灯 硬盘指示灯 VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO VGA3 ERC-1004A - 29 -...
  • Page 36 使用说明 ERC-1004A-31 配置的后视图 项目 描述 电源输入端子 电源开关 音频接口 LAN2/USB3-4 LAN1/USB1-2 COM2 CF 卡盖 COM1 VGA1 LVDS MS/KB 清 CMOS 按键 RESET 按键 电源指示灯 硬盘指示灯 VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14 - 30 - ERC-1004A...
  • Page 37 使用说明 ERC-1004A-32 配置的后视图 项目 描述 电源输入端子 电源开关 接地螺钉 LAN2/USB3-4 LAN1/USB1-2 COM2 CF 卡盖 COM1 VGA1 LVDS MS/KB 清 CMOS 按键 RESET 按键 电源指示灯 硬盘指示灯 USB5/6 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 音频接口 COM14 GPIO ERC-1004A - 31 -...
  • Page 38 使用说明 ERC-1004A-33 配置的后视图 项目 描述 电源输入端子 电源开关 音频接口 LAN2/USB3-4 LAN1/USB1-2 COM2 CF 卡盖 COM1 VGA1 LVDS MS/KB 清 CMOS 按键 RESET 按键 电源指示灯 硬盘指示灯 VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14 - 32 - ERC-1004A...
  • Page 39: 接口定义

    使用说明 4.4 接口定义 4.4.1 电源输入接口 管脚 信号名称 正 负 负 正 注:第 1、2PIN 为整机电源输入脚,第 3、4PIN 为远程开关机脚(其功能与面 板电源开关一致,即将第 3、4PIN 短接,触发整机开机或关机) 。 4.4.2 电源输出接口 信号名称 管脚 +12V 注:此接口输出最大 1A 电流。 4.4.3 音频接口 管脚 信号名称 LINE_OUT AUDIO MIC_IN ERC-1004A - 33 -...
  • Page 40: Usb接口(Usb1~Usb6 均为标准Usb接口)

    使用说明 4.4.4 USB接口(USB1~USB6 均为标准USB接口) 管脚 信号名称 USB_Data- USB1-2 USB_Data+ USB3-4 USB5-6 4.4.5 网络接口(LAN1 和LAN2 均为标准接口) LILED 网络速度 ACTLED 网络活动 (双色:橙绿双色) 指示状态 (单色:绿色灯) 指示状态 绿色 1000Mbps 闪烁 有数据传输 橙色 100Mbps 灭 无数据传输 灭 10Mbps 4.4.6 并口(采用标准LPT接口) - 34 - ERC-1004A...
  • Page 41: 显示接口

    使用说明 信号名称 管脚 信号名称 管脚 STB# AFD# ERR# INIT# SLIN# ACK# BUSY SLCT 4.4.7 显示接口 1、VGA 采用标准 DB15 接口。 管脚 信号名称 管脚 信号名称 Green Blue VGA1/VGA2/VGA3 DDCDATA HSYNC VSYNC DDCCLK ERC-1004A - 35 -...
  • Page 42: Gpio接口

    注意: 此接口为 LVDS 信号, 不能使用 DVI 连接线直接插入显示器的 DVI 接口。 信号名称 管脚 信号名称 管脚 LVDS_D2- LVDS_D2+ BKLTEN BKLTCTL LVDS_D1- LVDS_D1+ VDD_LCD VDD_LCD +12V LVDS1 LVDS_D0- LVDS_D0+ LVDS_CLK+ LVDS_CLK- +12V +12V 4.4.8 GPIO接口 1、GPIO 采用 DB44 孔型接口,32 路非光耦隔离配置。 GPIO1 - 36 - ERC-1004A...
  • Page 43 GPIO24 GPIO25 GPIO26 GPIO27 GPIO13 GPIO28 GPIO29 GPIO14 GPIO30 GPIO31 GPIO15 GPIO32 备注: GPIO[32:1]可任意配置为输入或输出,信号高电平 5V,低电平 0V。输出驱动 电流 20mA(Max)。在 EVOC FMI 界面中,该配置的 GPIO 序号与 FMI 界面显示 的序号一一对应。 VCC 定义:5V GND 定义:数字地 关于 EVOC FMI 编程接口详情,请向当地 EVOC 客服中心咨询索取。 ERC-1004A - 37 -...
  • Page 44 使用说明 输入接线示意图: R1=10KΩ PC_5V SMBus转GPIO控制器 IO接口逻辑示意图 DI/DO 内部 外部 2、GPIO 采用 DB44 孔型接口,36 路光耦隔离配置。 GPIO1 管脚 信号名称 管脚 信号名称 PCOM DO10 DO11 ECOM DO12 GND_ISO DO13 PCOM DO14 DI12 DI13 DI14 - 38 - ERC-1004A...
  • Page 45 备注: DO[20:1]定义为输出,逻辑高电平由 PCOM 供电电压值决定,电压范围:0~ 48V,输出电流≤+200mA(仅单路输出时,最大驱动电流值)。在 EVOC FMI 界 面中,该配置的 DO[20:1]序号与 FMI 界面显示的 GPIO[20:1]序号一一对应。 DI[16:1]定义为输入, 高电平为 3V~5V, 低电平为 0V~2V, 输入电流≥20mA。 在 EVOC FMI 界面中,该配置的 DI[16:1]序号与 FMI 界面显示的 GPIO[36:21] 序号一一对应。 PCOM 定义:数字输出无动作状态共模信号。 ECOM 定义:数字输入共模信号。 GND_ISO 定义:隔离地。 关于 EVOC FMI 编程接口详情,请向当地 EVOC 客服中心咨询索取。...
  • Page 46 使用说明 输出接线示意图: 内部 外部 PC_5V ISO_5V PCOM ISO_DO 负载 GND_ISO 隔离 3、GPIO 采用 DB25 孔型接口,24 路非光耦隔离配置。 GPIO 管脚 信号名称 管脚 信号名称 DO13 DO14 DO15 DO16 DO10 DO11 DO12 - 40 - ERC-1004A...
  • Page 47: 鼠标键盘接口(采用标准二合一鼠标键盘接口

    使用说明 备注: GND:信号地,对应于 FMI 界面显示 GPIO[1]; DO[16:1]定义为输出,上电后初始输出为高,DO 输出驱动能力≥20mA,高电 平 3.5~5.5V,低电平为 0V~0.8V,在 EVOC FMI 界面中,该配置的 DO[16:1] 序号与 FMI 界面显示的 GPIO[17:2]序号一一对应; DI[8:1]定义为输入,高电平为 3.5V~5.5V,低电平为 0V~0.8V,输入电流 ≤25mA,在 EVOC FMI 界面中,该配置的 DI[8:1]序号与 FMI 界面显示的 GPIO[25:18]序号一一对应。 关于 EVOC FMI 编程接口详情,请向当地 EVOC 客服中心咨询索取。 输出接线示意图: R1=200Ω PC_5V SMBus转GPIO控制器...
  • Page 48 RTS# CTS# 注:1、在 RS-485 模式下,数 据收 发方向 为自 动控制。 2、主板 JP3~JP5 为 COM1 模式选择,JP8~JP10 为 C OM2 模式选择。 模式选择 管脚 RS-232 设置 RS-422 RS-485 (Default) JP3/JP8 (JP3,JP4,JP5) JP4/JP9 1-3,2-4 3-5,4-6 3-5,4-6 (JP8,JP9,JP10) JP5/JP10 1-3,2-4 3-5,4-6 3-5,4-6 - 42 - ERC-1004A...
  • Page 49: Sata接口

    SATA2 接口可作为 SATA 总线的 DOM 盘接口,也可作为 SATA 硬盘接口。通过 JP1 选择第 7Pin 定义。设置方式如下: 设置 功能 -2 短路 SATA 7Pin 5V 2-3 短路 SATA 7Pin GND(Default SATA2 接口定义如下: 管脚 信号名称 5V/GND 接口为非标准 7Pin SATA 信号 定义 ,根据设备规 格来设置 JP1 跳线。 ERC-1004A - 43 -...
  • Page 50: 操作控件

    使用说明 3、 主板提供 1 个 7Pin+15Pin SATA 接口,可搭配硬盘支架安装标准 2.5 寸 SATA 硬盘或电子盘使用。其接口定义如下: 管脚 信号名称 管脚 信号名称 SATA_TX+ SATA_TX- SATA_RX- SATA_RX+ +3.3V +3.3V +12V +3.3V +12V +12V 4.5 操作控件 警告 开/关按钮信号不会切断 PC 电源! 小心 PC 执行硬件复位时可能会丢失数据。 - 44 - ERC-1004A...
  • Page 51: 状态指示灯

    断电的情 况下, 使用尖物或回形针 可操作清CMOS按钮。 按 ② 钮信号将触发BIOS复位。 整机BIOS设置恢复到出 厂设置 复位按钮 使用尖物或回 形针可操 ③ 作复位按钮。 按钮信号 将触发硬件复位。 整机 执行重启动(冷启动) 4.6 状态指示灯 显示 含义 描述 不亮 已从电源断开 POWER PC 状态显示 绿色 PC 运行中 不亮 无访问 显示硬盘访问 绿色 访问 ERC-1004A - 45 -...
  • Page 52: 拆装与维护

    拆装与维护 5.拆装与维护 5.1 整体装配图 项目 描述 项目 描述 项目 描述 主板面板 扩展板面板 扩展板 电源模块 底盖 主板 硬盘(仅-04、 硬盘支架(仅 线材固定架 -04、-22 配置) -22 配置) PCI 转接板及支 DOM 盘(仅 箱体 架(仅-02、-22 -01/-02/-03/配置) 配置) 主板散热器 箱体壁挂条 CF 卡盖 - 46 - ERC-1004A...
  • Page 53: 开盖安装

    拆装与维护 5.2 开盖安装 1、 卸下位于机箱顶面的两颗固定箱盖的螺钉; 2、 延图示方向将上盖打开。 5.3 主板拆装 5.3.1 主板安装 1、如上图所示,将主板与已固定在支架上的 PCI 转接板对插(-01/-02/-03 配 置省略此步骤) ; ERC-1004A - 47 -...
  • Page 54: 主板拆卸

    拆装与维护 2、将主板和 PCI 转接板模块放在底盖的对应螺柱上(底盖上应已固定好散热器 并在散热器凸台位置涂好导热膏贴好导热垫) ,安装孔与底盖上的各螺柱对 齐, 并用配套螺钉锁付主板各安装孔和 PCI 转接板支架, 使之固定在底盖上。 5.3.2 主板拆卸 1、 拆除固定箱体与底盖在两侧与机箱前面板上的 7 颗螺钉; 2、 拆除固定箱体与主板面板位于机箱两侧的螺钉; 3、 拆除固定箱体与 PCI 扩展板支架的两颗螺钉(-01/-02/-03/-11 配置省略此 步骤) ; - 48 - ERC-1004A...
  • Page 55 拆装与维护 4、 将固定了主板和 PCI 转接板的底盖与箱体分离; 5、 拆除固定主板、PCI 转接板支架和底盖的各螺钉,如上图所示; 6、将主板沿上图所示方向拔出(-01/-02/-03 配置省略此步骤) 。 ERC-1004A - 49 -...
  • Page 56: 驱动器拆装

    拆装与维护 5.4 驱动器拆装 1、 如图所示,拆除固定硬盘支架的四颗螺钉; 2、 将硬盘模块轻轻移出主板上的 SATA 连接器即可取下硬盘模块。 5.5 电源拆装 5.5.1 电源安装 将电源固定在箱体侧壁图示位置,在对应位置锁付螺钉。 - 50 - ERC-1004A...
  • Page 57: 电源拆卸

    拆装与维护 5.5.2 电源拆卸 危险 拆卸电源模块前,若有电源接入,则必须关闭电源,拆除电源线。 1、 卸除位于箱体侧面固定电源的三颗螺钉; 2、 卸除位于箱体两侧固定主板面板的两颗螺钉; 3、 卸除固定主板面板与底盖的螺钉; 4、 卸除固定主板各连接器与主板面板的六角螺柱; 5、 取下主板面板; 6、 沿图示方向拉出电源模块。 ERC-1004A - 51 -...
  • Page 58: 壁挂条安装

    拆装与维护 5.6 壁挂条安装 如上图所示,使用配件中的配套螺钉将壁挂条固定在机箱底盖。 5.7 扩展卡模块拆装 1、 拆除扩展板上的 FPC 柔性线路板和电源线; 2、 卸下位于两侧固定扩展板面板与箱体的 4 颗螺钉; 3、 沿图示方向拉出扩展板及面板。 - 52 - ERC-1004A...
  • Page 59: Cfast卡拆装

    拆装与维护 5.8 CFast卡拆装 ERC-1004A-31/32/33 直接拧开 CFast 卡盖的两颗松不脱螺钉,取下 CFast 卡盖,用手指推动位于 CFast 卡槽上的推杆,即可将 CFast 卡取出。 ERC-1004A - 53 -...
  • Page 60: 驱动程序安装说明

    驱动程序安装说明 6.驱动程序安装说明 6.1 驱动程序安装说明 本产品的驱动程序安装及主板详细信息请参考整机配套光盘,在此不做介 绍。 - 54 - ERC-1004A...
  • Page 61: 显卡驱动安装说明

    驱动程序安装说明 6.2 显卡驱动安装说明 1. xp 系统下安装好 intel 显卡驱动和 ch7036 显卡驱动后,再安装 712 显卡驱 动。 2. 右键单击“我的电脑” ,选择“管理”-“设备管理器” ,在“显示卡”列表 中选择“Silicon Motion LynxEM+” ,右键选择“更新驱动程序” ,如图选择 “从列表或指定位置安装” ,进行下一步:   如图选择“不要搜索,自己选择要安装的驱动程序” ,进行下一步:   ERC-1004A - 55 -...
  • Page 62 驱动程序安装说明 查找到“Silicon Motion LynxEM+”该硬件设备,如图选择“从磁盘安装”:   如图选择驱动文件所存放的路径:           - 56 - ERC-1004A...
  • Page 63 选择“仍然继续” ,完成 712 显卡驱动的安装,然后重启电脑。 3. 712 显卡搭配 intel 集成显卡实现三显功能, 其中 intel 集成显卡为主, 712 显卡为从,并且 712 显卡只能设为扩展模式。桌面上单击右键,在“图形属 性”和“图形选项”中调节的是 intel 集成显卡的模式,对应整机丝印 VGA1 和 VGA2,在“属性”-“设置”一栏中,可以调节 intel 集成显卡和 712 显 卡的显示模式。 4. 安装完驱动后,如果 intel 集成显卡或者 712 显卡中“颜色质量”为“低 8 位” ,出现掉色,请手动调节至最高。如下图所示: ERC-1004A - 57 -...
  • Page 64 驱动程序安装说明 5. VGA2 是 LVDS 信号通过 ch7036 转接出来的 VGA 信号,该分辨率受 bios 中的 设置影响。 6. 如果驱动中分辨率固定不可调节的话,请如图: 选择“高级”-“监视器”一栏:   不勾选“隐藏该监视器无法显示的模式” (驱动中该选项默认是勾选的) ,然 后点“确定” ,此时再去调节分辨率,分辨率就变为可手动调节。 - 58 - ERC-1004A...
  • Page 65 驱动程序安装说明 7. ERC-1004A-21/22 的整机,Intel 显卡驱动默认最佳分辨率满屏,当设置其 他分辨率时,如果出现缩屏居中显示,请按下图设置显卡驱动中的刷新率和 拉伸选项。 ERC-1004A - 59 -...
  • Page 66: 常见故障分析与解决

    2、检查显示器电缆是否正确 未连接电源线或显示器电 地连接到系统单元和显示 缆 器。 3、如果执行这些检查后显示 器屏幕仍不亮,请与技术 支持联系。 根据开机画面提示的按键,打 PC 上 的 时 间 或 BIOS 设置不正确 开 BIOS Setup, 在 BIOS Setup 日期不正确。 中调整时间和日期。 BIOS 设置正确, 时 间 和 日 期 不 备用电池电量不足 更换电池 对。 - 60 - ERC-1004A...
  • Page 67 中。 检查硬盘(硬盘必须是已经装 硬盘电源线或数据线未接 好系统可引导的)的电源线、 好 数据线是否插好。 开机提示找不到 用可引导的光盘进入系统(常 系统盘 用 winpe 系统) ,检查硬盘系 硬盘系统文件损坏 统是否已损坏,有必要时最好 重新安装系统。 一般是由于 PCI 或 ISA 卡频繁 即 插 即 用 I / O 的拔插、固定不稳、防尘措施 卡设备,再次使 插槽接触不良 不好等造成插槽接触不良所 用时检测不到或 致,可反复拔插几次或者换个 不能正常使用。 槽插。 ERC-1004A - 61 -...
  • Page 68 Please pay attention to the following instructions: Warning EVOC product can only be used according to the descriptions within the manual, including the contents and the relevant technical documents. If the products or components from other companies are required, please get the recommendation and grant from EVOC first.
  • Page 69 Trademarks EVOC is a registered trademark of EVOC Intelligent Technology Co., Ltd. Other product names mentioned herein are used for identification purposes only and may be trademark and/or registered trademarks of their respective companies.
  • Page 70 About this manual Scope of the Manual The manual is appropriate for EVOC ERC-1004A. Convention The term “the Board” or “the Product” within the manual stands for EVOC ERC-1004A. Instructions Safety instructions To avoid property losses or individual injury, please pay attention to the safety instructions within the manual.
  • Page 71 Contents 1. Product Introduction ....................1 1.1 Overview......................1 1.2 Product Specifications ..................1 2. Application Scheme ....................6 2.1 Transportation ....................6 2.2 Storage ......................6 2.3 Opening the Box and Initial Examination............6 2.4 Mounting Mode ....................7 3. Device Connection....................8 3.1 Notices before Connection................8 3.2 Product Grounding..................8 3.3 Connecting the Device to Power..............9 4.
  • Page 72 4.4.8 GPIO Port..................36 4.4.9 Mouse & Keyboard Connector (adopts standard 2-in-1 mouse & keyboard connector).................42 4.4.10 Serial Port..................42 4.4.11 SATA Connector ................43 4.5 Operation Control ..................45 4.6 Status Indicator .....................45 5. Assembly and Maintenance ..................46 5.1 Overall Assembly Drawing................46 5.2 Installing the Cover..................47 5.3 Removal and Installation of Motherboard ............47 5.3.1 Installing the Motherboard ..............47 5.3.2 Removing the Motherboard.............48...
  • Page 73: Product Introduction

    ERC-1004A is the main control unit of the AFC system for metro, which is used as the main control unit of the AGM, TVM and BOM in AFC system. The PC complies with GB 9254-2008 and GB/T 17626-2008 standards.
  • Page 74 64.4mm in height and 167.6mm in length; PCI2.3 standard-compliant (optional) ICH8M platform: support SATA DOM, IDE DOM, CF card, 2.5〞SSD or HDD Storage Support Baytrail-I SOC platform: support SATA DOM, CF card, 2.5〞SSD or HDD, SATA Slim - 2 - ERC-1004A...
  • Page 75 1 x IDE DOM disk port (IDE DOM disk optional, please refer to the actual configuration of complete PC);  One LPT connector.  1 x CFast card slot ( CFast card optional, please refer to the actual configuration of complete PC) ERC-1004A - 3 -...
  • Page 76 Product Introduction Dimensions: ERC-1004A-11 configuration:170mm (W) x 105mm Dimensions (H) x 235mm (D) ERC-1004A-31/32/33 configuration: 200mm(W)× (excluding the 97.3mm(H)× 260mm(D) hangers) Other configuration:200mm (W) x 105mm (H) x 260mm (D) 4.3 kg Weight Temperature Storage Temperature: -40°C ~ 80°C Humidity 5%~95% (non-condensing)
  • Page 77 The upper layer application software has no need to pay attention to the bottom layer design.  Provides watchdog programming connector;  Provides hardware monitoring connector (such as EVOC FMI temperature, motherboard operation voltage, etc.)  Provides GPIO programming connector;...
  • Page 78: Application Scheme

    (condensation) is formed on the surface or interior of the device. If condensation is formed on the device, please wait for over twelve hours before connecting the device. 2.3 Opening the Box and Initial Examination Opening the Box - 6 - ERC-1004A...
  • Page 79: Mounting Mode

    ● Please check whether the delivery contains the intact device and all of the independently ordered accessories. Please contact the customer service when any unconformity or transportation damages occur. 2.4 Mounting Mode □19″ Rack Mount ■Desktop □Embedded Panel ■Wall Mount □VESA Standard Arm □Portable □Others___________ ERC-1004A - 7 -...
  • Page 80: Device Connection

    (large surface or large area contact) shall be connected with the cabinet installed with the PC or the central grounding busbar ERC-1004A-11/12/13configuration on the device. The minimum cross section area of the cable shall be no less than 5mm...
  • Page 81: Connecting The Device To Power

    ①. Please refer to the pin definitions of the power connector for detailed ERC-1004A-11 configuration information. Connect the power cord with the connector ① and press down the switch ② with the silkscreen of “dot”.
  • Page 82: Instructions

    Instructions 4. Instructions 4.1 Product Outline ERC-1004A-01,02,03,04 configuration ERC-1004A-06 configuration ERC-1004A-07 configuration - 10 - ERC-1004A...
  • Page 83 Instructions ERC-1004A-11 configuration ERC-1004A-12 configuration ERC-1004A-13 configuration ERC-1004A - 11 -...
  • Page 84 Instructions ERC-1004A-21 configuration ERC-1004A-22 configuration ERC-1004ALA070A、B、C configuration - 12 - ERC-1004A...
  • Page 85 Instructions ERC-1004A-31 configuration ERC-1004A-32 configuration ERC-1004A-33 configuration ERC-1004A - 13 -...
  • Page 86: Product Appearance And Installation Dimensions

    Instructions 4.2 Product Appearance and Installation Dimensions ERC-1004A-01,02,03,04 configuration Unit: mm ERC-1004A-06, 07 configuration Unit: mm - 14 - ERC-1004A...
  • Page 87 Instructions ERC-1004A-11 configuration 9.75 47.5 R2.25 Unit: mm ERC-1004A-12, 13 configuration Unit: mm ERC-1004A - 15 -...
  • Page 88 Instructions ERC-1004A-21 configuration Unit: mm ERC-1004A-22 configuration Unit: mm - 16 - ERC-1004A...
  • Page 89 Instructions ERC-1004ALA070A、B、C configuration Unit: mm ERC-1004A-31、33 configuration Unit: mm ERC-1004A - 17 -...
  • Page 90: External Structure

    Instructions ERC-1004A-32 configuration Unit: mm 4.3 External Structure Front view of ERC-1004A-01, 02, 03, 04 Item Description GND screw USB 5/6 - 18 - ERC-1004A...
  • Page 91 Instructions Front view of ERC-1004A-06, 07 Item Description GND screw USB 5/6 Front view of ERC-1004A-11 Item Description USB 5/6 COM13 COM14 Front view of ERC-1004A-12, 13 Note No interface on the panel ERC-1004A - 19 -...
  • Page 92 Instructions Front view of ERC-1004A-21 Front Description GND screw USB 5/6 Front view of ERC-1004A-22 Front Description GND screw USB 5/6 Front view of ERC-1004ALA070A、B、C Front Description GND screw USB 5/6 - 20 - ERC-1004A...
  • Page 93 Instructions Front view of ERC-1004A-31、33 Front Description GND screw USB 5/6 CFast Front view of ERC-1004A-32 Front Description CFast ERC-1004A - 21 -...
  • Page 94 Instructions Rear view of ERC-1004A-01,02,03,04,06 Item Description DC-in terminal Power switch Audio LAN2/USB3-4 LAN1/USB1-2 COM2 CF card cover COM1 VGA1 LVDS MS/KB Clear CMOS button RESET button Power indicator HDD indicator VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14...
  • Page 95 Instructions Rear view of ERC-1004A-07 Item Description DC-in terminal Power switch Audio LAN2/USB3-4 LAN1/USB1-2 COM2 CF card cover COM1 VGA1 LVDS MS/KB Clear CMOS button RESET button Power indicator HDD indicator VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14...
  • Page 96 Instructions Rear view of ERC-1004A-11 Item Description GPIO Audio Ground screw LAN2/USB3-4 LAN1/USB1-2 COM2 CF card cover DOM disk COM1 VGA1 LVDS MS/KB Clear CMOS button RESET button Power indicator HDD indicator VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 DC-in terminal...
  • Page 97 Instructions Rear view of ERC-1004A-12 Item Description DC-in terminal Power switch Audio LAN2/USB3-4 LAN1/USB1-2 COM2 CF card cover DOM disk COM1 VGA1 LVDS MS/KB Clear CMOS button RESET button Power indicator HDD indicator USB5/6 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 VGA2...
  • Page 98 Instructions Rear view of ERC-1004A-13 Item Description DC-in terminal Power switch Audio LAN2/USB3-4 LAN1/USB1-2 COM2 CF card cover COM1 VGA1 LVDS MS/KB Clear CMOS button RESET button Power indicator HDD indicator USB5/6 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 VGA2 GPIO VGA3...
  • Page 99 Instructions Rear view of ERC-1004A-21 Item Description DC-in terminal Power switch Audio LAN2/USB3-4 LAN1/USB1-2 COM2 CF card cover COM1 VGA1 LVDS MS/KB Clear CMOS button RESET button Power indicator HDD indicator VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14...
  • Page 100 Instructions Rear view of ERC-1004A-22 Item Description DC-in terminal Power switch Audio LAN2/USB3-4 LAN1/USB1-2 COM2 CF card cover COM1 VGA1 LVDS MS/KB Clear CMOS button RESET button Power indicator HDD indicator VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14...
  • Page 101 Rear view of ERC-1004ALA070A、B、C Item Description DC-in terminal Power switch Audio LAN2/USB3-4 LAN1/USB1-2 COM2 CF card cover COM1 VGA1 LVDS MS/KB Clear CMOS button RESET button Power indicator HDD indicator VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO VGA3 ERC-1004A - 29 -...
  • Page 102 Instructions Rear view of ERC-1004A-31 Item Description DC-in terminal Power switch Audio LAN2/USB3-4 LAN1/USB1-2 COM2 CF card cover COM1 VGA1 LVDS MS/KB Clear CMOS button RESET button Power indicator HDD indicator VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14...
  • Page 103 Instructions Rear view of ERC-1004A-32 Item Description DC-in terminal Power switch GND screw LAN2/USB3-4 LAN1/USB1-2 COM2 CF card cover COM1 VGA1 LVDS MS/KB Clear CMOS button RESET button Power indicator HDD indicator USB5/6 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 Audio...
  • Page 104 Instructions Rear view of ERC-1004A-33 Item Description DC-in terminal Power switch Audio LAN2/USB3-4 LAN1/USB1-2 COM2 CF card cover COM1 VGA1 LVDS MS/KB Clear CMOS button RESET button Power indicator HDD indicator VGA2 COM3/COM4 COM5/COM6 COM7/COM8 COM9/COM10 COM11/COM12 COM13 GPIO COM14...
  • Page 105: Pin Definitions

    (its function is consistent with the panel power switch, the 3, 4 pin sub, triggering the PC boot or shutdown. 4.4.2 Power Output Connector Signal Name +12V Note: This connector outputs a maximum of 1A current. 4.4.3 Audio Connector Signal Name LINE_OUT AUDIO MIC_IN ERC-1004A - 33 -...
  • Page 106: Usb Port (Usb1 ~ Usb6 Are Standard Usb Ports)

    4.4.5 LAN Port (LAN1 and LAN2 are standard connectors) LILED LAN Speed ACTLED LAN Activity (Dual-Color: O/G) Indicator (Green) Status Indicator Green 1000Mbps Blink Data being transmitted Orange 100Mbps No data being transmitted 10Mbps 4.4.6 Parallel Port (Adopts standard LPT connector) - 34 - ERC-1004A...
  • Page 107: Display Connector

    Instructions Signal Name Signal Name STB# AFD# ERR# INIT# SLIN# ACK# BUSY SLCT 4.4.7 Display Connector 1. VGA adopts standard DB15 connector. Signal Name Signal Name Green Blue VGA1/VGA2/VGA3 DDCDATA HSYNC VSYNC DDCCLK ERC-1004A - 35 -...
  • Page 108: Gpio Port

    DVI cable directly. Signal Name Signal Name LVDS_D2- LVDS_D2+ BKLTEN BKLTCTL LVDS_D1- LVDS_D1+ VDD_LCD VDD_LCD +12V LVDS1 LVDS_D0- LVDS_D0+ LVDS_CLK+ LVDS_CLK- +12V +12V 4.4.8 GPIO Port 1. GPIO1 adopts DB44 pin-hole connector, 32-channel non-optical coupling isolation configuration. GPIO1 - 36 - ERC-1004A...
  • Page 109 Note: GPIO[32:1] may be configured as either input or output, with 5V high level and 0V low level signals. The output drive current is 20mA(Max). In the EVOC FMI interface, the GPIO numbers of that configuration correspond to those displayed in the FMI interface  ...
  • Page 110 Instructions Diagram of input connection: R1=10KΩ 2. GPIO1 adopts DB44 pin-hole connector, 36-channel optical coupling isolation configuration. GPIO1 Signal Name Signal Name PCOM DO10 DO11 ECOM DO12 GND_ISO DO13 PCOM DO14 DI12 DI13 - 38 - ERC-1004A...
  • Page 111 DO[20:1] is defined as output; logic high level is determined by PCOM power supply voltage; voltage range: 0~48V; output current ≤+200mA (maximum drive current, only for single-channel output). In the EVOC FMI interface, the DO[20:1] numbers of that configuration correspond to the GPIO[20:1] numbers displayed in the FMI interface on a one-to-one basis.
  • Page 112 Instructions Diagram of Input Connection: R1=49.9Ω,R2=100Ω Diagram of Output Connection: 3、GPIO1 adopts DB25 pin-hole connector, 24-channel non-optical coupling isolation configuration. GPIO Signal Name Signal Name DO13 DO14 DO15 DO16 - 40 - ERC-1004A...
  • Page 113 DO[16:1] is defined to be output. After the PC is powered up, the initial output is high, DO output driving capability≥20mA, high level 3.5 ~ 5.5V; low level 0V~0.8V. On the EVOC FMI interface, the DO[16:1] serial numbers of the configuration correspond to GPIO[17:2] serial numbers displayed on the FMI interface;...
  • Page 114: Mouse & Keyboard Connector

    Adopts standard DB9 pin header; COM1 and COM2 support RS-232/RS-422/RS-485 mode; COM1 supports Modem wake-up; COM3 ~ COM14 support RS-232 mode. Signal Name RS-232 RS-422 RS-485 DCD# TXD- Data- TXD+ Data+ RXD+ DTR# RXD- COM1,COM2 DSR# RTS# CTS# - 42 - ERC-1004A...
  • Page 115: Sata Connector

    2、SATA2 interface can be used as DOM port of SATA bus, and can also be used as SATA HDD interface. The definition of Pin7 can be selected via JP1.Please set as follows: Setup Function 1-2 Short SATA 7Pin 5V 2-3 Short SATA 7Pin GND(Default) ERC-1004A - 43 -...
  • Page 116 3. The motherboard provides one 7Pin+15Pin SATA interface, which can be used for 2.5-inch SATA HDD or SSD installed on a HDD bracket. Its pin definitions are as follows: Signal Name Signal Name SATA_TX+ SATA_TX- SATA_RX- SATA_RX+ +3.3V +3.3V +12V +3.3V +12V +12V - 44 - ERC-1004A...
  • Page 117: Operation Control

    Pressing button signal will reset the hardware. The PC will be rebooted (cold reset). 4.6 Status Indicator Display Meaning Description Disconnected with power supply POWER Indicates PC status Green PC is operating No access Indicates HDD access Green Accessing ERC-1004A - 45 -...
  • Page 118: Assembly And Maintenance

    -04, Bracket -04, -22 only) -22 only) Expansion DOM disk (for Board and Bracket Chassis configuration -01/ (for configuration -02/-03 only) -02 , -22 only) Motherboard Wall Mounting Bar CF Card Cover Heat Sink on Chassis - 46 - ERC-1004A...
  • Page 119: Installing The Cover

    Open the top cover along the direction shown in the figure. 5.3 Removal and Installation of Motherboard 5.3.1 Installing the Motherboard Connect the motherboard with the PCI expansion board fixed on the bracket, as shown in the above figure (skip this step for configuration -01/-02/-03); ERC-1004A - 47 -...
  • Page 120: Removing The Motherboard

    PCI expansion board bracket on to the bottom cover with enclosed screws. 5.3.2 Removing the Motherboard - 48 - ERC-1004A...
  • Page 121 Remove all the screws fixing the motherboard, the PCI expansion card bracket and the bottom cover as shown in the above figure; Remove the motherboard along the arrow head direction shown in the above figure (skip this step for configuration -01/-02/-03). ERC-1004A - 49 -...
  • Page 122: Removal And Installation Of Driver

    Assembly and Maintenance 5.4 Removal and Installation of Driver Remove the four screws fixing the hard disk bracket as shown in the figure; Remove the hard disk module gently away from the SATA connector on motherboard. - 50 - ERC-1004A...
  • Page 123: Removal And Installation Of Power Supply

    Fix the power supply on the side wall of the chassis as shown in the figure and fasten with screws. 5.5.2 Removing the Power Supply Danger Before removing the power module, please turn off the power and remove the power cable if any power is connected. ERC-1004A - 51 -...
  • Page 124: Installing The Wall-Mounted Bars

    Draw out the power module along the direction shown in the figure. 5.6 Installing the Wall-mounted Bars Fix the wall-mounted bars on the bottom cover of the chassis with the enclosed screws as shown in the above figure. - 52 - ERC-1004A...
  • Page 125: Removal And Installation Of Expansion Card Module

    5.8 Removal and Installation of CFast card ERC-1004A-31/32/33 Loosen the captive screws on the CFast card cover directly, remove CFast card cover. Then use fingers to push the push rod on the CFast card slot, the CFast card can be removed.
  • Page 126: Installing The Drivers

    Installing the Drivers 6. Installing the Drivers 6.1 Installing the Drivers Regarding the driver program of this product, please refer to the enclosed CD. - 54 - ERC-1004A...
  • Page 127: Installing The Graphics Card Driver

    “Update Driver”, select “Install from a list or specific location” as shown in the figure below, then press “Next”: As shown in the figure below, select “Don't search. I will choose the driver to install”, then press “Next”: ERC-1004A - 55 -...
  • Page 128 Installing the Drivers Find “Silicon Motion LynxEM+” hardware device, and select “Install From Disk”: Select the file path to save the driver file. - 56 - ERC-1004A...
  • Page 129 After the driver installation is finished, if the “Color Quality” of Intel integrated graphics card or 712 graphics card is “Low8bit”, and color fading occurs, please manually adjust it to the maximum, as shown in the figure below: ERC-1004A - 57 -...
  • Page 130 VGA2 is a VGA signal converted from ch7036, and its resolution is related to the settings in BIOS. If the resolution in the driver is fixed and cannot be adjusted, see the figure below: Select “Advanced”-“Monitor”: - 58 - ERC-1004A...
  • Page 131 “Confirm”, and then the resolution can be adjusted manually. The PC of ERC-1004A-21/22, the default optimal full-screen resolution of Intel video card drive. When another resolution is set, if the screen is reduced and located at center, please press the Refresh Rate and Stretch options in the video card drive as shown below.
  • Page 132: Appendix

    Follow the power-on prompt and Incorrect time or press the key to enter the BIOS Incorrect BIOS setting date on PC Setup; adjust the time and date in BIOS Setup. - 60 - ERC-1004A...
  • Page 133 IO Poor contact of the slot card, unstable fixing or improper dust-proof measures; please card can be used when used again remove and install the card for a few times or use another slot. ERC-1004A - 61 -...

Table of Contents
