Tools Required
• Phillips screwdriver
• 9/16" Wrench (2)
• 9/16" Socket 3/8" Drive
• 13 mm Socket
• 13 mm Wrench
• 3" Extension 3/8" Drive
• 3/8" Drive ratchet
Remove Motor Cover
1. Remove screws securing motor cover to base assembly using a Phillips screwdriver.
2. Remove motor cover.
Item
1
2
Screw, M4.2 x 19mm Phillips
3
Page 16 of 31
Description
Motor Cover
Base Assembly
Head
Qty
1
1
4
