3) MCM - Manual Configuration Module (Optional)

Rotary Switch
(SW4)
The MCM is the module that allows the user to manually set baud rate, MAC ID and other user definable
options, without the need for software configuration.
necessary. The MCM consists of two DIP switch sets (SW1 and SW2) and two rotary switches (SW3 and SW4).
MCM Module Part Numbers
G2-2 Series DeviceLogix Quick Start Manual
DIP Switch
Rotary Switch
(SW2)
(SW3)
1 2 3 4 5 6 7 8
All DIP switches shown in the "OFF" position
Description
Complete Module
Replacement Board
3835054 TDG22DLQS3-0
Subject to change without notice
www.numatics.com/fieldbus
DIP Switch
(SW1)
1 2 3 4 5 6 7 8
If software configuration is preferred, this module is not
Part Number
239-1384
256-684
1/07
Page 2
