- Page 1 User manual French version Operating and control manual for a lifting platform QUICK LIFT L520E 1-18 Imported by: Made in China: Yantai Tonghe Precision Industry Co.,Ltd GYS FRANCE www.gys.f r www.ytthjg.com...
- Page 2 DIMENSIONS Flat ramp Hydraulic power pack/ weight 20kg Max. ramp position / weight 39kg DIMENSIONS Boom length in min. position 1 746 mm Height min 88 mm Boom length in max. position 1 468 mm Maximum lifting height (with chock) 460 mm Width 315 mm...
- Page 3 Safety and functional check Carried out by the manufacturer according to the following data: The following elements are present: Technical nameplate on the product Instructions for use Max. load capacity Raise "UP", lower "DN" on the wired control unit. CE identification Controlled operation and safety: Pressure relief valve set at 180 bars Verify:...
- Page 4 Mr Wang C.E.O Yantai, 15/02/2019 Thank you for choosing GYS! In order to obtain maximum satisfaction from your QUICK LIFT lifting platform and for...
-
Page 5: Liability Limitations
your safety, please read these operating instructions carefully before first use and keep them in a safe place for future reference. BACKGROUND INFORMATION These operating instructions contain important information for installation in order to ensure proper commissioning and operational safety of the QUICK LIFT. Complying with the documentation reduces risks and extends the life of the product. - Page 6 LIFT does not come into contact with areas close to the airbag activation sensors during and after the climb. Do not place the rubber spacers on an area with plastic lining. Take care of electrical cables and hydraulic hoses, do not crush them or step on them. In the event of a violent impact on the load-bearing and/or structural elements of the QUICK LIFT, it is imperative to take the product out of service and contact your dealer or the manufacturer in order to assess the damage before putting it back into service.
- Page 7 Wired telecom Electrical outlet Hydraulic power pack Long hydraulic hoses (X2) Casters Short hydraulic hoses (X2) Locking bar Locking bar (On the outside) (On the outside) Transport handles Castors are provided on the QUICK LIFT to move the ramps easily and to allow them to be properly positioned under the vehicle.
-
Page 8: Installation
Step 4: Connect the hydraulic power pack to both booms using the quick couplings. Step 5: Check that the electrical system is equipped with a 16 A circuit breaker. Connect the hydraulic unit electrically to a 220V single-phase socket, your QUICK LIFT is ready to operate. SAFTEY AREA To achieve optimum safety, it is recommended to define an area in which other objects or walls will be at a certain distance (2m minimum). - Page 9 b. Visually check all hydraulic connections (cylinders, hoses, couplings, power pack) for hydraulic leakage. If you notice a slight leak, tighten the connection until there is no more leakage. If you see a large leak, immediately press "DN" (down) until the QUICK LIFT is lowered to the ground.
- Page 10 purging the jacks one by one below. a. Slightly loosen the bleed screw at the end of the hydraulic cylinder with a hexagon key. b. Be careful to keep your hands away from pinch points. Briefly press the "UP" button on the remote control. Air and oil will start to come out (use a container to collect the oil and place a cardboard box on the ground to avoid polluting the area).
- Page 11 She won't be able to lift a vehicle in some cases. It's not a malfunction. This can be problematic if, for example, you lift a vehicle and once raised you remove the wheels and return the QUICK LIFT to its original position (on the ground).
-
Page 12: Controls And Maintenance
descent. Position yourself so that you have an overview of the situation and can act quickly in the event of a problem. Position yourself outside the security perimeter and press the "UP" button on the wired remote control so as to raise the ramps by 2-3 cm. -
Page 13: Troubleshooting
Use the "Regular Security Check" form and the Maintenance Log to archive regular and annual checks. Make a copy of the QUICK LIFT status report and attach it to the operating instructions. Regular safety checks must be carried out by an authorised person. It is recommended to perform maintenance simultaneously. -
Page 14: Warranty Conditions
means that the circuit is open and the oil automatically returns to the tank (there is no pressure in the circuit).. DEACTIVATION Any equipment that appears damaged in any way, does not operate normally, or has missing parts should be taken out of service immediately by removing the power cord from the electrical outlet. - Page 15 Hydraulic short hose (X2) ELECTRIC CIRCUIT HYDRAULIC CIRCUIT REGULAR SECURITY CHECK Description of the QUICK LIFT L520E product Serial number Verification phase Note Technical table on the QUICK LIFT present (on hydraulic power pack) Max. load capacity 2500kg present on the 2 ramps Up "UP"...
-
Page 16: Maintenance Log
Condition of the load-bearing construction (mechanical structure) Status of the locking blocks (height 1 and height 2) Status of locking bars, cams and pins Condition of the jacks (leaks, rust...) Condition of the rubber chocks (and 4x4 option) Condition of the power cord of the hydraulic power pack General condition of the hydraulic power pack Functional test of the lifting platform with vehicle Control result... - Page 17 ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 18 Importer France GYS FRANCE 1, rue de la Croix des Landes CS 54159 53941 SAINT-BERTHEVIN Cedex France...
