SONOMA PRESIDIO STATIONARY CHAIR ASSEMBLY INSTRUCTIONS

PART LIST

A
B
C
D
E
F
G
H
I
J
K
L
M
N
FOR MISSING OR INCORRECT PARTS/HARDWARE, CONTACT THE MANUFACTURER'S CUSTOMER SERVICE DIRECTLY AT
REFER TO LAST PAGE FOR ADDITIONAL CUSTOMER SERVICE DETAILS.
SAVE THESE INSTRUCTIONS
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
FIGURE
4 PCS + 1 PC
4 PCS + 1 PC
4 PCS + 1 PC
6 PCS + 1 PC
6 PCS + 1 PC
6 PCS + 1 PC
INFO@GRANDBASKETCO.COM OR 1-800-327-2978
QUANTITY
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
2 PC
2 PC
DESCRIPTION
SEAT
BACK
RIGHT ARM
LEFT ARM
LARGE BOLT
(Φ8X20MM)
LARGE WASHER
LARGE BOLT CAP
LARGE ALLEN WRENCH
SMALL BOLT
(Φ6X30MM)
SMALL WASHER
SMALL BOLT CAP
SMALL ALLEN WRENCH
SEAT CUSHION
BACK CUSHION
