SAVE THESE INSTRUCTIONS
CORONADO HIGH DINING SWIVEL CHAIR
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
PART LIST
A
B
C
D
E
F
G
H
STYLE #: 61SRR2801COR
FIGURE
QUANTITY
DESCRIPTION
1 PC
CHAIR FRAME
1 PC
ROTATION AXIS
1 PC
4 PCS
8 PCS
FLAT WASHER
4 PCS
SPRING WASHER
4 PCS
LOCKING NUT
2 PCS
CHAIR BASE
BOLT (M8*35)
WRENCH
Page 1/2
Advertisement
Table of Contents
Related Manuals for Sonoma 61SRR2801COR
Summary of Contents for Sonoma 61SRR2801COR
- Page 1 SAVE THESE INSTRUCTIONS CORONADO HIGH DINING SWIVEL CHAIR STYLE #: 61SRR2801COR ASSEMBLE ON A FLAT, PROTECTED SURFACE. PART LIST FIGURE QUANTITY DESCRIPTION 1 PC CHAIR FRAME 1 PC ROTATION AXIS 1 PC CHAIR BASE BOLT (M8*35) 4 PCS 8 PCS...
- Page 2 CORONADO HIGH DINING SWIVEL CHAIR STYLE #: 61SRR2801COR ASSEMBLY INSTRUCTIONS (CONTINUED) STEP 1 A. PLACE THE CHAIR FRAME (A) ON A FLAT SURFACE. B. ATTACH THE ROTATION AXIS (B) TO CHAIR FAME (A) WITH FLAT WASHER (E), BOLT (G), ANOTHER FLAT WASHER (E) AND SPRING WASHER (F) ON BOTTOM OF BOLT (D) AND SECURE WITH LOCKING NUT (G).
