SONOMA PRESTON END TABLE ASSEMBLY INSTRUCTIONS
PART LIST
A
B
C
D
E
F
STEP 1
A. PLACE TOP (A) UPSIDE DOWN ON A FLAT,
PROTECTED SURFACE.
B. REMOVE DRAWER FROM TOP (A).
STEP 2
A. ATTACH 2 LEGS (B) TO BACK OF TOP (A) WITH
BOLTS (E) AND FLAT WASHERS (D) USING ALLEN
WRENCH (F). DO NOT TIGHTEN COMPLETELY.
SAVE THESE INSTRUCTIONS
STYLE #: 81SNRTB02
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
FIGURE
QUANTITY
12 PCS + 1 PC
12 PCS + 1 PC
1 PC
4 PCS
1 PC
1 PC
DESCRIPTION
TOP
LEG
SHELF
FLAT WASHER
BOLT
ALLEN WRENCH
Page 1/2
Advertisement
Table of Contents
Related Manuals for Sonoma PRESTON 81SNRTB02
Summary of Contents for Sonoma PRESTON 81SNRTB02
- Page 1 SAVE THESE INSTRUCTIONS SONOMA PRESTON END TABLE ASSEMBLY INSTRUCTIONS STYLE #: 81SNRTB02 ASSEMBLE ON A FLAT, PROTECTED SURFACE. FIGURE DESCRIPTION PART LIST QUANTITY 1 PC 4 PCS 1 PC SHELF 12 PCS + 1 PC FLAT WASHER 12 PCS + 1 PC...
- Page 2 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 81SNRTB02 STEP 3 A. ATTACH SHELF (C) TO LEGS (B) ON PREASSEMBLED UNIT WITH BOLTS (E) AND FLAT WASHERS (D) USING ALLEN WRENCH (F). DO NOT TIGHTEN COMPLETELY. B. ATTACH REMAINING 2 LEGS (B) TO TOP (A) AND SHELF (C) WITH BOLTS (E) AND FLAT WASHERS (D) USING ALLEN WRENCH (F).
