US-8-60W Quick Start Guide
Package Contents
UniFi Switch
Power Adapter
System Requirements
Linux, Mac OS X, or Microsoft Windows 7/8/10
Java Runtime Environment 1.8 or above recommended
Web Browser: Google Chrome (Other browsers may have limited functionality)
UniFi Controller software v5.3.x (or newer), available at:
IMPORTANT:
prevent equipment damage due to stability issues with local AC power.
Hardware Overview
Front Panel
https://dl.ubnt.com/qsg/US-8-60W/US-8-60W_EN.html[3/6/2020 11:42:31 AM]
US-8-60W Quick Start Guide
Mounting Screws (Qty. 2)
Power Cord
We strongly recommend using UPS backup and power regulation to
Screw Anchors (Qty. 2)
ui.com/download/unifi
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ubiquiti UniFi Switch 8
Summary of Contents for Ubiquiti UniFi Switch 8
- Page 1 US-8-60W Quick Start Guide US-8-60W Quick Start Guide Package Contents UniFi Switch Mounting Screws (Qty. 2) Screw Anchors (Qty. 2) Power Adapter Power Cord System Requirements Linux, Mac OS X, or Microsoft Windows 7/8/10 Java Runtime Environment 1.8 or above recommended Web Browser: Google Chrome (Other browsers may have limited functionality) UniFi Controller software v5.3.x (or newer), available at: ui.com/download/unifi...
-
Page 2: Top Panel
US-8-60W Quick Start Guide System LED Click here for detailed descriptions. RJ45 (Ports 1 - 4) RJ45 ports support 10/100/1000 Ethernet connections. RJ45 (Ports 5 - 8) RJ45 ports support 10/100/1000 Ethernet connections and auto-sensing 802.3af PoE. Top Panel PoE LED (Ports 5 - 8) https://dl.ubnt.com/qsg/US-8-60W/US-8-60W_EN.html[3/6/2020 11:42:31 AM]... -
Page 3: Back Panel
US-8-60W Quick Start Guide PoE Off Amber PoE On (IEEE 802.3af) RJ45 Speed/Link/Act LED (Ports 1 - 8) No Link Link Established at 10/100 Mbps Amber Flashing Indicates Activity Link Established at 1 Gbps Green Flashing Indicates Activity Back Panel Ground Optional ancillary grounding point. -
Page 4: Wall Mounting (Optional)
US-8-60W Quick Start Guide Wall Mounting (Optional) https://dl.ubnt.com/qsg/US-8-60W/US-8-60W_EN.html[3/6/2020 11:42:31 AM]... - Page 5 US-8-60W Quick Start Guide https://dl.ubnt.com/qsg/US-8-60W/US-8-60W_EN.html[3/6/2020 11:42:31 AM]...
- Page 6 US-8-60W Quick Start Guide https://dl.ubnt.com/qsg/US-8-60W/US-8-60W_EN.html[3/6/2020 11:42:31 AM]...
- Page 7 US-8-60W Quick Start Guide Grounding (Recommended) The UniFi Switch is grounded through the Power Adapter; however, you can enhance ESD protection by connecting the ancillary ground. 1. Loosen the ground screw and secure a ground wire (not included) to the grounding point. https://dl.ubnt.com/qsg/US-8-60W/US-8-60W_EN.html[3/6/2020 11:42:31 AM]...
-
Page 8: Connecting Power
US-8-60W Quick Start Guide 2. Secure the other end of the ground wire to a grounding block or other grounded structure. Connecting Power https://dl.ubnt.com/qsg/US-8-60W/US-8-60W_EN.html[3/6/2020 11:42:31 AM]... -
Page 9: Connecting Ethernet
US-8-60W Quick Start Guide Connecting Ethernet Software Installation Download and install the latest version of the UniFi Controller software at ui.com/download/unifi and follow the on-screen instructions. Note: If you already have UniFi Controller v5.3.x or higher installed, go to the section, Adopting the UniFi Switch. - Page 10 US-8-60W Quick Start Guide You can manage your network and view network statistics using the UniFi Controller management interface. To adopt the UniFi Switch, proceed to the section, Adopting the UniFi Switch. For information on configuring and using the UniFi Controller software, refer to the User Guide on the website: ui.com/download/unifi Adopting the UniFi Switch...
-
Page 11: Specifications
US-8-60W Quick Start Guide 2. Locate the UniFi Switch in the list of devices under the Model column. Click Adopt. 3. The System LED on the UniFi Switch will turn blue to confirm that it has been successfully adopted. Specifications US-8-60W https://dl.ubnt.com/qsg/US-8-60W/US-8-60W_EN.html[3/6/2020 11:42:31 AM]... -
Page 12: Safety Notices
US-8-60W Quick Start Guide Dimensions 148 x 99.5 x 30.7 mm (5.83 x 3.92 x 1.21") Weight 432 g (15.24 oz) Networking Interfaces (8) 10/100/1000 Mbps RJ45 Ports PoE Interfaces (4) Ports 5, 6, 7, 8: IEEE 802.3af Power Method 48VDC, Max. -
Page 13: Electrical Safety Information
US-8-60W Quick Start Guide Electrical Safety Information 1. Compliance is required with respect to voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified may result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed. 2. -
Page 14: Declaration Of Conformity
CE Marking CE marking on this product represents the product is in compliance with all directives that are applicable to it. WEEE Compliance Statement Declaration of Conformity Online Resources © 2020 Ubiquiti Inc. All rights reserved. https://dl.ubnt.com/qsg/US-8-60W/US-8-60W_EN.html[3/6/2020 11:42:31 AM]...
