Serial I/O Adapter
2
Installation & Setup
Adapter
Installation

PCI System Setup

Software
Installation
Serial I/O SST 128P Adapter Installation & Setup
The Adapter appears to the system host processor as memory. That is,
it is a memory mapped device. All SST Adapters are automatically
mapped into system memory at the time the device driver is installed.
The device driver soft-configures all adapters each time the system is
initialized (booted).
Note:
Please refer to the user manual that came with your personal
computer for detailed installation instructions.
Use the following procedure to install your Serial I/O Adapter:
1.
Set the host computer system power switch to OFF and
disconnect the power cord.
2.
Locate a free PCI expansion slot.
3.
Insert and secure the board firmly into the expansion slot.
4. Replace the power cord and turn the host computer system ON.
5.
Follow the information detailed in chapters 3, 4 and 5 to
complete your installation.
Peripheral Component Interconnect (PCI) system architecture has a
design feature termed Plug and Play. This feature automatically
detects, identifies and configures the currently installed devices each
time the system is booted. Therefore, whenever an Adapter is
installed (or removed) in a PCI system, the card is recognized and
configured immediately upon restart.
Refer to the Quick Start Card that came with the CD ROM for
detailed instructions on loading the Software.
2-1
