End Glass - Hot Food Unit - Duke SUBWAY Series Service Manual

Service Manual for Subway Front Counters
Top Glass Holder Removed
3. Remove top Glass Holder.
4. Reverse this procedure to install a replacement
End Glass.
End Glass – Hot Food Unit
WARNING:
THE POWER MUST BE TURNED OFF
AND DISCONNECTED AT ALL TIMES
DURING MAINTENANCE OR REPAIR
FUNCTIONS.
Hot Food Unit End Glass
1. Unpack and inspect the End Glass Kit.
2. Ensure that the Thermostat is in OFF position
and disconnect unit from its power source.
22
3. Remove and discard old glass, gaskets and
3. Line up the holes in the Extrusion with the
Hot Food
End Glass
4. Place the Large Gasket onto the lower
extrusion.
Line up with
holes in unit
Proper Placement of Extrusion.
holes in the outside end of the Hot Food unit
and screw extrusion into position.
Gaskets
Properly placed Gaskets
unprotected edge of the glass and the Small
Gasket on other unprotected edge of the
glass.
Extrusion
