23. Center and attach the Light Assembly onto the
Purse Rail ensuring that the front edge of the
Light Shield covers the laminate by ¼".
NOTICE: For 220 Volt Light Fixtures, reattach the
power cord, cord grommet and light clip.
24. Remove excess silicone from the top of the
Purse Rail with a putty knife.
25. Reinstall the Décor Panel.
26. Plug in the light cord and test for proper
operation.
Service Manual for Subway Front Counters

DAYCOVER

Daycover Bulb Gasket

WARNING:
THE POWER MUST BE TURNED OFF
AND DISCONNECTED AT ALL TIMES
DURING MAINTENANCE OR REPAIR
FUNCTIONS.
Location of Daycover Gasket
The Daycover Gasket is located on the operator's
side of the Daycover and provides a seal when
the Daycover is in the closed position.
1. Remove all food products from the unit.
2. Start at the center of the Door and peel the
old Bulb Gasket out of the channel by rolling
it towards the center of the door.
3. Once it is loose, work around the perimeter of
the Door, pulling the Bulb Gasket out of the
channel.
NOTICE: Do not stretch the Bulb Gasket while
pressing it into place.
4. To install the new Bulb Gasket, start at the
corner, press the dart side of the Bulb Gasket
into the channel.
5. Continue along the perimeter of the Door.
19
