GEONAUTE ONmove 120 GPS User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN
ONmove 120 GPS

TABLE OF CONTENTS

1
SETTINGS ...................................................................................................3
1.1
Intuitive guide ...................................................................................................................................... 3
1.8
About .................................................................................................................................................. 10
2
USE ...........................................................................................................11
2.1
Charging ............................................................................................................................................ 11
....................................................................................................................................... 11
3
LOGBOOK .................................................................................................15
4
MESSAGES ...............................................................................................16
....................................................................................................................................... 17
........................................................................................................................................ 17
5
CHARGING THE BATTERY .......................................................................18
6
7
TECHNICAL CHARACTERISTICS .............................................................19
8
CONTACT US ............................................................................................19
9
PRECAUTIONS FOR USE ..........................................................................19
10 LEGAL NOTICES .......................................................................................19
........................................................................................................................................... 19
................................................................................................... 3
................................................................................................................... 4
.................................................................................................................................. 5
.................................................................................................................................. 7
...................................................................................................................... 8
............................................................................................................................. 9
......................................................................................................................... 11
........................................................................................................ 14
............................................................................................................................... 15
............................................................................................................................. 15
......................................................................................................................... 16
................................................................................................................................... 16
.................................................................................................................................. 16
........................................................................................................... 19
1

Advertisement

Table of Contents
loading

Related Manuals for GEONAUTE ONmove 120 GPS

Summary of Contents for GEONAUTE ONmove 120 GPS

  • Page 1: Table Of Contents

    ONmove 120 GPS TABLE OF CONTENTS SETTINGS ....................3 Intuitive guide ............................3 ....................3 ........................4 ..........................5 ..........................7 ........................8 ..........................9 About ..............................10 USE ......................11 Charging ............................11 ............................11 ......................... 11 ......................14 LOGBOOK ....................15 ..........................
  • Page 2 USB cable to: - Recharge the battery, - Transfer your activities to decathloncoach.com Validation / Switch on / Switch off...

  • Page 3: Settings

    SETTINGS 1.1 Intuitive guide For every setting, use the C and D buttons to adjust the values The settings marked allow fast scrolling through the values when pressing and holding the E button Certain settings or displays cause a beep represented by the icon.
  • Page 4 This menu gives you access to the different settings of your ONmove 120: - General settings. - User settings. - Target zones. - Screen customisation. In watch mode, press E to access the main menu. Browse the menus using the C ( ) and D ( ) keys until you reach the "Settings" mode. Press E once again to enter the "Settings"...
  • Page 5 Note 1.4.1 1.4.2 D x1 1.4.3 Setting the date D x2 ( ) ( ) ( ) ( ) ( ) ( )
  • Page 6 Note: This setting does not concern the alarm sound. If it is set to "OFF", the alarm sound will remain active. D x3 D x4 1.4.6 Setting the language D x5...
  • Page 7 The user's personal parameters are also synchronised automatically when you log on to your myGeonaute account (see § 6). Weight: min : 20kg/44lb max : 220 kg/485 lb Default value: 70 kg/154 lb Height: min : 100cm/39inch max : 220cm/86inch Default value: 175 cm/69 inch...
  • Page 8 Setting a target zone helps you manage your effort by helping you stay within a determined effort zone. There is a beep every time you exit a zone. 2 types of target zone are available: speed, pace. When a target zone is activated, a 3 screen showing a graphic indication of your target zone is available during the activity.
  • Page 9 Note: At least one value must be selected on the 3 screens. The size of the message adapts to the number of values selected. The display is therefore larger when a single value is selected per screen. Example: Screen 1: Stopwatch + Distance, Screen 2: Speed + Pace, Screen 3: Calories.

  • Page 10: About

    1.8 About Serial 1.8.1 The FastFix system enables your ONmove 120 to predict the trajectory of the satellites for 7 days. Therefore your ONmove 120 knows the exact location of these satellites even before the search is launched. You can detect a signal within 30 seconds even if the signal is weak or if the area is partially covered.

  • Page 11: Use

    2.1 Charging charging time is approximately 1 1/2 hours. A full charge will give you a 7 hour life span in GPS mode and 10 days in clock mode. The ONmove 120 can be charged simply by connecting it to a USB port on your computer or a 5 V-1A.
  • Page 12 50 s. Flashing while activity has not started Once the GPS signal has been detected, your ONmove 120 automatically switches to "Free" mode. Note: This screen is only available and activated. (see § 1.5) Press E to start the activity; a beep can be heard. During the activity, press C or D parameters (see §...
  • Page 13 2.3.2 This action allows the user to: Save the activity Quit the activity Access the product settings Resuming the activity 3 s.
  • Page 14 2.3.3 2.4 Switching off the ONmove 120 off your ONmove 120 at any time. Press E (1 second) (1 s.) 1 s.

  • Page 15: Logbook

    LOGBOOK Activity time Average speed Calories burned % of time spent within the and distance and average target zone pace settings) If no session has been saved Auto 3 s. After deleting a session, the display will return to the last session saved. Press A to return to the logbook menu.

  • Page 16: Messages

    Auto 3 s. Recording time still available (hours and minutes) MESSAGES When the GPS connection is lost, a 30-second search starts automatically. If, after 30 seconds, the connection is not restored, the screen displays < - - - > instead of the "Speed"...
  • Page 17 There are 3 alert levels: When the battery is at 10%, 2 beeps can be heard. When the battery is at 5%, 3 beeps can be heard. the product switches off when the battery is completely discharged. If an activity is underway, it is automatically saved in the logbook before the ONmove 120 switches off Recharge the battery (see §...

  • Page 18: Charging The Battery

    "DECATHLON COACH" Connect your ONmove 120 to your computer and go to the following website: start.geonaute.com Download and install the ONconnect software in accordance with the instructions. Launch the ONconnect software then create your account or log on if you already have one.

  • Page 19: Technical Characteristics

    7 hours in GPS mode Range 10 days in watch mode 1.5 hours CONTACT US We would like your feedback on the quality, functionality and use of our products: support.geonaute.com We will reply as soon as possible. PRECAUTIONS FOR USE -10°C 60°C -50°F 140°F...
