CommBox Interactive Classic User Manual

Hide thumbs Also See for Interactive Classic:
Table of Contents

Advertisement

Quick Links

CommBox Interactive
Classic User Manual
Date: 15-Mar-2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Interactive Classic and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CommBox Interactive Classic

Summary of Contents for CommBox Interactive Classic

  • Page 1 CommBox Interactive Classic User Manual Date: 15-Mar-2016...

  • Page 2: Table Of Contents

    Table of Contents Preparations Parts List Control product 1.2.1 • You can control thetouchscreen by using the control buttons on the right side of the frame. Remote Sensor / Power indicator - 1.2.2 Control buttons – Input/output connection 1.3.1 Connector name and description 1.3.2 USB Multi media playback format Remote Controller Button Description...

  • Page 3: Preparations

    1 Preparations 1.1 Parts List If these items are missing, contact your dealer or service center: Power Cable (Option) Remote Controller HDMI Cable AAA 1.5V Battery x 2 Touch USB Cable & Extension cable 1.2 Control product 1.2.1 • You can control thetouchscreen by using the control buttons on the right side of the frame.

  • Page 4: Control Buttons

    1.2.2 Control buttons – When a menu is visible on-screen, this button operates identically to the up- arrow. Down When a menu is visible on-screen, this button operates identically to the down- arrow. Vol- Press this button to decrease the volume. When a menu is visible on-screen, this button operates identically to the left-arrow button.

  • Page 5: Input/Output Connection

    1.3 Input/output connection 1.3.1 Connector name and description Connector Description Earphone To connect audio output SPDIF To connect SPDIF Composite To connect composite for DVD etc. Audio In To connect audio input (3.5) VGA In To connect VGA video input Component To connect component for DVD etc.

  • Page 6: Usb Multi Media Playback Format

    HDMI 2 In To connect HDMI 1.4 video & audio input - 2 HDMI 1 In To connect HDMI 1.4 video & audio input – 1 USB In To connect with USB device Audio Out To connect audio output Touch In To connect Touch RS-232C In To connect RS232 input cable with control device (D-sub 9pin)
  • Page 7 Power on/off button POWER Select input signal SOURCE ASPECT Adjust the window's ratio Move to the upper menu Move to the lower menu Move to the left menu Move to the right menu Select to change menu MENU Display or hide menu on the screen Volume up Volume down +61 2 9975 6001...

  • Page 8: Setup

    2 Setup 2.1 Remote Control Setup 2.1.1 Inserting batteries into the remote • Press the tab on the battery case and open it. • Insert the battery (1.5V AAA) into the battery case. • Replace the battery case and push it down until clack sounds. 2.1.2 NOTICE: •...

  • Page 9: Cleaning

    2.3 Cleaning After disconnecting the power cable, clean the product screen lightly with a dry and soft cloth. Do not clean the product with a wet cloth or spray. If washed with any cleaning agent including brighteners, abrasives, waxes, benzene, alcohol, solvent or surface active agent, the surface of the product may be damaged.

  • Page 10: Connect To A Pc Or Laptop

    3 Connect to a PC or Laptop 3.1 HDMI Connection HDMI input is recommended because it receives a digital signal input from an external device with HDMI output to ensure high quality of digital signal. Use the cable provided with the product. Otherwise, no image may be shown on the screen or normal display may not be shown.
  • Page 11 +61 2 9975 6001...

  • Page 12: Menu Control

    4 Menu Control 4.1 Input selection 1. To select a source, first press the top right Source button on your remote. This will bring up the Input Menu (pictured right). 2. Use the Up and Down arrows in the centre of the remote to move up and down to highlight your source.

  • Page 13: User Function

    4.2 User function Upper Lower- Lower-2 Value Note Video Picture Picture mode Dynamic,Theater (Default: Dynamic) Personal,Standard Contrast 0-100 (Default: 60) Brightness 0-100 (Default: 50) Sharpness 0-100 (Default: 50) Tint 0-100 (Default: 50) Color 0-100 (Default: 50) Color Normal,Warm,Cool (Default: Normal) Temperature Cinema,Zoom Zoom Mode...
  • Page 14 MEMC On,Off (Default: Off) Audio Audio Equalizer Standard,Music,Movie, Sport, (Default: Standard) Personal 120Hz 500Hz 1.5KHz 5KHz 10KHz Audio English, Spanish, French Language Digital Output Surround On,Off (Default: Off) Sound Audio Only On,Off (Default: Off) On,Off (Default: Off) Balance 0-100 (Default: 50) Speaker out On,Off (Default: On)
  • Page 15 Upper Lower-1 Lower-2 Value Note Setup Setup Menu Language English,Spanish,French (Default: English) Transparent 0-100 (Default: 25) OSD Time Out 15-60sec (Default: 15sec) Restore Default Software Update (USB) Blue screen On,Off (Default: Off) No Signal Off On,Off (Default: Off) Lock Lock +61 2 9975 6001...

  • Page 16: Trouble Shooting

    5 Trouble Shooting Touch Issues Issue Check Action No Touch USB cable Install USB lead between device and Touch USB connection on touchscreen Laptop Try alternative USB connections on laptop socket USB cable Recommended length for USB is 5m. If laptop is further away, length then a USB powered extender is required Reflected...
  • Page 17 VGA or cable – 3.5 DVI-D mm M to M No sound Volume level Increase the volume level on both the CommBox on internal Touchscreen, Media Player and Device e.g laptop or PC speaker Audio Board Replace the Audio board...
  • Page 18 Check Action Batteries Replace batteries in the remote. remote Remote If possible test remote on a different Commbox Touchscreen Control Touchscreens Check that the control buttons on the bottom right side of the Buttons Commbox Touchscreen are working +61 2 9975 6001...

  • Page 19: Supported Resolutions

    6 Supported Resolutions Signal Types Supported Video Timings Note 640 x 480 @ 60Hz 800 x 600 @ 60Hz 1024 x 768 @ 60Hz D-SUB 1280 x 768 @ 60Hz 1360 x 768 @ 60Hz 1280 x 1024 @ 60Hz 1920 x 1080 @ 60Hz Component &...
