- Page 1 CommBox Interactive Table User Manual 1.0 Revision: 5...
-
Page 2: Table Of Contents
Table of Contents Introduction Table Assembly Components Accessories Table Assembly Procedure Step 1 Step 2 Step 3a (for S-Series) Step 3b (for T-Series) Step 4 (T-Series Only) Computer Installation Using the Computer Tray Cabling and Cable Management... -
Page 3: Introduction
1 Introduction This assembly manual outlines the procedure to assemble the CommBox Interactive Table Range. Models include 32S, 42S, 46S, 32T, 42T and 46T. 1.1 Table Assembly Components Assembled Table Body with Screen and White Cover 4 Legs (2 with CommBox logo) -
Page 4: Step
2 Table Assembly Procedure 2.1 Step 1 Unpack the Table body and lay flat on a protective surface to avoid damage to the screen and cover. Tip: We suggest that you lay the box on its side and slide the table out. +61 2 9975 6001... - Page 5 2.2 Step 2 From the accessories Kit, locate the 4 steel corner blocks. Note: Blocks are shown in red for illustrative purposes only. Place the blocks flat over the corner section of the frame inside the light strip. +61 2 9975 6001...
-
Page 6: Step 3A (For S-Series)
2.3 Step 3a (for S-Series) Position the 4 legs above the corner blocks and tighten bolts ( M6 x 37mm ) noting the orientation of the washers. The assembly of your S-Series table is now complete. Safely stand the table on the legs and remove the protective film on top. -
Page 7: Step 3B (For T-Series)
2.4 Step 3b (for T-Series) Position the 4 legs above the corner blocks. Tighten bolts to about 70% tension ( M6 x 37mm ) noting the orientation of the washers. You will notice that your T-Series table has 900mm legs with a centre welded support block for beam connection. -
Page 8: Step 4 (T-Series Only)
2.5 Step 4 (T-Series Only) Guide the beam into position while adjusting the leg to avoid any damage to the surface. Ensure that the beam holes line up with the leg block holes and the dressed side of the beam if facing the top of the table. Tighten the beam bolts ( M4 x 26mm ) noting the orientation of the bolt head and washers. -
Page 9: Computer Installation
3 Computer Installation 3.1 Using the Computer Tray The table is designed to fit a compact computer, such as an Intel Nuc. Using the provided key, open the door below the table. On the door, there is a computer tray. Remove the tray by removing the six screws. The tray is full of holes that serve both for cooling, and as mounting holes. -
Page 10: Cabling And Cable Management
3.2 Cabling and Cable Management The table ships with CommBox branded velcro cable ties. There are plenty of cable management points inside the table to keep things tidy. They are positioned around the edges inside and along the supporting beams that the touchscreen rests on. - Page 11 Notes...
- Page 12 CommBox Pty Ltd PO Box 6667, Frenchs Forest NSW 2086, p: +61 2 9975 6001 | e: office@commbox.com.au...
