- Page 1 USER MANUAL 4K Interactive Flat Panel Display SPACEHUB55 Rev.30/May/2017...
- Page 2 NOTICES COPYRIGHT AND TRADEMARKS Copyright © 2016 CommBox Corporation. All rights reserved. All brand names and product names are trademarks, registered trademarks or trade names of their respective holders. General Every effort has been made to ensure accuracy, however in some cases changes in the products or availability could occur which may not be reflected in this document.
-
Page 3: Table Of Contents
Table of Contents BEFORE USING THE PRODUCT ............. 4 Safety Precautions ................4 PREPARATIONS ................. 11 Parts List ................... 11 Control product ................12 Input/output connection ..............13 Remote Controller Button Description ..........14 INSTALLATION GUIDE................ 15 Caution before installation ..............15 Unpacking Process ................ -
Page 4: Before Using The Product
BEFORE USING THE PRODUCT Before installing or using the product, to avoid damaging the product, read and follow as the guidelines of the user manual for your safety. The color, design and specification may change without notice to enhance the function. ... - Page 5 Do not use the power cable near heating appliances and products. - This may cause a fire or electric shock. In case of contamination around the power plug or outlet, wipe clean with a dry cloth. - This may cause a fire. Do not place flammable objects near the product.
- Page 6 Do not install in the low place where a child can touch. - A child may be injured while playing and touching the product. Do not install near any kitchen or kitchen counter because it may cause damage or deformation of the product by the vapor or oil. - This may cause a fire.
- Page 7 Do not drop the product or throw something to the product. - This may cause a fire or electric shock. Do not give a shock or scratch to the screen with sharp objects. - This may cause damage to the product. Do not pull the power cable or signal cables connected to the product when moving the product.
- Page 8 Caution Do not unplug the power cable while using the product. - This may cause a fire or electric shock. Use only the power cable qualified for the standard. - This may cause a fire or electric shock. Connect the power cable to the nearest outlet. - If having a problem with the product, unplug the power cable completely.
- Page 9 Turing on the product in the condition of the fixed screen or 4:3 screen for a long time may also cause an afterimage or stain on the screen. - When using the product for a long time, set a screen saver of the connected computer or signaling equipment products or set it in sleep mode.
- Page 10 Do not place heavy objects on the product. - This may result in a malfunction or an injury. Please put obstacles away from the space between the remote controller and the product. - The product may not be operated by remote controller. The remote control may not be good in this operation under the sun or strong light.
-
Page 11: Preparations
PREPARATIONS Parts List If these items are missing, contact your dealer or service center. The following images may differ from the image shown. Other parts not packed in contents may cause performance degradation or problem during usage. HDMI Cable Power Cable Remote AAA 1.5V (Option) -
Page 12: Control Product
Control product The following images may differ from the image shown. You can control the product by using the control buttons on the rear side of the product. • ① ② *Note : sound bar is an optional item. - side ① Remote Sensor / Power indicator Power on Green... -
Page 13: Input/Output Connection
Input/output connection The items may differ from the image shown. ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑭ ⑬ ⑫ ⑪ ⑩ Connector name and description Connector Description ① Speaker Out To connect External Speaker Touch USB To connect Touch USB ②... -
Page 14: Remote Controller Button Description
Remote Controller Button Description Button Description images may differ from the actual items. The following Button not described does not work. POWER Power on/off button SOURCE Select input signal ASPECT Adjust the window’s ratio ▲ Move to the upper menu ▼... -
Page 15: Installation Guide
INSTALLATION GUIDE Caution before installation Caution Installation must be performed by a qualified custom video installation specialist under the conditional installation environment as below. Ambient Lighting When the sun or strong light shines on the front screen of the product, image contrast can •... -
Page 16: Unpacking Process
Unpacking Process The following mages may differ from the actual items. Before unpacking the box, refer to the diagram below. Remove the outer packing box. Remove the top foam. Lower down or remove the wrapping. Three or more people, remove the packing from the product. -
Page 17: Handling Guide
Handling Guide The following mages may differ from the actual items. Holding a product 1. Right way At least two persons are required to handle the product during transportation. Two persons should hold the each left and right hand grips of the backside of the product with one hand of the each person and with the other hand, grip the bottom portion of the rear side of the product to move. - Page 18 Putting a product 1. Right Way Before putting the product on the floor, prepare flat and soft cushions. Place the product horizontally and slowly on the floor. If firstly laying the edge of the bezel of the product, the screen panel of the product may be fragile or damaged. Cushions 2.
-
Page 19: Product Installation
Product Installation When installing the product with wall mount, make the product installed by a well-trained technician. Please refer to the User Guide of Wall Mounting. The product has VESA standard of 400X400 MM for wall mounting, and of M8 (Maximum length 35mm) of the screws by size. -
Page 20: Remote Controller
Remote Controller Inserting batteries in the remote controller Press the tab on the battery case and open it. • • Insert the battery (1.5V AAA) into the battery case. • Insert the battery case until clack sounds. Notice on battery When loading the battery, check if the polarity of the batteries is correct. -
Page 21: Remote Control
REMOTE CONTROL RS-232C connection Physical Connector Connector on the display: DB9 Male, configured as DTE Male (4) Type(Version) ※ Please check the RS-232pinout type in your serial number. Communication Parameter Baud Rate 9600 Data Length 8 bit Parity Bit None Stop Bit 1 bit Hardware Handshake... -
Page 22: Hdmi Connection
CONNET THE EXTRAL DEVICES HDMI Connection HDMI input is recommended because it receives a digital signal input from an external • device with HDMI output to ensure high quality of digital signal. , no image may be shown on the screen or * Use the cable provided with the product. -
Page 24: Touch Requirements
Touch Requirements 6. 1 Touch Requirements OS Compatibility Version Interfaces Windows Windows 10(not support OEM version OS.) Windows 8(not support OEM version OS.) Windows 7 Windows Vista, XP/2000 USB/RS232 Windows CE.net/5.0/6.0/7.0 Windows Embedded Windows XP Tablet PC edition Linux The Linux public driver supports most of the Linux distribution, including Ubuntu, Debian, SuSE(openSuSE), Fedora Core, Mandriva, Slackware and so on. - Page 25 USB/RS232 Type Controller Circuit Board Dimension 325mm x 100mm Channels of Panel Max. Tx:108 Rx:192 channels (include shielding pin) Input Voltage 3.5V~5.5V.Typical 5V. Operating Temperature -40 to 85 ℃ Storage Temperature -40 to 85 ℃ Relative Humidity 95% at 60 ℃, RH Non-condensing Interface 1.1 Full Speed, RS232: No parity,8 data bits,1 stop bit, baud rate 19200bps Resolution...
-
Page 26: Menu Control
MENU CONTROL Input selection Press the Input button and then select ▲ or ▼, or the input you want to select, and then press the ▶ (+) button. Input Description Component Component input HDMI1 HDMI1 input HDMI2 HDMI2 input HDMI3 HDMI3 input HDMI4 HDMI4 input... -
Page 27: User Function
User function Upper Lower Value Note Picture mode Standard, Dynamic, Soft, User (Default: Standard) Color Mode Normal, Warm, Cool, User (Default: Normal) Screen size Just Scan Normal, wide, cinema, zoom VIDEO Noise Reduction Medium, High, Off, Low (Default: Medium) Dynamic Contrast Medium, High, Off, Low (Default: Medium) MEMC... -
Page 28: Trouble Shooting
TROBLE SHOOTING The table below provides some general guidelines for trouble shooting problems you may encounter with your product. If the suggested solutions fail to resolve the problem or if you encounter an issue not described here, please contact your dealer or service centre. Symptom Checklist &... - Page 29 • Install into the “Sound” socket or check the Audio setting in the computer No Sound on internal speaker • Increase the volume level on both the CommBox interactive display, Media Player and Device e.g. laptop or PC No Sound on External Speakers •...
- Page 30 • Check for any shorts on the wires connecting to the speakers. •Power down the touchscreen, remove any external speaker connection, wait for 30seconds, reapply power and test internal speakers only. UD@60Hz is not displayed. • Connect directly from HDMI 2.0 of PC to HDMI port of the screen.
-
Page 31: Product Specification
PRODUCT SPECIFICATION Product specifica�ons are subject to change without no�ce. Model SPACEHUB55 Size (WxHxD) 1243 x 717 x 76.5mm Weight 50Kg Display size (WxHxD) 55ʺ Resolu�on 3840 x 2160 Brightness 350cd/m2 Response �me Viewing angle Horizontal/ver�cal 178'/178' Touch 20point as standard... - Page 32 HDMI &USB extension cables, Power cable, Remote controller, Cable Quick guide, Passive pen Passive pen, Active pens Options Sound bar-Harman kardon, JBL Wall mount bracket, Motorized moveable stand ※ Product design and specification can be changed for quality improvement without prior notice.
-
Page 33: Supported Resolutions
SUPPORTED RESOLUTIONS Video system PAL/NTSC CVBS Video Level 1.0Vp-p±5% Video Input Component 480i, 480p, 576i, 576p, 720p, 1080i, 1080p HDMI 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 4K 30Hz, 4K 60Hz CVBS & Audio component L/R RCA input 0.2 ~ 2.0 V RMS Input Audio... -
Page 34: Required Information
REQURIED INFORMATION 11.1 Prevent image sticking The fixed image (title, menu image, picture, motionless movie etc.) on the screen is maintained for a long time, image sticking may occur. Image sticking may be subject to operating time of still picture. Since the image sticking is not defect but a characteristic of the product, it is restricted from the product warranty.
