OWNER'S OPERATING AND MAINTENANCE MANUAL
MANUEL DE L'UTILISATEUR ENTRETIEN ET
FONCTIONNEMENT
MANUAL DE INSTRUCCIONES Y MANTENIMIENTO
STAND UP LIFT - MODEL RPS350-1
LÈVE-PATIENT - MODÈLE RPS350-1
LEVANTADOR – MODELO RPS350-1
DEALER: THIS MANUAL MUST BE GIVEN TO THE USER OF
THE PATIENT LIFT.
USER: BEFORE USING THIS PATIENT LIFT, READ THIS
MANUAL AND SAVE FOR FUTURE REFERENCE.

Advertisement

Table of Contents
loading

Related Manuals for Invacare RPS350-1

Summary of Contents for Invacare RPS350-1

  • Page 1 OWNER'S OPERATING AND MAINTENANCE MANUAL MANUEL DE L’UTILISATEUR ENTRETIEN ET FONCTIONNEMENT MANUAL DE INSTRUCCIONES Y MANTENIMIENTO STAND UP LIFT - MODEL RPS350-1 LÈVE-PATIENT - MODÈLE RPS350-1 LEVANTADOR – MODELO RPS350-1 DEALER: THIS MANUAL MUST BE GIVEN TO THE USER OF THE PATIENT LIFT.

  • Page 2: Special Notes

    SPECIAL NOTES SPECIAL NOTES WARNING DO NOT OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND UNDERSTANDING THE WARNINGS, CAUTIONS AND INSTRUCTIONS IN THIS MANUAL AND THE OWNER’S MANUAL PROVIDED WITH THE SLINGS. IF YOU ARE UNABLE TO UNDERSTAND THE WARNINGS, CAUTIONS, AND INSTRUCTIONS, CONTACT A HEALTHCARE PROFESSIONAL, DEALER OR TECHNICAL PERSONNEL IF APPLICABLE BEFORE ATTEMPTING TO USE THIS EQUIPMENT - OTHERWISE INJURY OR DAMAGE MAY RESULT.

  • Page 3: Table Of Contents

    REPLACING THE KNEE PAD ......................18 REPLACING OPTIONAL LEG STRAP ....................18 REPLACING THE PADDED COVER ....................18 REPLACING ELECTRIC ACTUATOR ....................18 REPLACING CASTERS AND/OR FORKS ..................19 LIMITED WARRANTY ....................20 LÈVE-PATIENT - MODÈLE RPS350-1 ....21 LEVANTADOR - MODELO RPS350-1 .....40...

  • Page 4: Safety Summary

    Invacare Stand Up Lift. Slings and accessories designed by other manufacturers or other Invacare slings are not to be utilized as a component of Invacare’s stand up lift system. Use of these products is prohibited and will void Invacare’s stand up lift warranty. Use only genuine Invacare standing and transport slings and lift accessories to maintain patient safety and product utility.
  • Page 5 National Electrical Code. If you must use an extension cord, use ONLY a three-wire extension cord having the same or higher electrical rating as the device being connected. In addition, Invacare has placed RED/ORANGE WARNING TAGS on some equipment. DO NOT remove these tags. Carefully read battery/battery charger information prior to operating, charging or servicing your stand up lift.

  • Page 6: Specifications

    SPECIFICATIONS/ASSEMBLY 2. Remove the hex bolt, nut and washer, that are located SPECIFICATIONS in the U-shape cut-out of the base. Stand Up Lift 3. Position the mast in an upright position and place the mast onto the U-shaped cut-out of the base. Height at Sling Hook-up Knob MAXIMUM: 66-inches...

  • Page 7: Operation

    OPERATION OPERATION OPERATING THE STAND UP LIFT OPENING. 1. Pull the shifter handle OUT and away from the Closing/Opening the Legs of the Base stand up lift and then to your RIGHT until it LOCKS in (FIGURE 1) the notch of the bracket. NOTE: Right is determined by standing behind the The shifter handle is used to open or close the legs of the stand up lift facing towards the front casters.

  • Page 8: Mounting Battery Charger

    FIGURE 3 - RAISING/LOWERING STAND UP LIFT CHARGING BATTERIES (FIGURE 5) MOUNTING BATTERY CHARGER NOTE: Invacare recommends the battery be recharged (FIGURE 4) daily. NOTE: An audible alarm will sound (horn will beep) when NOTE: Refer to your local regulations concerning battery is low.
  • Page 9 OPERATION NOTE: The charge LED will illuminate.When charging is complete, the charge LED will stop illuminating. NOTE: A battery needing to be fully recharged will take approximately four (4) hours. 4. Lift UP on the handle on the top of the battery. 5.

  • Page 10: Transferring From

    B. Lean back into the standing or transport sling. of Invacare’s stand up lift system. Use of these WARNING products is prohibited and will void Invacare’s STANDING SLINGS - Before lifting the patient, make stand up lift warranty.

  • Page 11: Moving The Patient

    TRANSFERRING FROM STEP 1A MOVING THE PATIENT (FIGURE 2) STEP 1B WARNING STANDING SLINGS - DO NOT use the standing sling in combination with the stand up lift as a transport device. It is intended to transfer an individual from one resting surface to another (such as a bed to a wheelchair).

  • Page 12: Transferring To

    However, since medical con- ditions vary, Invacare recommends that the healthcare professional evaluate the need for assistance and deter- mine whether more than one (1) assistant is appropriate in each case to safely perform the transfer.

  • Page 13: Transferring The Patient To A Bed

    ê 2. Press the DOWN ( ) button and lower the pa- tient onto the bed. WARNING Invacare recommends locking the rear swivel casters ONLY when positioning or removing the sling (standing or transport) STEP 4 from around the patient.

  • Page 14: Transferring The Patient To A Commode

    2. Press the DOWN ( ) button and lower the patient onto the commode. WARNING Invacare recommends locking the rear swivel casters ONLY when positioning or removing the sling (standing or transport) from around the patient. 3. Lock the rear swivel casters. Refer to LOCKING/ UNLOCKING THE REAR SWIVEL CASTERS in the OPERATION section of this manual.

  • Page 15: Maintenance Safety Inspection Checklist

    MAINTENANCE SAFETY INSPECTION CHECKLIST MAINTENANCE SAFETY INSPECTION CHECKLIST ITEM INITIALLY INSTITUTIONAL IN-HOME INSPECT INSPECT/ADJUST EVERY SIX (6) MONTHLY MONTHS THE CASTER BASE l Inspect for missing hardware. l Base opens/closes with ease. l Inspect casters and axle bolts for tightness and wear. l Inspect casters for smooth swivel and roll.

  • Page 16: Care And Maintenance Of Your Stand Up Lift

    NOTE: If problems are not remedied by the suggested means, please contact your Dealer or Invacare. CARE AND MAINTENANCE OF YOUR STAND UP LIFT NOTE: Follow the maintenance procedures described in If you question the safety of any part of the lift, contact your this manual to keep your stand up lift in continuous service.

  • Page 17: Wear And Damage

    CARE AND MAINTENANCE OF YOUR STAND UP LIFT The casters MUST swivel and roll smoothly. A light grease Linkage Rods Square (waterproof auto lubricant) may be applied to the ball bearing swivel of the casters once a year. Apply more frequently if the casters are exposed to extreme moist con- ditions.

  • Page 18: Replacing The Knee Pad

    CARE AND MAINTENANCE OF YOUR STAND UP LIFT REPLACING THE KNEE PAD 5. Position the mounting holes in the knee pad with the mounting holes in the stand up lift. (FIGURE 4) 6. Using the existing hardware, secure the knee pad and 1.

  • Page 19: Replacing Casters And/Or Forks

    CARE AND MAINTENANCE OF YOUR STAND UP LIFT Lift Arm Mounting Bracket REAR Base Locknut Fork Top Nut Bracket Bolt Base Bolt Bushing Rear Fork Caster Electric Bushing Actuator Locknut Shoulder Bolt Washer Bottom Nut Bolt Front Washer FRONT Casters Mast Mounting Bracket FIGURE 8 - REPLACING CASTERS AND/OR FORKS FIGURE 7 - REPLACING ELECTRIC ACTUATOR...

  • Page 20: Limited Warranty

    For warranty service, please contact the dealer from whom you purchased your In- vacare product. In the event you do not receive satisfactory warranty service, please write directly to Invacare at the address on the back cover, provide dealer’s name, address, and the date of purchase, indicate nature of the defect.

  • Page 21: Lève-Patient - Modèle Rps350-1

    Invacare Corporation Canada...
