ENGINEERING COMPANY, INC
Route 145, Winthrop Road
Chester, CT 06412-0684
TELEPHONE: (860) 526-9504
TOLL FREE: 1-800-637-4736
BASE GASKET
© 1996 Whelen Engineering Company, Inc. Doc No. 04-0113078-01
February 8, 1996.
13078
DOME
CLAMP RING
STROBE TUBE ASSEMBLY
POWER SUPPLY ASSEMBLY
BASE
Doc No. 04-0113078-01
ISB SERIES
STROBE LIGHT BEACONS
ISB24, 12/24 VOLTS DC, COMET FLASH
ISB120, 120 VOLTS AC, COMET FLASH
SEE OTHER SIDE
OF PAGE FOR
REPLACEMENT
PARTS LISTING.
WARNING...
DISCONNECT THE
POWER SOURCE AND
WAIT 10 MINUTES
BEFORE INSTALLING
OR SERVICING THE
STROBE LIGHT.
REPLACEMENT PARTS
LISTING FOR ISB
SERIES STROBES
