STOP NUT
© 1996 Whelen Engineering Company, Inc. Doc No. 04-0113085-01
May 24, 1996
.
13085B
DOME
CLAMP RING
#6-32 SCREW
STROBE TUBE ASSEMBLY
PCB ASSEMBLY
O RING SEAL
BASE
Doc No. 04-0113085-01
IS1 SERIES
STROBE BEACONS
IS1224P, 12-48 VDC, PIPE MOUNT
IS1120P, 120 VAC, PIPE MOUNT
IS1224S, 12-48 VDC, SURFACE MOUNT
IS1120S, 120 VAC, SURFACE MOUNT
IS124CP, 12-48 VDC, CAST, PIPE MOUNT
SEE OTHER SIDE OF PAGE FOR
REPLACEMENT PARTS LISTING.
WARNING ALWAYS
DISCONNECT POWER
BEFORE SERVICING OR
INSTALLING AN IS1
SERIES BEACON.
MICRO SIZE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whelen Engineering Company IS1 Series
Summary of Contents for Whelen Engineering Company IS1 Series
- Page 1 SEE OTHER SIDE OF PAGE FOR REPLACEMENT PARTS LISTING. PCB ASSEMBLY O RING SEAL BASE WARNING ALWAYS DISCONNECT POWER BEFORE SERVICING OR INSTALLING AN IS1 SERIES BEACON. © 1996 Whelen Engineering Company, Inc. Doc No. 04-0113085-01 May 24, 1996 13085B...
- Page 2 MODELS IS1120P and IS1120S 1. Connect the BLACK wire to the AC hot wire. 2. Connect the WHITE wire to the AC return wire. Refer to the IS1 Series Product Sheet for current draw to determine the proper wire gauge. 3.4"...
