ENGINEERING COMPANY, INC
Route 145, Winthrop Road
Chester, Ct 06412-0684
TELEPHONE: (860) 526-9504
TOLL FREE: 1-800-637-4736
MOUNTING SCREW
BASE
BASE GASKET
© 1996 Whelen Engineering Company, Inc. Doc No. 04-0113059-01
January 25, 1996.
13059D
Doc No. 04-0113059-01
STROBE LIGHT BEACONS
IS3006, 10-40 VDC, 12-28 VAC, SINGLE FLASH
IS3010, 12/24 VOLTS DC, DOUBLE FLASH
IS3020, 12/24 VOLTS DC, DOUBLE FLASH
IS3210, 120 VOLTS AC, SINGLE FLASH
IS3220, 120 VOLTS AC, DOUBLE FLASH
IS3240, 240 VOLTS AC, DOUBLE FLASH
DOME
STROBE TUBE ASSEMBLY
STROBE POWER SUPPLY
IS3 SERIES
REPLACEM
ENT PARTS
FOR IS3
SERIES
STROBES
SEE OTHER SIDE
OF PAGE FOR
REPLACEMENT
PARTS LISTING.
WARNING...
DISCONNECT THE
POWER SOURCE AND
WAIT 10 MINUTES
BEFORE INSTALLING
OR SERVICING THE
STROBE LIGHT.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Whelen Engineering Company IS3 Series
Summary of Contents for Whelen Engineering Company IS3 Series
- Page 1 OF PAGE FOR REPLACEMENT MOUNTING SCREW PARTS LISTING. BASE WARNING... DISCONNECT THE POWER SOURCE AND WAIT 10 MINUTES BEFORE INSTALLING OR SERVICING THE STROBE LIGHT. BASE GASKET © 1996 Whelen Engineering Company, Inc. Doc No. 04-0113059-01 January 25, 1996. 13059D...
- Page 2 (with the gasket, if required) on the wire (ground). mounting surface. Secure the beacon with three #10 2. Connect the BLACK wire and the WHITE wire to screws. the AC service. © 1996 Whelen Engineering Company, Inc. Doc No. 04-0113059-01 January 25, 1996.
