Step 1 — Check Required Hardware
Caution
: If using your own power supply, be certain that it is wired
correctly and supply voltage is 10 to 28 VDC. Incorrect wiring or volt-
age can cause software or equipment failures.
If connecting to a host with an IB-131 Interface Box, you will need
the following:
a
Item
1 FIS-0820-XXXXG
2
3 61-300026-03
4 98-000014-02
5 61-000011-02
97-100004-15
6
(90-264 VAC, 24VDC)
7 99-000017-01
a. See "Connect the System" on page 3 for diagram of system.
b. With either a terminal communications program or Microscan's
ESP which runs on Windows 98 or higher.
c. If using another host cable, make certain that it does not have
RTS/CTS connected to the host.
2
Part Number
MS-820 Industrial Bar Code Scanner Quick Start Guide
Description
MS-820 Industrial Bar Code Scanner
A Host Computer
DB-25 Null modem configuration
cable plug to DB-9 socket, 6ft.
a 25-pin cable to the 25-pin port
IB-131 Interface Box kit including
configuration cable
Null Modem Configuration Cable
Power Supply
Optional Object Detector
b
c
or
