- Page 1 Black Max ™ X300, X450, & X600 Models Installation and Use Manual Amplifier © 2001 Bogen Communications, Inc. All rights reserved. 54-2063-01R2 0109...
- Page 2 Every effort was made to ensure that the information in this guide was complete and accurate at the time of printing. However, information is subject to change. Important Safety Information WARNING: To Reduce The Risk of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or Moisture.
-
Page 3: Table Of Contents
Contents INTRODUCTION...1 Package Contents ...1 PANEL DESCRIPTIONS...2-3 Black Max Front Panel...2 Black Max Rear Panel ...3 INSTALLATION ...4-5 Mechanical Components...4 Ventilation...5 Rack Mounting...5 Rear Rack Mounting...5 Table Mounting ...5 CONNECTIONS...6 Speakers ...6 Inputs ...6 SEQUENTIAL TURN-ON ...7 Sequential Turn-On Operation ...7 OPERATION ...8-9 Front Controls &... -
Page 4: Introduction
Bogen's Black Max™ amplifiers deliver on what professional sound installers need most: Power and Reliability. Power With three different models (X600, X450, and X300), the Black Max series provides 2 independent channels of amplification at 600W, 450W, and 300W per channel into 70V constant voltage speaker loads safely and secure- ly. -
Page 5: Panel Descriptions
These indicators illuminate amber when excessive signal levels or very low impedance output loads cause out- put distortion to exceed a few percent Under such conditions, a built-in Clip/Limiting circuit activates and reduces input signal levels to protect both amplifier and speaker loads. One for each channel. 4. Power Switch/Circuit Breaker Magnetic circuit breaker controls AC power to the amplifier. -
Page 6: Black Max Rear Panel
8. Ground Terminal Provides convenient access to earth ground. 9. Speaker Terminals Connects to 70V constant voltage speaker loads. One set for each amplifier section. Accepts up to #10 AWG wire or spade lugs for speaker system connections. 10. Fan Exhausts Cooling air outlets for independent, variable speed cooling fans. -
Page 7: Installation
Installation Mechanical Components 1. Rack Ears Prior to installing the amplifier in to a 19" rack, you will need to attach the rack ears. Remove and save the 6 front most cover screws on each side panel of the amplifier. Position the rack ears as shown and attach using the 6 screws. -
Page 8: Table Mounting
Ventilation The Black Max amplifiers were designed to be placed on a table or rack-mounted. For rack-mounted applica- tions, the amplifiers can be stacked one on top of the other for maximum use of the rack space available with- out any extra, empty rack spaces between them. An open air space of at least 4"... -
Page 9: Connections
The speaker terminals can accept up to a #10 AWG wire or spade lug and have integral clamping plates which make wiring easier. The polarity of each set of speaker out- puts (A & B) is indicated with a "+" and "-" sign. Use these indica- tors to ensure that the phasing of the speakers are correct. -
Page 10: Sequential Turn-On
Sequential Turn-On Operation Black Max amplifiers contain a sequential turn-on feature that is designed to turn on a bank of Black Max ampli- fiers, one at a time, in sequence with approximately 1 second between each amplifier. This type of sequencing of power is necessary in large systems where the in-rush current of all the system amplifiers turning on at once would overload the AC mains supplying the system. -
Page 11: Operation
LIMIT - When illuminated, it indicates a condition in which the ampli- fier is limiting and automatically reducing signal level to reduce the overload condition. Limiting is a result of speaker load impedances that are too low or input signals that are too high, which drive the outputs beyond their operational ranges. - Page 12 Sleep Switch The Black Max amplifier includes a sleep mode feature that greatly reduces the power consumption of the amplifier after it has been idle (no audio activity) for more than 3 minutes. Any audio activity present at the input will power up the amplifier instantaneously and noiseless- ly, so that there is no loss of audio.The Sleep Switch is located on the rear of the unit.The sleep feature is activated by setting the switch to the AUTO position.
-
Page 13: Troubleshooting
• Lo-Cut Switch set to Flat • DC level at signal input • Load impedance too low • Amplifier speaker output is short-circuited • Amplifier too hot (check for proper ventilation clearances) • Poor electrical connections at input • Input cable routed near AC cables, power transformer, or other EMI radiating devices •... -
Page 14: Specifications
17" x 3.5" x 16" RF, DC, Low-frequency, Thermal, Low-impedance, Circuit Breaker, Short Circuit Sequential Turn-On Circuitry (defeatable), Sleep Mode (defeatable), Back-Slope AC voltage regulation, Toroidal Power Transformer Specifications X300 300W / Ch @ 70V 41 lbs. 15A line cord 16 ohms... - Page 15 50 Spring Street, Ramsey, NJ 07446, U.S.A. Tel. 201-934-8500; Fax: 201-934-9832; www.bogen.com...
