- Page 1 LIVINGSTON QUADRUPLE BRIDGE Date : 28-March-16 www.potterybarn.com Rev : - Page 1 of 4...
- Page 2 Use only vendor supplied hardware to assemble. Using unauthorized hardware could jeopardize the structural integrity of the item. The Livingston Quadruple Bridge is designed for use with Livingston Single Hutch or Double Hutch. Pre-assembly: Remove all parts and hardware from the box and lay out on a clear carpeted or scratch-free work surface, as this will avoid damaging parts during assembly.
- Page 3 1. Turn out the mending plates on the top of Quadruple Bridge (A) by loosen the allen bolts pre-attached on its mending plates with the Allen Key (E) as shown in fig. 1, illustration. 1. 2. Re-tighten with the Allen Key (E). Fig.
- Page 4 Configuration #2: Livingston Double Hutch (C) and Livingston Double Hutch (C). Position all Livingston Modular items which will be set up together at the desired location. Use drill bit to penetrate the pre-drilled holes on the side panels of Hutches that will be connected together as shown in illustration.
