Summary of Contents for Bogen TP-30D
- Page 1 Digital AM/FM Tuner Model TP-30D 54-5020-01 9609 Printed in Korea User’s Guide...
-
Page 2: Specifications
Specifications Band Coverage ..AM ....530 - 1620KHz FM ....87.5 - 107.5MHz Tuning . -
Page 3: Before You Begin
Before You Begin Your Bogen TP-30D Digital Tuner incorporates the latest in PLL digital circuitry for reliable performance for years to come. To get the maximum benefit from your Bogen product, please read all instructional materials provided with the unit. - Page 4 For reception where the unit is installed in a rack, an external antenna installed in accordance with National Electric Codes, is required. 1. Connect the external antenna leads to the 300 OHM BAL terminals. For applications using coaxial cable, a 75 OHM coaxial cable connector is provided.
-
Page 5: Audio Connections
Audio Connections Two audio patch cords are provided to make audio connections. One cord is a stereo patch cord (2 RCA plugs at each end) and one is a stereo-to-mono cord (2 connectors at one end, 1 connector at the other end). - Page 6 To Preset Stations 1. Select a band and tune the first desired station. 2. Press the ME button and then one of the “M” but- tons; for example, M1. (The preset number appears on the display as: CH1 .) 3. Tune the next station, press ME and the M2 but- ton, etc., for the 2nd through 6th preset.
- Page 7 The warranty will become void if repairs are made by other than the Bogen Factory Service Center. We are interested in the maintenance of your Bogen equipment. In the event of any difficulty, do not hesi- tate to ask our advice or assistance. Information may be obtained by writing to the Service Department, Bogen Communications, Inc., P.O.
- Page 8 50 Spring Street, Ramsey, NJ 07446 (201) 934-8500 Fax: (201) 934-9832...
