- Page 1 Unity / Unity Junior Bike Desk Owner’s Manual...
-
Page 2: Table Of Contents
Table of Contents Welcome Getting Started Welcome Warranty Safety Transportation Storage Specifications Unity Desk Assembly Assembly Instructions Unity Desk Operations Leveling Seat Adjustment Final Inspection... -
Page 3: Welcome
Welcome Congratulations on choosing the Unity, by LifeSpan. Your new bike desk is the perfect complement to studying, screen time, or working from home. It provides a healthy opportunity to add light exercise to sedentary activities you’re already engaged in. -
Page 4: Warranty
In order to insure our product warranty and to ensure the safe and efficient operation of your LifeSpan product, only authorized parts can be used. The warranty is void if any parts other than those provided by LifeSpan are used. Exclusions and Limitations: •... -
Page 5: Safety
Safety When using your Unity bike desk, basic precautions should always be followed, including: • Never operate this bike desk if it has been damaged. • Do not use outdoors or in areas of high humidity or extreme temperature changes. - Page 6 • Although the Unity Bike Desk is not intended for serious exercise, always consult a physician before beginning an exercise program. If you experience chest pains, nausea, dizziness or shortness of breath, stop exercising immediately and consult your physical before continuing.
-
Page 7: Transportation
You can then pull or push the Unity to the desired location. Prior to lowering the bike to its regular position, verify the rear seat area is clear of walls and other objects. -
Page 8: Specifications
Specifications Unity Bike Desk Seat Adjustable; Polyurethane Foam Pedaling Bi-Directional; forward and backward Max User Weight 400 lb (181.4 kg) Desk Size* 31.5 W x 24D in / 80 W x 61 D cm Net Weight 80.5 lb (36.5 kg) -
Page 9: Assembly Instructions
Assembly Instructions At LifeSpan we strive to make our equipment easy to assemble and start using. Parts that can be pre-assembled are always assembled and tested on the product line. Prior to starting the assembly process, take all the parts out of the box, remove plastic bags and lay everything out on the floor to become familiar with the components. - Page 10 Assembly Instructions Hardware Included Item# Part Description Item# Part Description Seat Slide Frame Desk Base Frame Rear Base Foot Left Desk Attachment Frame Drive System Right Desk Attachment Frame Seat Slide Frame Base Cover Desktop Left Pedal Right Pedal Seat All Hardware is Pre-Installed Step # Item #...
- Page 11 Assembly Instructions Step 1: Attach Base Foot to Seat Slide Frame A. Position Seat Slide Frame (1) on floor as shown in figure 1. Remove the two pre-installed M8X15L Bolts, Lock Washers and Washers (12) from Seat Slide Frame. C. Connect the Rear Base Foot (2) to the Seat Slide Frame (1) with the two M8x15L Bolts, Lock Washers and Washers (12).
- Page 12 Assembly Instructions Step 2: Attach Drive System to Seat Slide Frame A. Remove the four Phillips Head Screws(14) attaching the Seat Slide Frame Base Cover (4) to the Seat Slide Frame (1) and remove the Cover. Remove the two pre-installed M8x50L Bolts, Lock Washers, Washers and Nuts (13) from the Seat Slide Frame (1).
- Page 13 Assembly Instructions Step 3: Right and Left Pedal Assembly Identify which pedal goes on the right side and which goes on the left side by locating the “R” on the back of the Right Pedal (6) and the “L” on the back of the Left Pedal (5).
- Page 14 Assembly Instructions Step 4: Attach Seat A. Remove the four M8x15L Screws and Washers (15) from the base of the Seat (7). Attach the Seat (7) to the Seat Side Frame (1) with the four M8x15L Screws and Washers (15). M8 x 15L Bolt 5mm Allen (x4)
- Page 15 Assembly Instructions Step 5: Attach Desk Base Frame to Drive System A. Remove the two pre- installed M8 Nuts, Washers and Lock Washers (16) on the Low Connection Point(A) of the Drive System (3) as shown in the image to the right.
- Page 16 Assembly Instructions Step 6: Position Examples Positioning Desktop Option 1: The Unity Bike Desk Close allows you to position Position the Desktop(11) in one of Front three positions for your preference; close, middle and far. The image to the right shows an example of how this can be achieved.
- Page 17 Assembly Instructions Step 7: Attach Desk & Supports to Desk Base A. Remove the two M8x15L Screws and Washers (19) from the ends of the Left and Right Desk Attachment Frames (9)(10). Position the Desktop over the Desk Base Frame(8) and slide the Left and Right Desktop Attachment Frames(9)(10) into the Desk Base Frame.
-
Page 18: Leveling
LifeSpan's Unity Bike Desk comes with two leveling feet located on bottom of Desk Base Frame (8). Locate your Unity Bike Desk on a solid, level surface. Try to rock in all directions to see if any of the feet are not touching the floor. -
Page 19: Seat Adjustment
Seat Adjustment Seat Adjustment Pull the blue Seat Height Adjustment Lever(C) and move the Seat up or down to desired position. Release and allow the mechanism to lock into place. -
Page 20: Final Inspection
Final Inspection After your Unity bike desk has been assembled it is necessary to perform a final visual inspection and test of features. Thoroughly look at the bike from all angles. After visually checking your finished product, does anything look out of place? If so, please review assembly instructions for those areas and make needed adjustments. - Page 21 Unity / Unity Junior Bike Desk Manufacture Date: LifeSpan Fitness 785 West 1700 South Suite 1 Salt Lake City, UT. 84104 Phone: 877.654.3837 www.LifeSpanFitness.com Unity Bike Desk patent(s) pending Version 2.1...
