Operating and installation
instructions
Gas hobs
To avoid the risk of accidents or damage to the appliance it is
essential to read these instructions before it is installed and used for
the first time.
en-HK
M.-Nr. 09 316 120

Advertisement

Table of Contents
loading

Related Manuals for Miele KM 3014

Summary of Contents for Miele KM 3014

  • Page 1 Operating and installation instructions Gas hobs To avoid the risk of accidents or damage to the appliance it is essential to read these instructions before it is installed and used for the first time. en-HK M.-Nr. 09 316 120...
  • Page 2 For trouble-free operation of the appliance, it is best to use it in the countries specified for use. For use in other countries, please contact Miele in your country.
  • Page 3 Gas-heated appliances Safety precautions to take if you smell gas  Turn off the gas emergency control valve immediately. This is usually located near the gas meter.  Eliminate all sources of ignition in a safe manner. Do not smoke, light cigarette lighters or matches. ...

  • Page 4: Table Of Contents

    Contents Warning and Safety instructions..............Caring for the environment ................16 Guide to the appliance ..................17 Hob........................17 Control knobs...................... 18 Burner........................19 Accessories supplied ..................20 Before using for the first time ................21 Cleaning the hob for the first time............... 21 Switching on the hob for the first time ..............
  • Page 5 Contents Installation ......................42 Gas connection ....................44 Electrical connection ................... 46 Burner ratings ....................48 Product data sheets ..................49 Technical Data ....................50...

  • Page 6: Warning And Safety Instructions

    They contain important notes on installation, safety, use and maintenance. Miele cannot be held liable for damage caused by non-compliance with these instructions. Keep these instructions in a safe place and ensure that new users...
  • Page 7 Warning and Safety instructions Correct application  This hob is intended for domestic use and use in other similar environments.  This hob is not intended for outdoor use.  It is intended for domestic use only to cook food and keep it warm.
  • Page 8 Warning and Safety instructions Safety with children  Children under 8 years of age must be kept away from the hob unless they are constantly supervised.  Children over 8 years of age may use the hob without supervision if its operation has been clearly explained to them and they are able to use it safely.
  • Page 9  Unauthorised installation, maintenance and repairs can cause considerable danger for the user. Installation, maintenance and repairs must only be carried out by a Miele authorised registered gas installer.  Damage to the hob can compromise your safety. Check the hob for visible signs of damage.
  • Page 10 Miele authorised service technician. Otherwise the warranty is invalidated.  Miele can only guarantee the safety of the appliance when genuine original Miele replacement parts are used. Faulty components must only be replaced by Miele spare parts.
  • Page 11 If it is in use switch it off immediately. Disconnect it from the mains electricity supply, shut off the gas supply, and contact Miele.  If the hob is installed behind a cabinet door, do not close the door while the hob is in use.
  • Page 12 Warning and Safety instructions Correct use  The hob gets hot when in use and remains hot for some time after being switched off. Do not touch the hob if there is a possibility that it could still be hot. ...
  • Page 13 If the pan diameter is too large, flames can spread out to the sides and damage or burn the worktop, wall claddings or surrounding units and also parts of the cooktop. Miele cannot be held liable for this type of damage.
  • Page 14 Warning and Safety instructions  Ensure that the flames from the burner do not spread out beyond the base and up the sides of the pan.  Do not use pans with very thin bases on this hob, and never heat up empty pans as they could get damaged.
  • Page 15 Warning and Safety instructions Cleaning and care  Do not use a steam cleaning appliance to clean this hob. The steam could reach electrical components and cause a short circuit.

  • Page 16: Caring For The Environment

    / recycling centre for electrical and electronic appliances, or contact your dealer or Miele for advice. You are also responsible (by law, depending on territory) for deleting any personal data that may be stored on the appliance being disposed of.

  • Page 17: Guide To The Appliance

    Guide to the appliance a Wok burner b Small burner c Medium burner d Pan support (one for each burner) e Cooking zone symbols Controls knobs for the cooking zones: f Front right g Rear right h Left...

  • Page 18: Control Knobs

    Guide to the appliance Control knobs Small and medium burners Symbol Description  Burner off, the gas supply is turned off  Largest flame  Smallest flame Wok burner Symbol Description  Burner off, the gas supply is turned off ...

  • Page 19: Burner

    Guide to the appliance Small and medium burners Burner Wok burner a Burner cap b Burner head c Burner base d Thermocouple (flame failure monitor) a Outer burner cap e Ignitor b Inner burner cap c Burner head d Burner base e Thermocouple (flame failure monitor) f Ignitor...

  • Page 20: Accessories Supplied

    Guide to the appliance Accessories supplied The accessories supplied with your appliance as well as a range of optional ones are available to order from Miele (see “Optional accessories”). Accessories supplied with KM 3014 only: Wok ring The wok ring supplied gives additional stability to the wok, especially to woks with a rounded base.

  • Page 21: Before Using For The First Time

    Before using for the first time  Please stick the extra data plate for Switching on the hob for the the appliance supplied with this first time documentation in the space provided The metal components have a in the “After sales service” section of protective coating which when heated this booklet.

  • Page 22: Pans

    Pans - You can use any cookware that is Minimum pan base diameter heat-resistant. Ø cm Burner - Cookware with a thick base is Small burner preferable as the heat is distributed evenly. With thinner based cookware, Medium burner there is the risk that food will Wok burner overheat in places.
  • Page 23 Pans Wok ring Combination trivet  Use the wok ring supplied to give The combination trivet must be used if additional stability to pans, especially you wish to use a pan with a smaller to woks with a rounded base. diameter base than the minimum given in the table.

  • Page 24: Tips On Saving Energy

    Tips on saving energy - Use a pan lid whenever possible to minimize heat loss. - Wide, shallow pans are preferable to tall, narrow ones. They will heat up faster. - Cook with as little water as possible. - Reduce the size of the flame once the water has come to the boil or the oil is hot enough to fry in.

  • Page 25: Operation

    Operation Adjusting the flame  Risk of fire with overheated food. Unattended food can overheat and The burners can be regulated at any catch alight. level between the strongest and weakest flame. Do not leave the hob unattended whilst it is being used. As the outer part of the flame is much hotter than the centre, the tips of the Switching on...

  • Page 26: Safety Features

    Safety features Thermocouple (flame failure monitor) This hob has a thermocouple. If the flame goes out, for example because food has boiled over or if there has been a sudden draught, the supply of gas to the burner will be cut off. This will prevent any gas escaping.

  • Page 27: Cleaning And Care

    Cleaning and care Unsuitable cleaning agents  Danger of burning due to hot surfaces. To avoid damaging the surfaces of the The hob surface, pan supports and appliance, do not use: burners will be hot after use. - cleaning agents containing soda, Allow the hob to cool down before alkalines, ammonia, acids or cleaning it.

  • Page 28: Ceramic Surface

     Then clean the ceramic glass surface with the Miele ceramic and stainless steel hob cleaner (see “optional accessories”) or with a proprietary ceramic glass cleaner applied with kitchen paper or a clean cloth.

  • Page 29: Pan Supports

    Cleaning and care Pan supports Burner  Remove the pan supports. Do not clean any parts of the burners in a dishwasher.  Clean the pan supports in the dishwasher or with a solution of warm The surface of the burner cap will water and a little washing-up liquid become duller with time.
  • Page 30 Cleaning and care Assembling the small, medium and The surface of the burner cap will large burners become duller with time. This is completely normal and does not indicate material deterioration.  Place the burner head  on the burner base  so that the thermocouple ...
  • Page 31 Cleaning and care Assembling the wok burner  Place the burner head  on the burner base  so that the thermocouple  and the ignitor  extend through their respective holes in the burner head. The burner head must click into place correctly. ...

  • Page 32: Problem Solving Guide

    Problem solving guide Many malfunctions and faults that can occur in daily operation can be easily remedied. Time and money will be saved because a service call will not be needed. The following guide may help you to find the reason for a malfunction or a fault, and to correct it.
  • Page 33 The mains fuse has tripped. burner does not spark.  You may need to contact a registered electrical worker or Miele. There is food residue stuck between the ignitor and the burner cap. There is food residue on the thermocouple.

  • Page 34: Optional Accessories

    These products can be ordered through the Miele Webshop. Removes heavy soiling, limescale deposits and aluminium residues They can also be ordered from Miele (see end of this booklet for contact Microfibre cloth details) or from your Miele dealer. Removes finger marks and light soiling...

  • Page 35: After Sales Service

    You can book a Miele Customer Service Department call-out online at www.miele.com/service. Contact information for the Miele Customer Service Department can be found at the end of this document. Please quote the model identifier and serial number of your appliance (Fabr./SN/ Nr.) when contacting the Miele Customer Service Department.

  • Page 36: Installation

    *INSTALLATION* Installation Safety instructions for installation  Risk of damage from incorrect connection. Incorrect installation can cause damage to the hob. The hob must only be installed by a qualified person.  Damage from falling objects. Take care not to damage the hob when fitting wall units or a cooker hood above Fit the wall units and the cooker hood before the hob.

  • Page 37: Safety Distances

    *INSTALLATION* Installation Safety distances Safety distance above the hob A minimum safety distance must be maintained between the appliance and the cooker hood above it. See the cooker hood manufacturer's operating and installation instructions for details. If the manufacturer's instructions are not available for the cooker hood or if any flammable objects (e.g.
  • Page 38 *INSTALLATION* Installation Safety distances to the sides and back of the hob Ideally the hob should be installed with plenty of space on either side. There may be a wall at the rear or a tall unit or wall on one side (right or left) (see illustrations).
  • Page 39 *INSTALLATION* Installation Safety distance when installing the appliance near a wall with additional niche cladding A minimum safety distance must be maintained between the worktop cut-out and any niche cladding to protect it from heat damage. If the niche cladding is made from a combustible material (e.g. wood) a minimum safety distance ...

  • Page 40: Installation Notes

    *INSTALLATION* Installation Tiled worktops Installation notes Seal between the hob and the worktop Grout lines  and the hatched area underneath the hob frame must be smooth and even. If they are not the hob will not sit flush with the worktop and the sealing strip underneath the ...

  • Page 41: Building-In Dimensions

    *INSTALLATION* Installation Building-in dimensions All dimensions are given in mm. a Front b Casing depth c Mains connection box with mains connection cable, L = 2000 mm d Gas connection R ¹/₂...

  • Page 42: Installation

    *INSTALLATION* Installation Installing the hob Installation  Stick the supplied sealing strip under Preparing the worktop the edge of the hob.  Create the worktop cut-out as shown  Feed the power cable for the hob in the hob diagram. Remember to down through the worktop cut-out.
  • Page 43 *INSTALLATION* Installation Securing the hob Functional check  After installing the hob, ignite all burners to check that they are operating correctly: - The flame must not go out on the lowest setting, or when the control is turned quickly from the highest to the lowest setting.

  • Page 44: Gas Connection

    *INSTALLATION* Installation Gas connection Connection to the gas supply must be carried out in strict accordance  Attention! According to the Gas with current local regulations. Every Safety Ordinance of Hong Kong, any appliance should have its own easily gas installation works including the accessible isolating valve and test installation of appliances and point.
  • Page 45 *INSTALLATION* Installation Appliances set up for connection to HK town gas have an external gas governor MDG ELITRE (model-no. EL-125, pressure setting at 10 mbar) included. Connecting the hob The hob is supplied with a conical ½" gas connection point for connection to one of the following: - Rigid connection with isolation valve - Flexible connection, maximum length...

  • Page 46: Electrical Connection

    Green/yellow = earth  Danger of injury. Blue = neutral Miele cannot be held liable for Brown = live unauthorised installation, WARNING maintenance and repair work as this THIS APPLIANCE MUST BE can be dangerous to users.
  • Page 47 H 05 VV-F with a following depending on installation: suitable cross section. A suitable connection cable is available to order Safety fuses from Miele.  Completely remove fuses. Automatic circuit breakers  Press the (red) test button until the middle (black) button springs out.

  • Page 48: Burner Ratings

    Burner ratings Rated Heat Input Burner Gas type Highest Lowest setting setting Small burner HK Liquefied Petroleum gas (29 mbar) 0.95 0.20 HK Town gas (10 mbar) 1.30 – 0.19 Medium burner HK Liquefied Petroleum gas (29 mbar) 1.70 0.35 HK Town gas (10 mbar) 2.00 –...

  • Page 49: Product Data Sheets

    Product data sheets The following data sheets apply to the models described in this operating instruction manual.

  • Page 50: Technical Data

    Technical Data Model No KM 3014 Cut-out dimensions Width 560–600 mm Depth 490–500 mm Build-in depth 46 mm (Allow additional space below for connection to the gas supply) Unit Dimensions Width 626 mm Depth 526 mm Electrical connection Voltage 220–240 V Fuse rating 13 A Gas Type HK Town Gas HK Liquefied Petroleum (with external gas governor)
  • Page 51 Miele (Hong Kong) Limited Miele (Hong Kong) Limited 41/F - 4101, Manhattan Place 香港九龍灣宏泰道23號 23 Wang Tai Road Manhattan Place 41樓4101室 Kowloon Bay 電話: (852) 2610 1025 Hong Kong 傳真: (852) 3579 1404 Tel: (852) 2610 1025 電郵地址: customerservices@miele.com.hk Fax: (852) 3579 1404 網址: www.miele.hk...
