I N S TA L L AT I O N
1

Characteristics :

Power: 3V lithium battery, CR 2430 type
Protection index: IP 30
Operating temperature: +5°C to +40°C
Class III product
Normally polluted environment
2

Programming :

A

INITIAL INSTALLATION

Memorise a TELIS SOLIRIS RTS in the memory of a SOLIRIS receiver RT S
• Press the PROG button of the SOLIRIS receiver RTS until its LED lights. This indicates that the receiver
is ready for one minute to memorise the address of the transmitter. After this time limit, the LED goes out.
• Press the programming button on the backside of the TELIS SOLIRIS RTS with a ball-
point pen until the LED of the SOLIRIS receiver RTS blinks.
The address of the transmitter is memorized by the RTS receiver which automati-
cally quits its programming mode.
B

EXISTING INSTALLATION

Add another control (TELIS 1/4 RTS; CENTRALIS RTS ) in the memory of the SOLIRIS receiver RT S
TWO POSSIBILITIES
1
Repeat the same procedure as described in chapter 2A.
2
• Press more than two seconds on the programming button of a TELIS SOLIRIS RTS already memorized in
the SOLIRIS receiver
the both LEDs of the TELIS SOLIRIS RTS light on, indicating that the SOLIRIS receiver RTS is in
its programming modefor one minute.
• Press b r i e f l y the programming button of the new control you wish to memorise.
The address of the control is memorised in the SOLIRIS receiver RTS which automatically quit its
programming mode.
inteo
The TELIS SOLIRIS RTS is a SINGLE CHANNEL hand-held transmitter
compatible with the SOLIRIS receiver RTS
Commands are transmitted by radio (frequency 433.42 MHz).
Hereby, SOMFY, declares that this equipment is in compliance with the
essential requirements and other relevant provisions of Directive
1999/5/EC.
A Declaration of Conformity is available at the web address
www.somfy.com Heading CE
RTS in order to "wake up" the receiver.
TELIS SOLIRIS RTS
120 mm
45 mm
g u i d e
102 mm
51 mm
17 mm
23 mm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the inteo TELIS SOLIRIS RTS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SOMFY inteo TELIS SOLIRIS RTS

  • Page 1 Operating temperature: +5°C to +40°C Class III product Normally polluted environment Hereby, SOMFY, declares that this equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A Declaration of Conformity is available at the web address www.somfy.com Heading CE...
  • Page 2 DELETE ATRANSMITTER FROM THE MEMORY OF AR E C E I V E R To delete a transmitter from a RTS receiver, carry out the same procedure as described in chapter 2A : Set the RTS receiver in its programming mode, then press the prog button of the transmitter (the trans- mitter will be erased from the memory of the receiver).
