Select-Alert Alarm
Features
· Use as a cabinet alarm, door alarm,
link with push button/switch or as a
burglar alarm.
· Independent strobe and siren timing
of 15 seconds, 30 seconds, 60
seconds or continuous.
· Durable, polycarbonate construction.
· Includes ten high intensity LED's.
· Siren offers 32 user selectable tones.
· Choose piercing 100 or 85 dB alarm.
We protect the things that protect you.
Mini Controller
STI-SA5000 SERIES
· For indoor use only.
· Available with amber, green, blue,
red or white lens.
· Includes a tamper switch which
triggers the alarm when unit is
being removed from a wall.
· Low battery indicator.
· Powered by a 9 VDC battery
(not included) or external 12 – 24
volts.
· One Form "C" dry relay contact
output.
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for STI SA5000 Series
Summary of Contents for STI SA5000 Series
- Page 1 Select-Alert Alarm Mini Controller STI-SA5000 SERIES · For indoor use only. Features · Available with amber, green, blue, · Use as a cabinet alarm, door alarm, red or white lens. link with push button/switch or as a · Includes a tamper switch which burglar alarm.
- Page 2 CONTENTS Warnings and Cautions ....................... page 3 Warranty Information ......................page 3 Dimensions ........................page 3 Specifications ........................page 4 Electronic Setup ........................page 4 Alarm Tones ........................page 5 Alarm Timing and Volume ....................page 5 Terminal Strip Connections ....................page 6 Mounting Options ........................
- Page 3 All units are recommended for indoor use. Unit must be tested periodically to verify the life of battery. STI recommends you change the 9 Volt battery twice a year. When purchasing a Select- Alert, you will need to periodically test the connections to make sure audibles function at a sound level to alert staff.
- Page 4 OPEN ACTIVE STAND BY NORMALLY SPECIFICATIONS CLOSED Operating Voltage Internal power 9 VDC battery (not included) FORM "C" DRY CONTACTS Operating Temperature 32°F-120° MAIN POWER ALARM CONTROL SWITCH Power Consumption Stand by: 50µA Siren low volume: 85mA Siren high volume: 90mA Strobe: 25mA Siren Volume Low: 85 dB...
- Page 5 Step 2 - Alarm Tones - S1 1 2 3 4 5 1 2 3 4 5 ALARM TIMING STROBE TIMING ALARM TONES SIREN 0 0 0 0 0 BUZZ 0 0 0 0 1 STANDARD ALARM BATTERY VOLUME 1 0 0 0 0 SLOW ON/OFF 1 0 0 0 1 #3 FAST...
- Page 6 4.Mount back box to wall using #6 x 1 ¼ in. screws. 5.Mount base plate as shown using (2) #6-32 x 1 in. screws. Note: If not using STI back box, make sure surface will depress tamper switch. DRILL (4) 3/16 in. DIA. HOLES...
- Page 7 B) To Key Mount Plate or into Wall without Electrical Box DRILL 3/16 DIA HOLES KIT-SA505 KEY SWITCH MOUNTING BRACKET DRILL 3/16 DIA HOLES KIT-SA505 KEY SWITCH H18074 SWITCH LOCK MOUNTING BRACKET #801 KEY H18074 SWITCH LOCK #801 KEY 3 9/32 in. BASE PLATE 3 9/32 in.
- Page 8 Phone: 248-673-9898 • Fax: 248-673-1246 info@sti-usa.com • www.sti-usa.com Taylor House • 34 Sherwood Road • Bromsgrove, Worcestershire • B60 3DR • England Tel: +44 (0)1527 520 999 • Fax: +44 (0)1527 501 999 • info@sti-emea.com • www.sti-emea.com Printed in USA Inst. Sht. SA5000, Aug2017...
