Page 1
6 1/4” Split lock washers NOTE: We highly recommend using a medium strength thread lock product, such as Loctite®, on all of the bolts when installing your Corbin Beetle Bags. SADDLEBAG INSTALLATION 1. If applicable, remove the stock bags, brackets and sissybar.
Page 2
3. Replace the fender rail bolts with the supplied stainless steel studs and one #P10162 spacer and one #P10071 spacer on each stud, using a 5/8” wrench (Figure 2). Tighten to 12 ft. lbs. NOTE: If using a sissy bar or trunkbox, you will only be using one of the supplied spacers (#P10162) on each stud.
Page 3
Secure with the supplied 1/4 x 20 x 1” button head Allen bolts, lock washer and flat washer. Tighten to 6 ft. lbs. (Figure 9) FIG 8 Questions? Give us a holler... 800-223-4332 tech corbin.com FIG 9...
