FujiFilm TS-X 1440 Instruction Manual

Binocular techno-stabi
Hide thumbs Also See for TS-X 1440:
Table of Contents

Advertisement

Quick Links

防抖望远镜
BINOCULAR TECHNO-STABI
取扱説明書
Instruction manual
Bedienungsanleitung
Mode d'emploi
Manual de instrucciones
使用说明书
製品を使用する前にこの取扱説明書をよく読んで、安全な場所に保管してください。
Read these instructions thoroughly before using the product and then them store in a
safe place.
Lesen Sie diese Anweisungen sorgfältig durch, bevor Sie das Produkt verwenden, und
bewahren Sie sie an einem sicheren Ort auf.
Veuillez lire ces instructions attentivement avant d'utiliser le produit, puis rangez-les en
lieu sûr.
Lea estas instrucciones detenidamente antes de usar el producto y luego guárdelas en
un lugar seguro.
使用产品前请仔细阅读本使用说明书，并请妥善保管。
1440
BL00005042-100
日本語
ENGLISH
DEUTSCH
FRANÇAIS
ESPAÑOL
中文简
Worldwide Network

Advertisement

Table of Contents
loading

Related Manuals for FujiFilm TS-X 1440

Summary of Contents for FujiFilm TS-X 1440

  • Page 1 BL00005042-100 防抖望远镜 BINOCULAR TECHNO-STABI 日本語 1440 ENGLISH DEUTSCH 取扱説明書 FRANÇAIS Instruction manual Bedienungsanleitung ESPAÑOL Mode d’emploi 中文简 Manual de instrucciones Worldwide Network 使用说明书 製品を使用する前にこの取扱説明書をよく読んで、安全な場所に保管してください。 Read these instructions thoroughly before using the product and then them store in a safe place. Lesen Sie diese Anweisungen sorgfältig durch, bevor Sie das Produkt verwenden, und bewahren Sie sie an einem sicheren Ort auf.

  • Page 2: Before You Begin

    Before You Begin Check that the package contains all the supplied accessories listed below. Read “For Your Safety” to ensure safe operation. Read this manual thoroughly before using the product. Supplied Accessories • Strap • Lens cap • Eyepiece cap •...

  • Page 3: Specifications

    Specifi cations Magnifi cation 14× Eff ective objective lens 40 mm (1.6 in.) diameter Actual fi eld of view 4° Field of view at 1000 m 70 m (230 ft) (1094 yds) Minimum focusing 5 m (16 ft) distance Exit pupil diameter 2.86 mm (0.11 in.) Eye relief 13 mm (0.5 in.)

  • Page 4: For Your Safety

    For Your Safety • Although this product is designed with safety in mind, we ask that you read and observe the following safety precautions. • Keep this manual where it will be seen by all who use the product. Failure to observe warnings could result in death or serious WARNINGS injury.
  • Page 5 • Operators could pinch their fi ngers when adjusting eye width. Observe cau- tion when allowing small children to use the product. • Do not leave the product in direct sunlight. Failure to observe this precaution could result in fi re. •...
  • Page 6 CAUTIONS • In the event of product malfunction, do not attempt to repair the product yourself. Consult the original retailer. • Should the product break open as the result of a fall or other accident, do not touch the exposed parts. Failure to observe this precaution could result in injury.

  • Page 7: For Customers In Canada

    For Customers in the U. S. A. Tested To Comply With FCC Standards FOR HOME OR OFFICE USE FCC Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 8 Disposal of Electrical and Electronic Equipment in Private Households In the European Union, Norway, Iceland and Liechtenstein: This symbol on the product, or in the manual and in the warranty, and/ or on its packaging indicates that this product shall not be treated as household waste.
  • Page 9 Parts of the Binoculars Image stabilizer switch Eye-width indicator Image stabilizer LED Power LED Power switch Eyepieces Eyecups Diopter adjustment control Focus control Strap attachment point Objective lenses Battery chamber latch Open AA batteries Battery chamber Bottom view EN-8 ENGLISH...

  • Page 10: Using The Binoculars

    Using the Binoculars Rotate the battery-chamber latch to the left, remove the battery chamber, and load the batteries. Reinsert the battery chamber and latch it by rotat- ing the latch to the right. Adjust the eye height by rotating the eyecups. Retract the eyecups if you wear glasses and extend them if you do not.
  • Page 11 Other Precautions for Use • Although the product is water resistant, leaving water, dust, sand, or other foreign matter on the product could cause it to malfunction. To remove sea- water or dirt, fi rst check that the battery chamber is securely latched, then rinse the product under a slow trickle of water from a tap or wash it gently in a basin of fresh water.
