M101Q8 Series
Rugged Android Tablet
Qualcomm® SDA 660 Kryo 260 CPU, octa-core, up to 2.2 GHz
Android 9.0
Quick Start Guide
Version 1.0
Document Part No. 915211101068
Please read these instructions carefully before using this product, and save this manual for future use.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Winmate M101Q8 Series
Summary of Contents for Winmate M101Q8 Series
- Page 1 M101Q8 Series Rugged Android Tablet Qualcomm® SDA 660 Kryo 260 CPU, octa-core, up to 2.2 GHz Android 9.0 Quick Start Guide Version 1.0 Document Part No. 915211101068 Please read these instructions carefully before using this product, and save this manual for future use.
- Page 2 M101Q8 Rugged Android Tablet ❶ Getting Started Congratulations on purchasing Winmate® M101Q8 Rugged Android Tablet Computer. The rugged design allows you to use it in harsh outdoor environments. This quick start guide tells you step by step how to get the Tablet Computer up and running.
- Page 3 Quick Start Guide ❸ Description of Parts Front: Right: Item Description Item Description Micro Memory card reader Front 2 Megapixel Webcam Camera SD Card port for Micro SD Reader Card Show the current status of the Tablet Computer Red: High speed USB port Charging / Hot-swap battery Type C connects to PC or...
- Page 4 M101Q8 Rugged Android Tablet Rear: Bottom: No Item Description Item Description Optional NFC reader for Latch to lock the battery reading of NFC tags. Battery Lock in place once battery is Latch inserted. No spring Kensington Provide lock access for loaded.
- Page 5 Quick Start Guide Installing SIM Card (For WWAN Equipped Devices) The Tablet Computer supports WWAN data connection and fits a Micro-SIM card. To install the SIM card: Tools Needed: Service Windows 3G/ LTE Module Screw: M2x5, 4 pc Screw: M2x3.5, 1 pc Screwdriver: Philips Type , Size #0 , for Screwdriver: Philips Type , Size #0 , for M2 screws, torque: 2.0 ±...
-
Page 6: Inserting Microsd Card
M101Q8 Rugged Android Tablet Inserting MicroSD Card Your tablet supports Micro SDXS card. To install Micro SDXS card: 1. Open I/O protective cover by pulling out the latch. 2. Insert microSD card into slot with contacts facing down. 3. Press the card in to ensure that it is seated properly. 4. -
Page 7: Connecting To Power Supply
Quick Start Guide To remove the standard battery pack into the Tablet Computer: 1. Power off the tablet computer (or put it to sleep). Disconnect any cords connected to the computer. 2. Turn the tablet computer over, back facing up. 3. - Page 8 M101Q8 Rugged Android Tablet ❺Turning On and Off the Device To turn on the device: 1. Press and hold the power button for 3 seconds, located on the top side of the unit. 2. When the device vibrates, release the power button. 3.
- Page 9 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
