  • Page 1 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide...
  • Page 2 INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
  • Page 3 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Compliance This equipment has been tested and found to comply with the limits for Class A device, pursuant to part 15 of the FCC Rules.
  • Page 4 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Symbol Convention The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in WARNING equipment damage, data loss, performance degradation, or unexpected results.
  • Page 5 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Power Supply Make sure that the power has been disconnected before you wire, install, or disassemble the device. • Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with •...
  • Page 6 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Environment DO NOT expose the device to extremely hot, cold, dusty, corrosive, saline-alkali, or damp • environments. Make sure the running environment meets the requirement of the device. The operating temperature shall be -40°...

  • Page 7: Table Of Contents

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Table of Contents Appearance Description ..........................8 Type I Camera Appearance ........................... 8 Type II Camera Appearance ........................10 Type III Camera Appearance ........................10 Type IV Camera Appearance ........................11 Cable Description ............................

  • Page 8: Appearance Description

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Appearance Description There are four thermal and optical bi-spectrum network bullet camera types. Here are overviews of Type I cameras, Type II cameras, Type III cameras, and Type IV cameras. Bullet Type Model Type I...
  • Page 9 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Figure 3, Type I Camera Appearance (2) Figure 4, Wall Mounting Bracket (Optional) Description No. Description No. Description Photoresister Lens (Optical) Lens (Thermal) Sun Shield Network Cable Power Supply Interface Alarm Interface RS-485 Audio Interface...

  • Page 10: Type Ii Camera Appearance

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Type II Camera Appearance Mount Sun Shield Thermal Lens Memory Card Optical Lens Figure 5, Type II Camera Appearance Type III Camera Appearance Figure 6, Type III Camera Appearance QSG DS-2TD2xxx-xx/xx 071720NA...

  • Page 11: Type Iv Camera Appearance

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Sun Shield Camera Memory Card Slot Bracket Holder Cable Outlet Bracket Hinge Bracket Arm Reset Button Junction Box Cover Junction Box Base Sealing Interface Figure 7, Type III Camera Cables Type IV Camera Appearance B r a c k e t S u n S h i e l d...

  • Page 12: Junction Box Interfaces

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Audio Output Interface Audio Input Interface Alarm Interface 1 Alarm Interface 2 RS-485 Interface Power Interface (12 VDC) Network Interface Audio Output Interface Audio Input Interface Alarm Interface 1 Alarm Interface 2 RS-485 Interface Power Interface (12 VDC or 24 VAC)

  • Page 13: Installation

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide The junction box differs by camera model. Alarm Interface Audio Input& Output Interface Network Interface Power Interface Figure 10, Interface Description Installation Before You Start Make sure the device in the package is in good condition and all the assembly parts are included. •...

  • Page 14: Install Memory Card

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Install Memory Card Install Type I Camera Memory Card 1. Unscrew and remove the sun shield. Screws Shield Figure 11, Remove Sun Shield 2. Unscrew and remove the back cover. QSG DS-2TD2xxx-xx/xx 071720NA...
  • Page 15 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Figure 12, Remove Back Cover Case 3. Insert a microSD card into the microSD card slot. Figure 13, Insert MicroSD Card 4. Fix the sun shield and back cover to the camera body with the removed screws. Figure 14, Figure 1-1 Fix Sun Shield and Back Cover QSG DS-2TD2xxx-xx/xx 071720NA...

  • Page 16: Install Type Ii And Type Iv Camera Memory Card

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Install Type II and Type IV Camera Memory Card Type II and Type IV camera memory cards are installed in the same way. Here is an example of memory card installation for a Type II camera.

  • Page 17: Wide Range Coverage

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Memory Card Cover Figure 17, Remove Card Slot Cover 2. Insert the memory card into the memory card slot. Memory Card Figure 18, Insert Memory Card 3. Cover the memory card slot and fix the screws on the memory card slot cover. Wide Range Coverage Select the installation location and proper lens focal length according to the Wide Range Coverage list below:...

  • Page 18: Install Camera

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Detect Target: The target should be at least 1.5 pixels on the image. • Recognize Target: The target should be at least 6 pixels on the image. • Identify Target: The target should be at least 12 pixels on the image. •...
  • Page 19 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Figure 21, Fix the Camera to the Wall 4. Adjust the camera to the optimal surveillance angle. 1) Loosen the pan adjusting screw to adjust panning position [0° to 360°]. Tighten the screw. Panning Position [0°...

  • Page 20: Install Type Ii And Type Iv Camera

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Tilting Position [-45° to 45°] Figure 23, Tilt Adjustment Loosen the screws slightly until you can adjust the camera. DO NOT remove the screws from the bracket. Install Type II and Type IV Camera Type II and Type IV cameras are installed in the same way.
  • Page 21 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide 4. Install the bullet camera with the screws (supplied). Figure 25, Wall/Ceiling Mounting 5. Adjust the camera to the optimal surveillance angle. Bracket Type I • 1) Loosen the tilt adjusting screw to adjust tilting position [0° to 360°]. Tighten the screw. 2) Loosen the pan adjusting screw to adjust the panning position [-45°...

  • Page 22: Install Type Iii Camera

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Screw 0°-360° 0°-90° Figure 27, 2-Axis Adjustment Install Type III Camera Before You Start There are three Type III camera installation methods: wall mounting, ceiling mounting, and stand mounting. Wall Mounting Ceiling Mounting Stand Mounting...
  • Page 23 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Latch Holes Latches Figure 29, Take Apart Junction Box Attach the drill template (supplied) to where you want to affix the camera, and then drill four screw holes (recommended depth: 40 mm) in the ceiling/wall according to the drill template. Drill a cable hole according to the A mark of the drill template.
  • Page 24 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Sealing Ring Screw Figure 31, Install Junction Box Base Route the cables through the cable hole. Insert the latches into the latch holes to fix the bracket and camera with the junction box. Wall Mounting Ceiling Mounting Stand Mounting...

  • Page 25: Waterproof Measures (Optional)

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Tilting Adjusting Screw Tilting Range [-90° to +55°] Figure 34, T-Axis Adjustment 3) Loosen the pan adjusting screw to adjust the panning position [-90° to 90°]. Tighten the screw. Panning Adjusting Screw Panning Range...

  • Page 26: 2.4.1 Install Network Cable Waterproof Jacket

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide 2.4.1 Install Network Cable Waterproof Jacket ② ④ ⑥ ③ ⑤ ① Align ⑥ ① ④ ③ Figure 36, Install Waterproof Jacket Feed the network cable through ① and ③ in order. Fix ②...

  • Page 27: Set The Network Camera Over The Lan

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Set the Network Camera over the LAN You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 28: Activate Via Sadp Software

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Figure 40, Activation Interface (Web) Create a password and input it into the password field. STRONG PASSWORD RECOMMENDED − We highly recommend that you create a strong password of your own choosing (using a minimum of eight characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 29: Modify The Ip Address

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Figure 41, SADP Interface The SADP software supports activating the camera in batch. Refer to the SADP software user manual for details. Create a password, input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED −...

  • Page 30: Access Via Web Browser

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Change the device IP address to the same subnet as your computer by either modifying the IP address manually or checking Enable DHCP. Figure 42, Modify the IP Address Input the password to activate your IP address modification.
  • Page 31 DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Open the Web browser. Input the IP address of the network camera in the browser address bar, and press Enter to enter the login interface. The default IP address is 192.168.1.64. If the camera is not activated, activate the camera first according to Chapter 3.2.

  • Page 32: Appendix

    DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide Appendix Common Material Emissivity Reference Material Emissivity Human Skin 0.98 0.91 Cement Concrete 0.95 Ceramics 0.92 Rubber 0.95 Paint 0.93 Wood 0.85 Asphalt 0.96 Brick 0.95 Sand 0.90 Soil 0.92 Cotton 0.98...
