  • Page 1 CTR 1.2i Crosstrainer User manual...

  • Page 2: Table Of Contents

    ASSEMBLY INSTRUCTIONS 11 - 12 MAINTENANCE MAINTENANCE 13 - 21 CONTROL PANEL CONTROL PANEL APP INSTRUCTIONS APP INSTRUCTIONS 23 - 24 EXPLODED DRAWING EXPLODED DRAWING 25 - 26 PARTS LIST PARTS LIST TRAINING INSTRUCTIONS TRAINING INSTRUCTIONS VirtuFit CTR 1.2i Crosstrainer...

  • Page 3: Safety Instructions

    0.5 metres of free space all around it. – Before using the device, check that the nuts and bolts are securely tightened. – The safety of the device can only be maintained if it is regularly examined for damage and/or wear and tear. VirtuFit CTR 1.2i Crosstrainer...
  • Page 4 – Maintenance assembly and repair work not carried out by an official dealer. – In the event of improper use, neglect and / or poor maintenance. – Failure to maintain the device in accordance with the manufacturer’s instructions (see the enclosed manual). VirtuFit CTR 1.2i Crosstrainer...

  • Page 5: Assembly Instructions

    Transport wheels: Make sure that the transport wheels are attached to the front of the appliance. STEP 1 • Attach the Front Stabilizer (35) and the Rear Stabilizer (36) to the Main Frame (40) with Carriage Bolt (33), Domed Nut (23) and Arc Washer (22). VirtuFit CTR 1.2i Crosstrainer...
  • Page 6 STEP 2 • Connect the Sensor 16 and 38, fix the Upright Post (15) with the Main Frame (40) with Nut (27) Arc Washer (22). Note: Tighten the Screw (27) and the Arc Washer (22) very tight. VirtuFit CTR 1.2i Crosstrainer...
  • Page 7 Fix the Pedal Tubel ( 42 L / R ) with the Pedal Crank by Pedal Hinge Bolt (46 L / R) Curved Washer (50), and Nylon Nut ( 51 L / R ). Install the Pedal (44) on the Pedal Tube (42 L / R) with Hex Head Bolt (43), Knob (27). VirtuFit CTR 1.2i Crosstrainer...
  • Page 8 Install the Middle handlebar (4) on the Upright Post (15) with bolt (8) Arc Waser (9). • Fix the Handlebar ( 11 L / R ) to the Lower Handle Bar ( 25 L / R ) with Bolt (21), Arc Washer (85) and Domed Nut (23). VirtuFit CTR 1.2i Crosstrainer...
  • Page 9 Place the end cap (17) and (28) on the bolts as pictured above. NOTE! Make sure that all nuts and bolts are tight before you start training. The end cap of the front stabilizer tube is movable, making it easier for you to move the crosstrainer. VirtuFit CTR 1.2i Crosstrainer...
  • Page 10 ASSEMBLY INSTRUCTIONS ADAPTER • The adapter connection is located on the back of the device (see illustration). Attach the adapter to the adapter connection and connect to the power supply. You can now use the elliptical trainer. VirtuFit CTR 1.2i Crosstrainer...

  • Page 11: Maintenance

    Be sure to clean the exposed area of the belt and the foot rails of the treadmill on both sides. In addition, wear clean shoes to reduce the risk of contamination of the treadmill. Remove the hood at least once a year to vacuum underneath. VirtuFit CTR 1.2i Crosstrainer...
  • Page 12 • The sensors may become damp, dirty or greasy. So you have to clean them regularly. The console is not working If there is no signal when pedaling, check if the cable is properly attached. VirtuFit CTR 1.2i Crosstrainer...

  • Page 13: Control Panel

    • When in setting, press “ENTER” to confirm the value that you would like to preset. (2) START/ Press “START/STOP” button to start or stop the programs. During any mode, STOP hold down this button for 2 seconds to totally reset the computer. VirtuFit CTR 1.2i Crosstrainer...
  • Page 14 • First test your current heart rate and show your heart rate value, press this (5) RECOVERY button to enter into pulse recovery testing. • When you are in pulse recovery mode, press this button to exit. VirtuFit CTR 1.2i Crosstrainer...
  • Page 15 The maximum heart rate depends on different age and this program will ensure you do the healthy exercise within maximum heart rate. 1. Press UP , DOWN button to choose the heart rate control program. 2. Press ENTER to confirm the heart rate control program, and enter into AGE setting window. VirtuFit CTR 1.2i Crosstrainer...
  • Page 16 3. The time display will flash, and then press UP, DOWN button to set up the desired time to do the exercise. Press ENTER to confirm the value. 4. The distance will flash, and then press UP, DOWN button to set up the desired distance value. Press ENTER to confirm the value. VirtuFit CTR 1.2i Crosstrainer...
  • Page 17 The measurement value cannot be regarded as the basis of medical treatment. • If the computer is also equipped with wireless heart rate measuring via the transmitter belt, and with hand pulse function, the hand-measurement-signal-detecting is preferred. VirtuFit CTR 1.2i Crosstrainer...
  • Page 18 When the calorie reaches 0, the program will stop and the computer will alarm. PULSE Showing the exercise heart rate value. Range: 60~240BPM(beat per minute). RESISTANCE LEVEL Showing level. Range:1~16 WATT Show the exercise watt,the interval should be 10,between 30-350 ADAPTER iNPUT: AC 230V OUTPUT: 8 VDC 500mA VirtuFit CTR 1.2i Crosstrainer...
  • Page 19 CONTROL PANEL PROGRAMS 1 MANUAL PROGRAM 10 PRESET PROGRAM PROFILE (PROGRAM: P1-P10) VirtuFit CTR 1.2i Crosstrainer...
  • Page 20 P3: FATBURN P8: ENDURANCE P4: RAMP P9: SLOPE P5: MOUNTAIN P10: RALLY 1 WATT CONTROL PROGRAM (WATT PRO: P16) 4 HEART RATE CONTROL PROGRAM (PULSE PRO: P17-P20) 55% Hearthbeat, 75% hearthbeat, 95% hearthbeat, Target heart rate VirtuFit CTR 1.2i Crosstrainer...
  • Page 21 3. The computer will turn off automatically if there is no operation, speed signal and pulse signal over 4 minutes. Meanwhile,it will store your current exercise data and urn the loading resistance to the minimum. Once you press any button or in motion, the computer will turn on automatically. VirtuFit CTR 1.2i Crosstrainer...

  • Page 22: App Instructions

    3. Scan the QR code on the right to go to the user manual of the app. The manual describes step by step how the app should be connected to the device, how the app works and what the options are. FITSHOW APP STORE GOOGLE PLAY USER MANUAL FITSHOW FITSHOW FITSHOW VirtuFit CTR 1.2i Crosstrainer...

  • Page 23: Exploded Drawing

    EXPLODED DRAWING VirtuFit CTR 1.2i Crosstrainer...
  • Page 24 EXPLODED DRAWING VirtuFit CTR 1.2i Crosstrainer...

  • Page 25: Parts List

    Crosshead screw M5*15 Lower handlebar ( L / R ) Motor Bolt M8x16 Crank cover Knob M10 Crosshead screw ST4.2*16 End cap S17 Crosshead screw ST4.2*19 Bolt M10x60 Chain cover ( L / R ) Bushing φ14x12.5Xφ10.1 VirtuFit CTR 1.2i Crosstrainer...
  • Page 26 Tension spring 1 Crank Bolt Bracket Open-end wrench S13 14 15 Hex wrench S6 Hex wrench S8 Open-end wrench S17 18 19 End cap Arc washer D8Xφ16X1.5XR30 Magnetic board Tension spring 2 Plastic lattice Magnet Hexagon nut M6 VirtuFit CTR 1.2i Crosstrainer...

  • Page 27: Training Instructions

    The purpose of cooling down is to return the body to its normal or near normal, resting state at the end of each exercise session. A proper cool-down slowly lowers your heart rate and allows blood to return to the heart. VirtuFit CTR 1.2i Crosstrainer...
  • Page 28 For questions or missing parts please contact your dealer.
