Step 2:
Assemble the rear wall panels
You will find it easier to assemble your shed using sawhorses with timber studs attached (timber needs to be the same length as the
shed (1.5m)) or alternatively, a trestle table.
Place 2 x part 6A (sheet) on your worktable and join together with the self-tapping screws as per the diagram below.
Now fit part 20B (top channel) and part 20C (bottom channel) to the sheeting by tapping it in (diagram A) or sliding it in (diagram B).
Make sure the small lip of the channel is always facing out. This ensures rainwater cannot build up inside your shed.
ROOF TOP EDGE
RIDGES FACING UP
20B
TOP
6A
6A
20C
A
A
Original Language Version
GSS1515.V2, GSS1515G.V2 Issue: 2(I) - 13/04/17
