GardenShed
1.5 x 1.5 x 2.1m
Now fit the bolt down kit as per the diagram. Strengthen the mid wall braces by applying part 72 (mid wall brace bracket) to
each corner if necessary.
72
WALL SHEET
BOLT & NUT
BOLT & NUT
WALL SHEET
STEEL ANGLE
STEELA NGLE
SLAB
SLEEVE ANCHOR BOLT
SLEEVEA NCHORB OLT
DOOR
DOOR
Original Language Version
GSS1515.V2, GSS1515G.V2 Issue: 2(I) - 13/04/17
