- Page 1 VE2812AUST / VE2812AEUT HDMI & VGA HDBaseT Transmitter with US / EU Wall Plate User Manual www.aten.com...
-
Page 2: Emc Information
VE2812AUST / VE2812AEUT User Manual EMC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: User Information
VE2812AUST / VE2812AEUT User Manual User Information Online Registration Be sure to register your product at our online support center: International http://eservice.aten.com Telephone Support For telephone support, call this number: International 886-2-8692-6959 China 86-400-810-0-810 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America... -
Page 4: Package Contents
VE2812AUST / VE2812AEUT User Manual Package Contents 1 VE2812AUST / VE2812AEUT HDMI & VGA HDBaseT Transmitter 1 3-Pin RS-232 Terminal Block 1 2-Pin Power Terminal Block 1 Mounting Kit (VE2812AEUT only) 1 Faceplate (VE2812AUST only) 1 Power Adapter 1 User Instructions* Note: Make sure that all of the components are present and in good order. -
Page 5: Table Of Contents
VE2812AUST ........ - Page 6 VE2812AUST / VE2812AEUT User Manual RS-232 Serial Transmission ........17 Bypass .
-
Page 7: About This Manual
VE2812AUST / VE2812AEUT User Manual About this Manual This user manual is provided to help you get the most from the VE2812AUST / VE2812AEUT unit. It covers all aspects of installation, configuration, and operation. An overview of the information found in the manual is provided below. -
Page 8: Conventions
VE2812AUST / VE2812AEUT User Manual Conventions This manual uses the following conventions: Indicates text that you should key in. Monospaced Indicates keys you should press. For example, [Enter] means to press the Enter key. If keys need to be chorded, they appear together in the same bracket with a plus sign between them: [Ctrl+Alt]. -
Page 9: Product Information
VE2812AUST / VE2812AEUT User Manual Product Information For information about all ATEN products and how they can help you connect without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers: International http://www.aten.com... - Page 10 VE2812AUST / VE2812AEUT User Manual This Page Intentionally Left Blank...
-
Page 11: Introduction
Overview ATEN VE2812AUST / VE2812AEUT is a video transmitter that can send VGA (with audio) and HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. Featuring built-in PoH (Power over HDBaseT) function, the VE2812AUST / VE2812AEUT receives power supply from the HDBaseT output port on the connected device. -
Page 12: Features
HDMI 4K up to 100 m via a Cat 5e/6/6a cable or ATEN 2L-2910 Cat 6 cable VGA 1600 x 1200 / 1920 x 1200 up to 100 m via a Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable ... -
Page 13: Planning The Installation
Note: The maximum transmission distance for 4K resolution using a Cat 5e cable is 70 m. Compatible ATEN Video Extenders The VE2812AUST / VE2812AEUT is compatible with a wide range of ATEN HDBaseT video extenders. Visit our official web site for more details. -
Page 14: Components
VE2812AUST / VE2812AEUT User Manual Components Top View VE2812AUST VE2812AEUT Component Description IR Port Connects to an IR transmitter/receiver. HDMI Input Port Connects to the HDMI Out port on the source device. Audio Input Port Connects to the Audio Out port on the source device. -
Page 15: Side View 1
VE2812AUST VE2812AEUT No. Component Description Firmware Upgrade Switch This port is reserved for ATEN Technical Support. If you would like to do a firmware upgrade yourself, please contact your dealer. HDBaseT Long Reach Put the switch to ON to enable the Long Reach Mode Switch Mode. -
Page 16: Led Display
VE2812AUST / VE2812AEUT User Manual LED Display You can find the unit’s LEDs on the top and front panel as illustrated below. See the table below for details on LED indication. VE2812AEUT VE2812AUST No. LED Indication Description Link LED Lights orange The transmission to the receiver is stable. -
Page 17: Hardware Setup
2. Do not power on the VE2812AUST / VE2812AEUT until all the necessary hardware is connected. Mounting the VE2812AUST / VE2812AEUT Unit VE2812AUST / VE2812AEUT is designed to be installed in a wall or ceiling. Site Preparation Choose a location where cables are free of interference and install the cables into the wall before installing the unit. -
Page 18: Ve2812Aeut
VE2812AUST / VE2812AEUT User Manual VE2812AEUT Depth (into the wall): 35.5mm Length x Width: 111mm x 52.5mm Drawing Screw Site Screw sites are required to secure the unit into the wall. There are regional template screw sites and the unit can use the sites easily. -
Page 19: Ve2812Aust
Chapter 2. Hardware Setup VE2812AUST VE2812AEUT... -
Page 20: Ve2812Aust Wall Mount
Note: Screws stabilizing the unit to the site are not included in the package content 2. Attach the hook on the top of the faceplate to the VE2812AUST / VE2812AUST2 until it clicks in place. 3. Push in the lower part of the faceplate on the VE2812AUST /... -
Page 21: Ve2812Aeut Wall Mount
Chapter 2. Hardware Setup VE2812AEUT Wall Mount 1. Secure the supplied mounting kit to your installation site by tightening 4 screws (EU type) or 2 screws (MK type) to the screw holes. This installation site can be a wall or ceiling. For MK Type For EU Type Note: Screws stabilizing the mounting kit are not included in the package... -
Page 22: Connecting The Ve2812Aust / Ve2812Aeut Unit
VE2812AUST / VE2812AEUT User Manual Connecting the VE2812AUST / VE2812AEUT Unit Follow the steps below to connect the VE2812AUST / VE2812AEUT to a source, a compatible ATEN Video Extender, and other controls as required. VE2812AUST Top View Side View Example: VE2812R Receiver... -
Page 23: Terminal Block Connection
4. (Optional) Connect an IR transmitter/receiver to the IR port. 5. (Optional) Plug the Power Adapter cable into the Power Terminal Block on the VE2812AUST / VE2812AEUT to power on the device. Please refer to Power Supply Information on page 13 for more details. -
Page 24: Rs-232 Channel Transmission
(Rx) end of another unit. The RS-232 signals can be transmitted back the other way. You can set the VE2812AUST / VE2812AEUT to either bypass serial data or to receive RS-232 commands. By default, the VE2812AUST / VE2812AEUT is set to receive serial data. -
Page 25: Operation
For more details, see RS-232 Serial Transmission, page 17. HDMI The VE2812AUST / VE2812AEUT only transmits HDMI source to the connected receiver. (LED lights orange) The VE2812AUST / VE2812AEUT only transmits VGA source and its audio input to the connected receiver. (LED lights orange) -
Page 26: Input Selection Pushbutton
VE2812AUST / VE2812AEUT User Manual Input Selection Pushbutton Press the Input Switch Pushbutton located on the front panel to switch among the Auto Switch, HDMI, and VGA input mode. VE2812AUST Source Switch Pushbutton HDMI Mode LED Auto Switch Mode LED... -
Page 27: Rs-232 Serial Transmission
Command mode: the Auto LED, HDMI LED, and VGA LED light orange and blink once every 0.3 seconds for three seconds. Note: 1. By default, the VE2812AUST / VE2812AEUT is set to Command mode. 2. The RS-232 status is kept even VE2812AUST / VE2812AEUT is powered on and off. -
Page 28: Bypass
VE2812AUST / VE2812AEUT User Manual Bypass RE-232 serial data is bypassed from the controller PC or Pad to other connected devices. Command You can change the input mode using RS-232 commands. Refer to the table below for a list of available tasks and the corresponding commands. -
Page 29: Long Reach Mode
VE2812AUST Side VE2812AEUT Side Long Reach Mode Switch Long Reach Mode Switch Note: When Long Reach Mode is enabled, the VE2812AUST / VE2812AEUT will not be able to transmit 4K signals, in which case, the output display will be blank. - Page 30 VE2812AUST / VE2812AEUT User Manual This Page Intentionally Left Blank...
-
Page 31: Appendix
Appendix Safety Instructions General This product is for indoor use only. Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result. - Page 32 VE2812AUST / VE2812AEUT User Manual extension cord ampere rating. Make sure that the total of all products plugged into the wall outlet does not exceed 15 amperes. To help protect your system from sudden, transient increases and decreases in electrical power, use a surge suppressor, line conditioner, or uninterruptible power supply (UPS).
-
Page 33: Technical Support
Troubleshooting http://www.aten-usa.com/support Support Documentation Software Updates Telephone Support 1-888-999-ATEN ext 4988 1-949-428-1111 When you contact us, please have the following information ready beforehand: Product model number, serial number, and date of purchase Your computer configuration, including operating system, revision level, expansion cards, and software ... -
Page 34: Specifications
HDCP Compatible Consumer Electronics Control (CEC) Max. Resolutions / HDMI: Distances Up to 4k @70m (Cat 5e/6) / 100m (Cat 6a/ATEN 2L-2910 Cat6) Up to 1080p @100m (Cat 5e/6/6a) VGA: Up to 1920 x 1200 & 1600 x 1200 @70m (Cat 5e/6) / 100m (Cat 6a/ATEN 2L-s910 Cat 6) ... - Page 35 Appendix Function VE2812AUST VE2812AEUT Switches Video Input Port 1 x Pushbutton - HDMI, VGA, and AUTO Selection Long Reach Mode 1 Slide Switch - ON/OFF Switch Firmware Upgrade 1 Slide Switch - ON/OFF Power Unit to Unit 1 x RJ-45 Female (PoH)
-
Page 36: Supported Vga Resolutions
VE2812AUST / VE2812AEUT User Manual Supported VGA Resolutions The VE2812AUST / VE2812AEUT supports the following VGA resolutions: VGA Resolution Frame Rate (Hz) 640 x 480 640 x 480 800 x 600 800 x 600 1024 x 768 1024 x 768... -
Page 37: Limited Warranty
ATEN will provide a repair service, without charge, during the Warranty Period. If a product is detective, ATEN will, at its discretion, have the option to (1) repair said product with new or repaired components, or (2) replace the entire product with an identical product or with a similar product which fulfills the same function as the defective product. -
Page 38: Template Printing
VE2812AUST / VE2812AEUT User Manual Template Printing Please use 1:1 ratios when printing. We also recommend using A4 sized paper or larger. After printing, please measure the print so that the labeled measurement is correct. - Page 39 VE2812AUST Screw Sites Template 4.6cm 4.6cm 0.80cm...
- Page 40 VE2812AEUT Screw Sites Template 1.1cm 6.0cm...
