LawnMaster NPTGSP2617A Operator's Manual

26cc 2-cycle grass trimmer
Hide thumbs Also See for NPTGSP2617A:
Table of Contents

Advertisement

Quick Links

Operator's Manual / Manual del usuario
EN p. 2
ES p. 46
NOTICE:
Only use unleaded gasoline containing up to 10% ethanol. Do not use E15 or E85 fuel in this trimmer.
It will violate the federal law, damage the trimmer and void your warranty.
AVISO:
Utilice solo gasolina sin plomo que contenga un máximo de 10 % de etanol. No utilice combustible
E15 o E85 con esta bordeadora. Esto violará la ley federal, dañará la bordeadora y anulará su
garantía.
Read all safety rules and instructions carefully before operating this tool.
601 Regent Park Court Greenville, SC 29607, SC 29650 1-866-384-8432
Lea con cuidado todas las reglas e instrucciones de seguridad antes de utilizar esta herramienta.
601 Regent Park Court Greenville, SC 29607, SC 29650 1-866-384-8432
26cc 2-Cycle Grass Trimmer NPTGSP2617A
Bordeadora con Motor de 2 Tiempos de 26 cc NPTGSP2617A

Advertisement

Table of Contents
loading

Related Manuals for LawnMaster NPTGSP2617A

Summary of Contents for LawnMaster NPTGSP2617A

  • Page 1 EN p. 2 26cc 2-Cycle Grass Trimmer NPTGSP2617A ES p. 46 Bordeadora con Motor de 2 Tiempos de 26 cc NPTGSP2617A NOTICE: Only use unleaded gasoline containing up to 10% ethanol. Do not use E15 or E85 fuel in this trimmer.

  • Page 2: Table Of Contents

    CONTENTS Section Page CONTENTS PRODUCT SPECIFICATIONS GENERAL SAFETY RULES SYMBOLS 9-10 KNOW YOUR GRASS TRIMMER 11-16 ASSEMBLY 17-18 BATTERY PACK AND CHARGER 19-27 OPERATION 28-35 MAINTENANCE ENVIRONMENTALLY SAFE BATTERY DISPOSAL 37-38 TROUBLESHOOTING WARRANTY EXPLODED VIEW PARTS LIST EXPLODED VIEW 26CC 2-CYCLE ENGINE PARTS LIST 26CC 2-CYCLE ENGINE 44-45 NOTES...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES WARNING READ ALL INSTRUCTIONS AND SAVE THESE INSTRUCTIONS. Read the Operator’s Manual and follow all warnings and safety instructions. Failure to do so can result in serious injury to the operator and/or bystanders. use in agricultural or forest environments. example: - Hedges, shrubs and bushes, - Flowers,...
  • Page 4 GENERAL SAFETY RULES exposure to hot surfaces. control of the tool. Do not use the trimmer whilst on a ladder or other unstable support. cutting attachment and hot surfaces. after the trimmer has been used. Contact with hot surfaces could result in serious burns. equipment and observe all safety instructions.
  • Page 5 GENERAL SAFETY RULES from the battery may cause irritation or burns. dropped or received a sharp blow. A damaged battery is subject to explosion. Properly dispose of a dropped or damaged battery immediately. contact with your skin, wash immediately with soap and water, then neutralize with lemon juice or immediate medical attention.
  • Page 6 GENERAL SAFETY RULES identical model as listed in this manual. another battery pack. FCC COMPLIANCE conditions: - This device may not cause harmful interference, and - This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Symbols

    SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. NAME DESIGNATION/EXPLANATION SYMBOL Volts Voltage Amperes Current Hertz Frequency (cycles per second)
  • Page 8 SYMBOLS Do not dispose of battery packs in rivers or immerse in Keep Away From Water water. Do not dispose of battery packs in fire. They will Keep Away From Fire explode or leak and cause injury. Do not expose battery packs to heat in excess of Heat Alert 140°F (60°C).

  • Page 9: Know Your Grass Trimmer

    KNOW YOUR GRASS TRIMMER...
  • Page 10 KNOW YOUR GRASS TRIMMER The safe use of this product requires an understanding of the information on the product and in this Operator’s Manual as well as knowledge of the project you are attempting. Before use of this product, familiarize yourself with all operating features and safety rules. Components 1.

  • Page 11: Assembly

    ASSEMBLY This product requires assembly. the packing list are included. the product. PACKING LIST (1) Trimmer Assembly (with assist handle installed) (1) Straight Shaft Attachment (with trimmer head and line spool installed) (1) Debris Guard (1) Socket Wrench / Cross-head Screwdriver (1) Spanner (2) Hex Wrenches (1) Operator's Manual...
  • Page 12 ASSEMBLY FITTING THE DEBRIS GUARD (See Figs. 1-2) WARNING the blade. Failure to avoid contact can result in serious personal injury. washer and screw. Hole on the Hole on the mounting debris guard Tab bracket Slot Fig. 1 Fig. 2 INSTALLING AND REMOVING THE SHAFT (See Figs.
  • Page 13 ASSEMBLY Fig. 3 sleeve. Slide the shaft into the shaft connection sleeve until the button locks into the positioning hole (Fig. 4). NOTE: If the button does not release completely in the positioning hole, the shaft is not locked into place. Slightly rotate from side to side until the button is locked into place.
  • Page 14 ASSEMBLY To remove the battery pack: Ⅰ Ⅱ WRONG Fig. 6 Fig. 7 ADJUSTING THE ASSIST HANDLE (See Figs. 8-9) WARNING Never adjust the assist handle while the trimmer head is running. Failure to stop the engine may cause serious personal injury. The assist handle is pre-installed at delivery.
  • Page 15 ASSEMBLY INSTALLING THE SHOULDER STRAP (SOLD SEPARATELY) (See Figs. 10-14) A removable shoulder strap and shoulder strap clasp (not included) are sold separately for your convenience. Use of a shoulder strap is recommended for trimmer and brush cutter use. engine). 10).
  • Page 16 ASSEMBLY Check to ensure the shoulder strap is attached securely (Fig. 13). Ring Release latch Fig. 13 the tab, and the machine will drop away from you (Fig. 14). Rope Fig. 14...

  • Page 17: Battery Pack And Charger

    BATTERY PACK AND CHARGER BATTERY CHARGING ® YLS0042-T084045 battery charger. The battery charger supplied other heat sources. Do not leave the battery in the tool in direct sunlight over long periods. The lithium-ion battery can be charged at any time without reducing its service life. Interrupting the charging procedure does not affect the battery.
  • Page 18 BATTERY PACK AND CHARGER supply. Fig. 15 Fig. 16 NOTE: It is normal for the battery pack and the charger to become warm (but not hot) during the charging process. If the battery does not charge properly, check to make sure the electrical outlet is operational. Always...

  • Page 19: Operation

    OPERATION WARNING Do not allow familiarity with products to make you careless. Remember that a careless fraction of a WARNING protection. Failure to do so could result in objects being thrown into your eyes and other possible serious injuries. WARNING Do not use any attachments or accessories not recommended by the manufacturer or retailer of this product.
  • Page 20 DO NOT prepare quantities that will need to be stored for more than 30 days. Recommended Fuel U.S. EPA regulations make it illegal to use gasoline containing higher than 10% ethanol content ® in outdoor power equipment like your LawnMaster power equipment and doing so can void your ® LawnMaster Limited Warranty.
  • Page 21 OPERATION FILLING THE FUEL TANK (See Fig. 18) NOTICE: Before each use, ALWAYS shake the fuel container thoroughly to ensure that the fuel is mixed completely. Gasket Fig. 18 replacing the cap onto the fuel tank. and inspecting the tank. Check that the cap is sealed tightly and wipe clean any spillage that may have occurred.
  • Page 22 OPERATION BALANCING THE GRASS TRIMMER (See Figs. 19-20) If the shoulder strap clasp and shoulder strap (sold separately) are used for your convenience, balance the grass trimmer before starting the trimmer. hangs freely above the ground. The cutting head should just touch the ground (Fig. 20). Fig.
  • Page 23 OPERATION engage the throttle safety and the throttle trigger to start the trimmer (Fig. 22 - 25). The choke lever will automatically switch to RUN position. START Fig. 22 Fig. 23 Fig. 24 Fig. 25 NOTE: If the engine does not start, repeat step 5 until the engine starts. NOTE: This 2-cycle grass trimmer is equipped with an automatic choke reset.
  • Page 24 OPERATION To stop the trimmer: Press the STOP switch to the stop position “O” until the trimmer stops (Fig. 26). STOP Fig. 26 (See Fig. 27) A battery power indicator is located above the start button, and can be used to indicate the battery status (Fig.
  • Page 25 OPERATION WARNING Always position the trimmer on your right side in order to reduce exposure to hot surfaces which can cause possible serious injuries. WARNING Keep the bottom of the engine below waist level during operation to avoid burns from hot surfaces. hand on the assist handle.
  • Page 26 OPERATION TRIMMING TIPS (See Figs. 28-29) surfaces (Fig. 28). this direction will reduce the amount of debris thrown towards the operator. Avoid cutting in the dangerous area as shown (Fig. 29). borders, curbs and walls made of metal, wood, stone and brick. Avoid using the trimmer against these materials.
  • Page 27 OPERATION To advance the cutting line manually: NOTE: After each use, clean the trimmer head with a damp cloth to remove dirt and grime. CUTTING BLADE (See Fig. 31) The trimming line cutting blade is attached to the underside of the debris guard (Fig. 31). The cutting blade trims the line at a length that yields optimum cutting results.

  • Page 28: Maintenance

    MAINTENANCE Normal maintenance, replacement or repair of emission control devices and systems may be assistance or Customer Service (Toll Free Number 866-384-8432). WARNING When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage.
  • Page 29 MAINTENANCE BATTERY MAINTENANCE not allow the battery pack to become completely discharged. charger from the outlet. hot, allow it to cool down before charging. Storing the battery for 30 days or longer: If the lithium-ion battery is being stored for 30 days or longer, store the battery pack in a location where the temperature does not exceed 80°F (26°C) and is free of moisture.
  • Page 30 MAINTENANCE the locking tabs on the trimmer head housing as shown. Then press the locking tabs and push the trimmer head cover onto the trimmer head housing. Make sure they are secured tightly (Fig. 34). Ⅱ Ⅰ Ⅰ Locking tabs on the trimmer head housing Fig.
  • Page 31 MAINTENANCE Fig. 37 NOTE: Always clean the trimmer head cover and trimmer head housing before reassembling the trimmer head. NOTE: Always clean the trimmer head before replacing the spool. necessary. NOTE: TRIMMER HEAD REPLACEMENT (See Fig. 38) trimmer head clockwise to remove (Fig. 38). head counter-clockwise to install.
  • Page 32 MAINTENANCE NOTICE: The spark arrestor on this product has not been evaluated by the USDA Forest Service and cannot be used on U.S. forest lands. In addition, product users must comply with Federal, State, and local authorized service center to purchase a replacement spark arrestor. amount of lubricant used, or the operating conditions.
  • Page 33 MAINTENANCE NOTE: correctly will decrease the chances of engine wear caused by dirt entering the engine (Fig. 41). Fig. 41 Fig. 42 DANGER WARNING damaged tank caps, or leaking tanks must be replaced immediately. Failure to follow this instruction may lead to serious personal injury. Use a clean cloth to remove loose dirt from around the fuel tank cap and empty the fuel tank.
  • Page 34 MAINTENANCE the socket wrench counter-clockwise to remove the spark plug (Fig. 44). a new one. DO NOT use a blowing tool to clean as the movement of dirt may damage the engine. Fig. 43 Fig. 44 Outer Electrode 0.026 in. (0.65 mm) Fig.
  • Page 35 MAINTENANCE STORAGE Clean the trimmer of any debris and store indoors in a dry, well-ventilated area that is inaccessible to children. Keep away from corrosive agents such as garden chemicals and de-icing salts. Abide by all ISO and local regulations for the safe storage and handling of gasoline. Storing for 30 days or longer: Drain all the fuel from the tank into a container approved for storing gasoline.

  • Page 36: Environmentally Safe Battery Disposal

    ENVIRONMENTALLY SAFE BATTERY DISPOSAL The following toxic and corrosive materials are in the batteries used in this battery pack: WARNING environment. Before disposing of damaged or worn out lithium-ion battery packs, contact your local instructions. WARNING If the battery pack cracks or breaks, with or without leaks, do not recharge it and do not use. Dispose of it and replace with a new battery pack.

  • Page 37: Troubleshooting

    TROUBLESHOOTING If your grass trimmer does not appear to operate properly, follow the instructions below. If this does not solve the problem, please contact your local repair agent. WARNING Before proceeding, shut off the engine, wait for all moving parts to stop, and remove the battery pack. Failure to follow these instructions can result in serious personal injury or property damage.
  • Page 38 TROUBLESHOOTING Air Filter section in this manual. Clean or replace the spark plug. Reset the spark plug gap. Refer to the Spark The spark plug is worn out. Plug Replacement section in this manual. Allow the engine to run at idle for 5 The engine overheats.

  • Page 39: Warranty

    No-Pull LIMITED WARRANTY ® We take pride in producing a high quality, durable product. This LawnMaster product carries a limited three (3) year warranty against defects in workmanship and materials from date of purchase under normal household use. This product carries a ninety (90) day warranty from the date of purchase when used for commercial or rental purposes.

  • Page 40: Exploded View

    EXPLODED VIEW NPTGSP2617A EXPLODED VIEW...

  • Page 41: Parts List

    PARTS LIST NPTGSP2617A MANUAL PARTS LIST Key Number Part Number Description Quantity 321001101 Cleva 26cc 2-Cycle Engine 321001102 Throttle-body & Starter Set 321001103 Throttle-body Set 321001104 Starter Set 2.2.2 321001106 Starter Switch Assembly 2.2.3 321001107 Stop Switch Set 2.2.4 321001108...

  • Page 42: Exploded View 26Cc 2-Cycle Engine

    EXPLODED VIEW 26CC 2-CYCLE ENGINE...

  • Page 43: Parts List 26Cc 2-Cycle Engine

    PARTS LIST 26CC 2-CYCLE ENGINE 26CC 2-CYCLE ENGINE PART LIST Key Number Part Number Description Quantity 321001130 Spark Plug Cover 321001131 321001132 Upper Engine Cover 321001133 Logo 321001134 321001135 Cylinder Assembly 321001136 321001137 321001138 Insulation Sheet 321001139 Spark Plug 321001140 Crankcase Assembly 321001141 Ignition Coil Assembly...

  • Page 44: Notes

    NOTES...
  • Page 45 NOTES...
  • Page 46 CONTENIDO Sección Página Contenido ESPECIFICACIONES DEL PRODUCTO BORDEADORA CON MOTOR DE 2 TIEMPOS DE 26 cc...
  • Page 47 REGLAS GENERALES DE SEGURIDAD ADVERTENCIA LEA TODAS LAS INSTRUCCIONES Y GUARDE ESTAS INSTRUCCIONES.
  • Page 48 REGLAS GENERALES DE SEGURIDAD BATERÍA...
  • Page 49 REGLAS GENERALES DE SEGURIDAD CARGADOR DE LA BATERÍA...
  • Page 50 REGLAS GENERALES DE SEGURIDAD CUMPLIMIENTO FCC NOTA: ADVERTENCIA GUARDE ESTAS INSTRUCCIONES...
  • Page 51 SÍMBOLOS Algunos de los siguientes símbolos podrían aparecer en este producto. Estúdielos y aprenda su significado. La interpretación adecuada de estos símbolos le permitirá utilizar el producto de mejor manera y con más seguridad. NOMBRE DESIGNACIÓN/EXPLICACIÓN SÍMBOLO Voltios Voltaje Amperes Corriente Hertz Frecuencia (ciclos por segundo)
  • Page 52 SÍMBOLOS Mantener alejado del No elimine las baterías lanzándolas a ríos ni las agua sumerja en agua. No elimine las baterías utilizando fuego. Explotarán o Mantener alejado del tendrán fugas y provocarán lesiones. fuego No exponga baterías a un calor mayor a Alerta de calor 140°F (60°C).
  • Page 53 CONOZCA SU BORDEADORA...
  • Page 54 CONOZCA SU BORDEADORA Componentes...
  • Page 55 MONTAJE LISTA DE PIEZAS INCLUIDAS ADVERTENCIA ADVERTENCIA ADVERTENCIA...
  • Page 56 MONTAJE INSTALACIÓN DEL PROTECTOR CONTRA SEDIMENTOS (Consulte las Figuras 1-2) ADVERTENCIA Orificio de la Orificio en la abrazadera protección Leng Ranu Fig. 1 Fig. 2 INSTALACIÓN Y EXTRACCIÓN DEL EJE (Consulte las Figuras 3-5) ADVERTENCIA Para instalar el eje:...
  • Page 57 MONTAJE Fig. 3 NOTA: Ⅰ Ⅱ Apriete Suelte Botón Orificio de posicionamiento Fig. 4 Fig. 5 ADVERTENCIA Para quitar el eje: INSTALACIÓN Y EXTRACCIÓN DE LA BATERÍA (Consulte las Figuras 6-7) Instale el paquete de baterías:...
  • Page 58 MONTAJE Extracción de la batería: Ⅰ Ⅱ Incorrecto Fig. 6 Fig. 7 AJUSTE DE LA MANILLA DE APOYO (Consulte las Figuras 8-9) ADVERTENCIA...
  • Page 59 MONTAJE Fig. 8 Fig. 9 INSTALACIÓN DE LA CORREA PARA EL HOMBRO (SE VENDE POR SEPARADO) (Consulte las Figuras 10-14) Fig. 10...
  • Page 60 MONTAJE Gancho Hebilla Pestillo de liberación Fig. 11 Fig. 12 Anillo Pestillo de Hebilla liberación Fig. 13 Cuerda Fig. 14...
  • Page 61 BATERÍA Y CARGADOR CARGA DE LA BATERÍA LED DE CARGA LUCES INDICADORAS ESTADO CÓMO CARGAR LA BATERÍA (Consulte las Figuras 15-16) ADVERTENCIA...
  • Page 62 BATERÍA Y CARGADOR Fig. 15 Fig. 16 NOTA:...
  • Page 63 FUNCIONAMIENTO ADVERTENCIA ADVERTENCIA ADVERTENCIA TRATAR CON EL COMBUSTIBLE PELIGRO combustible para que la presión se iguale. ¡JAMÁS reposte una bordeadora con el motor CALIENTE o ANDANDO!
  • Page 64 FUNCIONAMIENTO combustible después de repostar. MEZCLA DE COMBUSTIBLE (Consulte la Figura 17) Combustible recomendado NOTA: GASOLINA LUBRICANTE...
  • Page 65 FUNCIONAMIENTO Fig. 17 LLENADO DEL TANQUE DE COMBUSTIBLE (Consulte la Figura 18) AVISO: Empaquetadura Fig. 18 AVISO:...
  • Page 66 FUNCIONAMIENTO ADVERTENCIA EQUILIBRIO DE LA BORDEADORA (Consulte las Figuras 19-20) Fig. 19 Fig. 20...
  • Page 67 FUNCIONAMIENTO ARRANQUE Y DETENCIÓN DE LA BORDEADORA (Consulte las Figuras 21- CHOKE Fig. 21 START Fig. 22 Fig. 23 Fig. 24 Fig. 25 NOTA: NOTA:...
  • Page 68 FUNCIONAMIENTO NOTA: Para un arranque en caliente: Para detener la bordeadora: STOP Fig. 26 INDICADOR DE POTENCIA DE LA BATERÍA (Consulte la Figura 27) Indicador potencia de la batería Fig. 27...
  • Page 69 FUNCIONAMIENTO SUGERENCIA PARA UN USO ÓPTIMO CORTE (Consulte la Figura 28) ADVERTENCIA ADVERTENCIA ADVERTENCIA Fig. 28...
  • Page 70 FUNCIONAMIENTO CONSEJOS DE USO (Consulte las Figuras 28-29) A - Dirección de giro B - Zona de corte peligrosa Fig. 22 C - Mejor área de corte AVANCE DE LA LÍNEA (Consulte la Figura 30)
  • Page 71 FUNCIONAMIENTO AVISO: AVISO: Fig. 30 NOTA: HOJA DE CORTE (Consulte la Figura 31) Hoja de corte de hilo Fig. 24...
  • Page 72 MANTENIMIENTO ADVERTENCIA ADVERTENCIA ADVERTENCIA AVISO: MANTENIMIENTO GENERAL...
  • Page 73 MANTENIMIENTO ADVERTENCIA MANTENIMIENTO DE LA BATERÍA Para almacenar la batería durante 30 días o más: MANTENIMIENTO DEL CARGADOR CAMBIO DEL CARRETE (Consulte las Figuras 32-34)
  • Page 74 MANTENIMIENTO NOTA: Ⅱ Lengüetas de la carcasa del Ⅰ cabezal de la Fig. 25 Fig. 26 bordeadora Ⅱ Ⅰ Lengüetas de la Ⅰ carcasa del cabezal de la bordeadora Fig. 27 CAMBIO DEL HILO (Consulte las Figuras 35-37) NOTA:...
  • Page 75 MANTENIMIENTO Fig. 35 Fig. 36 Fig. 37 NOTA: NOTA: NOTA: REINSTALACIÓN DEL CABEZAL DE LA BORDEADORA (Consulte la Figura...
  • Page 76 MANTENIMIENTO Fig. 38 DE CHISPAS AVISO: AJUSTE DE LA VELOCIDAD EN RALENTÍ ADVERTENCIA...
  • Page 77 MANTENIMIENTO LIMPIEZA DEL FILTRO DE AIRE (Consulte las Figuras 39-42) Tapa del filtro Tapa del filtro de aire Perilla de aire Filtro de del filtro de aire Cerrado Abier Fig. 33 Fig. 32 NOTA: Fig. 41 Fig. 42...
  • Page 78 MANTENIMIENTO PELIGRO almacenarlo o manipularlo. No seguir estas instrucciones podría causar lesiones personales ADVERTENCIA CAMBIO DE LA BUJÍA (Consulte las Figuras 43-46)
  • Page 79 MANTENIMIENTO Fig. 43 Fig. 44 Electrodo exterior 0.026 in. (0.65 mm) Fig. 45 Fig. 46 AVISO: LUBRICACIÓN (Consulte la Figura 47) Fig. 47...
  • Page 80 MANTENIMIENTO ALMACENAMIENTO Almacenamiento durante 30 días o más: FUNCIONAMIENTO DEL MOTOR EN LUGARES DE GRAN ALTITUD ESTE PRODUCTO SE FABRICÓ CON UN CONVERTIDOR CATALÍTICO ¡Felicidades! PROGRAMA DE MANTENIMIENTO Inspeccione Limpie Cambie Cambie cada 25 que no haya cada 5 cada 50 Pieza de mantenimiento horas de daños antes...
  • Page 81 ELIMINACIÓN AMBIENTALMENTE SEGURA DE LA BATERÍA un material tóxico. ADVERTENCIA ADVERTENCIA ¡NO INTENTE REPARARLA!
  • Page 82 RESOLUCIÓN DE PROBLEMAS ADVERTENCIA PROBLEM POSSIBLE CAUSE SOLUTION...
  • Page 83 TROUBLESHOOTING...
  • Page 84 Cobros por transporte: Los cobros por transporte para cualquier unidad o aditamento son responsabilidad del comprador. Es responsabilidad del comprador pagar los cobros por transporte de ® cualquier pieza enviada a cambio bajo esta garantía, a menos que LawnMaster haya requerido tal devolución por escrito.
  • Page 85 VISTA EN DETALLE NPTGSP2617A VISTA EN DETALLE...
  • Page 86 LISTA DE PIEZAS LISTA DE PIEZAS DE LA BORDEADORA NPTGSP2617A Descripción Cantidad...
  • Page 87 VISTA EN DETALLE DEL MOTOR DE 2 TIEMPOS DE 26 CC...
  • Page 88 LISTA DE PIEZAS DEL MOTOR DE 2 TIEMPOS DE 26 CC LISTA DE PIEZAS DEL MOTOR DE 2 TIEMPOS DE 26 CC Descripción Cantidad Logo...
  • Page 89 NOTAS...
  • Page 90 NOTAS...
