Integral Audio PHANTOM Installation Manual page 5

A.
5
1. REMOVE TRUNK FLOOR PANEL
Remove the trunk floor panel.
2. REMOVE BATTERY COMPARTMENT COVER
Remove battery cover by turning the locking knob and lifting out
the cover.
3. REMOVE THE SIDE FLOOR TRIM PANEL
Remove the side floor trim panel by lifting up on the forward por-
tion, lift clear and remove.
4. MOUNT THE SUBWOOFER INTO THE ENCLOSURE
Subwoofer Internal Wiring Harness [F30.WH.SUB-INT]
Connect the
Neutrik terminal
to the in the enclosure. Note polarity markings
Neutrik terminal
on the ! Connect the other end to the subwoofer.
Mount the subwoofer to the enclosure using the eight
1" Button Head Cap Screws
Insert the speaker grille over and around the subwoofer gasket.
5. SUBWOOFER WIRING (NEUTRIK PLUG)
Subwoofer Wiring Pigtail
Select the 3ft long
Hardware Kit.
Connect the
subwoofer wire. Slide the blue chuck (1) over the wire, followed
by the strain-relief bushing (2). Make the positive & negative con-
nections to the plug as shown, tighten the terminals with a small
Phillips screwdriver. Slide the bushing (2) forward and tighten the
chuck (3) onto the plug (3).
and tighten with a 1/8" Allen wrench.
from the
Neutrik Speak-on Plug
to one end of the
#10-24 x
Subwoofer
