INSTALLATION GUIDE
PHANTOM
FOR 2012+ BMW 3 & 4-SERIES (F30/F80/F32/F82)
SKILL LEVEL REQUIRED
DO-IT-YOURSELF
INSTALLATION DIFFICULTY
2 OUT OF 5
INSTALLATION TIME
1.5 HOURS
SUBWOOFER SYSTEM
TM
BEFORE YOU BEGIN .......................................................................................................................... 2
WHAT'S IN THE BOX........................................................................................................................... 3
TOOLS YOU WILL NEED ...................................................................................................................... 5
INSTALLATION:
A. Prep Vehicle ........................................................................................................................ 6
B. Subwoofer ......................................................................................................................... 20
NOTES & TIPS.................................................................................................................................. 28
TROUBLESHOOTING ......................................................................................................................... 28
APPLIES TO
ver. 5/20
2012+ F30 SEDAN
2012+ F80 M3
2012+ F32 COUPE
2012+ F82 M4
Advertisement
Related Manuals for Integral Audio PHANTOM
Summary of Contents for Integral Audio PHANTOM
- Page 1 INSTALLATION GUIDE PHANTOM SUBWOOFER SYSTEM FOR 2012+ BMW 3 & 4-SERIES (F30/F80/F32/F82) ver. 5/20 2012+ F30 SEDAN SKILL LEVEL REQUIRED APPLIES TO 2012+ F80 M3 DO-IT-YOURSELF 2012+ F32 COUPE 2012+ F82 M4 INSTALLATION DIFFICULTY 2 OUT OF 5 INSTALLATION TIME 1.5 HOURS...
- Page 2 IMPORTANT • Read this Guide completely BEFORE you begin. • Disconnect the battery negative terminal while working on the vehicle. • DO NOT PLACE THE KEY FOB in the vehicle with the battery connected and the seat airbag wiring disconnected. Doing so will set off the airbag light, and must be reset by your dealer.
- Page 3 I. INTEGRAL AUDIO PHANTOM™ SUBWOOFER 1. Phantom™ Subwoofer Enclosure 2. Integral Audio Soundstage Series 10” Subwoofer II. SUBWOOFER HARDWARE 3. Subwoofer Mounting Bracket & Hardware 4. Subwoofer Support Bracket & Hardware 5. Neutrik Quick-connect Subwoofer Terminal & Wiring 6. Subwoofer Cover Grille...
-
Page 4: Tools You Will Need
I. TOOLS YOU WILL NEED: 1. Wrenches or Socket Driver & Sockets: • 10mm deep socket 2. Torx Bits: • T40 3. Screwdrivers: • Small Slotted & Phillips 4. Plastic Panel Removal Tool(s) 5. 1/8” Allen (Hex) Wrench 6. Magnetic Parts Tray [Optional] Images Not to Scale... - Page 5 1. REMOVE BATTERY COVER Remove battery cover by turning the locking knob and lifting out the cover. 2. DISCONNECT BATTERY NEGATIVE TERMINAL Disconnect battery negative terminal with 10mm deep socket. 3. REMOVE TRUNK FLOOR PANEL Remove the trunk floor panel. 4.
- Page 6 6. REMOVE TRUNK REAR SILL Remove the trunk rear sill by removing the (4) center pin expan- sion clips along the inner side. Lift the lower front edge of the sill forward to clear the D-rings, then give a firm lift up to release the friction clips holding the upper portion.
- Page 7 11. REMOVE DRIVER-SIDE REAR QUARTER PANEL TRIM (STEP 4) Then locate & remove the one on the forward edge of the panel, by the rear seat back. 12. REMOVE DRIVER-SIDE REAR QUARTER PANEL TRIM (STEP 5) Now remove the trim panel. Start at the forward edge. Lift clear/ free the forward edge from behind the trim at the sides of the rear seat backs and pull the panel out 4-6 inches.
-
Page 8: Subwoofer Installation
16. LOOSEN WIRE BUNDLE Loosen/free the 12V power outlet wire bundle by sliding the plas- tic retaining clip off the mounting stud. 17. SUBWOOFER INSTALLATION IASW10T4 Subwoofer, Subwoofer Enclosure, Subwoofer Locate the Hardware Kit, Speaker Grille. 18. MOUNT THE SUBWOOFER IN THE ENCLOSURE Subwoofer Internal Wiring Harness [F30.WH.SUB-INT] Connect the Neutrik terminal... - Page 9 21. SUBWOOFER MOUNTING BRACKET Clip On Nuts Slide the two (1) over the holes in the uprights in the Subwoofer Mounting Bracket . Slide the clips on over the outer edge. The holes in the clips should align with the holes in the bracket. 1/4”...
-
Page 10: Connect Subwoofer
26. REPLACE TRUNK TRIM PANEL Replace the rear quarter panel trim. Start by insterting the for- ward edge behind the trim at the side of the rear seat backs (1). Carefully open the slit in the panel (2) and place around the trunk lid support. - Page 11 FOB to have consistent sound. • PLEASE LISTEN RESPONSIBLY: Your new Integral Audio system is capable of delivering Sound Pressure Levels that can damage your hearing. It also delivers very clean, low-distortion sound reproduction.
