Integral Audio 1100S Installation Manual

Mini cooper hardtop 2007+ (r56) subwoofer system

Advertisement

Quick Links

INSTALLATION GUIDE
MINI Cooper Hardtop 2007+ (R56)
Model 1100S Subwoofer System
The MC1100S Subwoofer enclosure installs in the
floor of the luggage compartment (boot). The ampli-
fier installs behind the trim panel on the right side of
the boot.
Vehicles equipped with the Digital Tuner option will
need to install the amplifier under the front seat (con-
tact us for more info).
!
IMPORTANT
Read this Installation Guide Carefully and Completely before proceeding.
Disconnect Negative Battery Terminal before beginning work.
This is a guide - your vehicle may vary. ALWAYS check behind panels,
etc. before drilling or screwing into any part of a vehicle.
You are responsible for your own vehicle - use your brain and be careful!
INSTALLATION
DIFFICULTY
3
OUT OF
5
Contents
WHAT'S INCLUDED & WHAT YOU WILL NEED ................................... 2
INSTALLATION:
A. PREP THE VEHICLE .................................................................... 3
C. SIGNAL WIRING (BASE STEREO) .............................................. 5
D. SIGNAL WIRING (HIFI) . ................................................................ 6
F. INSTALL ENCLOSURE MOUNTS . ............................................... 7
G. INSTALL ENCLOSURE ................................................................ 7
TROUBLESHOOTING ............................................................................ 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1100S and is the answer not in the manual?

Questions and answers

Summary of Contents for Integral Audio 1100S

  • Page 1: Table Of Contents

    Contents WHAT’S INCLUDED & WHAT YOU WILL NEED ........2 INSTALLATION: INSTALLATION GUIDE A. PREP THE VEHICLE ..............3 MINI Cooper Hardtop 2007+ (R56) B. RUN THE POWER & GROUND WIRES ........3 Model 1100S Subwoofer System C. SIGNAL WIRING (BASE STEREO) ..........5 D. SIGNAL WIRING (HIFI) ..............6 E. AMPLIFIER MOUNTING & CONNECTIONS ........ 6 F. INSTALL ENCLOSURE MOUNTS ..........7 G. INSTALL ENCLOSURE ..............7 H. TESTING & RECOMMENDED SETTINGS ........8 TIPS & TUNING ..................9 The MC1100S Subwoofer enclosure installs in the INSTALLATION TROUBLESHOOTING ................9 floor of the luggage compartment (boot). The ampli- DIFFICULTY fier installs behind the trim panel on the right side of OUT OF the boot.
  • Page 2 WHAT’S INCLUDED: WHAT YOU WILL NEED: 1. Integral Audio Model 1100S Subwoofer Enclosure • Wire Stripper/Crimper • Torx T50 2. Integral Audio IASW26-4 10” Subwoofer • Flat Screwdriver 3. ARC Audio KS125.2 MINI Amplifier • Small Phillips Screwdriver 4. R56 False Floor Panel • Electric Drill • Drill bits: 1/8”, 7/16”...
  • Page 3: Prep The Vehicle

    Unplug the light. where it passes through the rear of the door sill trim. CAUTION: the light may be hot! NOTE: Left (Driver’s) side shown, but the procedure is the same for left & right sides. 3 | Integral Audio | Installation Instructions Continued on next page...
  • Page 4 Rear Right Side Panel and up to the Door Sill, then use it to pull the Power Wire to the luggage compartment area. NOTE: Leave enough slack in the wire to be able to reinstall the Thru-wall cover. 4 | Integral Audio | Installation Instructions Continued on next page...
  • Page 5: Signal Wiring (Base Stereo)

    Use pliers to make it easier to lock the Repeat Steps 8-10 for the left side of the vehicle. tap onto the wire. Double-check that you are selecting the correct wires by verifying the Pin location. Attach See Steps 8-10 the correct Signal Wire to each T-tap. 5 | Integral Audio | Installation Instructions Continued on next page...
  • Page 6: Signal Wiring (Hifi)

    At the end near the factory (bridged). Attach the Banana Plugs to the other end. amplifier, carefully crimp a ¼” Insulated Male Quick (no image) Disconnect on each wire, 5 total. Solder the connec- tions if desired. 6 | Integral Audio | Installation Instructions Continued on next page...
  • Page 7: Install Enclosure Mounts

    “star” pattern, go slowly and take care not to strip center as a stop for the drill. them. Make sure the speaker is mounted flush - the gasket on the back of the speaker flange should seal. 7 | Integral Audio | Installation Instructions Continued on next page...
  • Page 8: Testing & Recommended Settings

    Contact us if you are having difficulty or something • Crossover: 90 Hz and remove - Clean, Simple, Easy! doesn’t sound right. • Bass Boost: 0 • Input: Speaker Level In (button IN) • Factory Radio Bass Level: -1 • Factory Radio Fade: Front +3 8 | Integral Audio | Installation Instructions Continued on next page...
  • Page 9: Tips & Tuning

    FOB to have consistent sound. TROUBLESHOOTING Having Trouble? The best thing to do is contact us at support@integralaudio.com or via the phone number listed on the receipt that was emailed to you. We’ll get you fixed up! www.integralaudio.com All specifications are subject to change without notice. Integral Audio® and the Integral Audio logo, are registered trademarks of Integral Audio. For more detailed information please visit us online at www.integralaudio.com. 9 | Integral Audio | Installation Instructions...
