INSTALLATION GUIDE
PHANTOM
FOR 2014+ BMW 4-SERIES GRAN COUPE (F36)
SKILL LEVEL REQUIRED
DO-IT-YOURSELF
INSTALLATION DIFFICULTY
2 OUT OF 5
INSTALLATION TIME
1 HOUR
SUBWOOFER SYSTEM
TM
BEFORE YOU BEGIN .......................................................................................................................... 2
WHAT'S IN THE BOX........................................................................................................................... 3
TOOLS YOU WILL NEED ...................................................................................................................... 5
INSTALLATION:
A. Prep Vehicle ........................................................................................................................ 6
B. Subwoofer ......................................................................................................................... 20
NOTES & TIPS.................................................................................................................................. 28
TROUBLESHOOTING ......................................................................................................................... 28
APPLIES TO
ver. 5/20
2014+ F36 GRAN COUPE
Advertisement
Related Manuals for Integral Audio PHANTOM
Summary of Contents for Integral Audio PHANTOM
- Page 1 INSTALLATION GUIDE PHANTOM SUBWOOFER SYSTEM FOR 2014+ BMW 4-SERIES GRAN COUPE (F36) ver. 5/20 2014+ F36 GRAN COUPE SKILL LEVEL REQUIRED APPLIES TO DO-IT-YOURSELF INSTALLATION DIFFICULTY 2 OUT OF 5 INSTALLATION TIME 1 HOUR BEFORE YOU BEGIN .......................... 2 WHAT’S IN THE BOX........................... 3 TOOLS YOU WILL NEED ........................
- Page 2 IMPORTANT • Read this Guide completely BEFORE you begin. • Disconnect the battery negative terminal while working on the vehicle. • DO NOT PLACE THE KEY FOB in the vehicle with the battery connected and the seat airbag wiring disconnected. Doing so will set off the airbag light, and must be reset by your dealer.
- Page 3 I. INTEGRAL AUDIO PHANTOM™ SUBWOOFER 1. Phantom™ Subwoofer Enclosure [F36.SUB10] 2. Integral Audio Soundstage Series 10” Subwoofer [IA26W4558T03] II. SUBWOOFER HARDWARE 3. Subwoofer Mounting Bracket & Hardware 4. Subwoofer Support Bracket & Hardware 5. Neutrik Quick-connect Subwoofer Terminal & Wiring...
-
Page 4: Tools You Will Need
I. TOOLS YOU WILL NEED: 1. Wrenches or Socket Driver & Sockets: • 10mm deep socket 2. Torx Bits: • T40 3. Screwdrivers: • Small Slotted & Phillips 4. Plastic Panel Removal Tool(s) 5. 1/8” Allen (Hex) Wrench 6. Magnetic Parts Tray [Optional] Images Not to Scale... - Page 5 1. REMOVE TRUNK FLOOR PANEL Remove the trunk floor panel. 2. REMOVE BATTERY COMPARTMENT COVER Remove battery cover by turning the locking knob and lifting out the cover. 3. REMOVE THE SIDE FLOOR TRIM PANEL Remove the side floor trim panel by lifting up on the forward por- tion, lift clear and remove.
- Page 6 6. SUBWOOFER MOUNTING BRACKET (STEP 1) Cage Nuts Insert the two (1) into the holes in the uprights in the Subwoofer Mounting Bracket Cage Nut . Pinch the clips with pliers Cage Nuts to insert. The insert from the REAR side of the bracket. The bracket holes are slotted to allow for side-to-side adjustment if needed.
- Page 7 11. INSTALL SUBWOOFER ENCLOSURE Connect the Neutrik connector. Install the enclosure by placing the bottom front edge into the slot in the Floor Side Trim Panel with the top of the enclosure leaning forward, then rotate/tilt the top of the enclosure into place. Domed Logo Badge Affix the to the subwoofer grille.
- Page 11 FOB to have consistent sound. • PLEASE LISTEN RESPONSIBLY: Your new Integral Audio system is capable of delivering Sound Pressure Levels that can damage your hearing. It also delivers very clean, low-distortion sound reproduction.
