- Page 1 ULTRAbloc 320 JBOD Quick Installation Guide P/N: MAN-SC2100-QUIK Revision: 1.7 September 2003 Unpacking and Installation Cabling and Configuration Getting More Information...
-
Page 2: Section 1: Unpacking And Initial Setup
Section 1: Unpacking and Initial Setup NOTE: Before removing any of the components, ensure that anti-static precautions have been taken. The minimum requirement is an anti-static wrist strap and ground- ing wire. STEP 1. Remove all the components from the packaging and place on an anti-static surface until you are ready to use them. -
Page 3: Section 2: Cabling And Configuration
Section 2: Cabling and Configuration SCSI ID Assignments The SCSI ID’s for the ULTRAbloc Series enclosure are hard set and cannot be changed in anyway. The ULTRAbloc Series enclosure has two modes of operation: Single (Joined) SCSI bus mode (1x14), and Dual (Split) SCSI bus mode (1x7 and 1x7). - Page 4 ULTRAbloc Series JBOD Configurations STEP 1. Attach the cables provided with your ULTRAbloc Series enclosure. The illustrations below show the configurations and how to cable them. To Host ID 7 Single/Joined Mute SCSI Bus (Joiner Module may be used also) Disk Disk Disk...
- Page 5 NOTE: Both I/O modules are at ID 15. Only one module will be active at any one time and the other will be in standby mode. If the active I/O module fails the stand- by will take over. STEP 2. Attach the power cords provided, to the power connectors on each of the two power supplies on the rear of the enclosure.
- Page 6 ULTRAbloc Series Dual CSM Configuration STEP 1. Attach the cables provided with your ULTRAbloc Series enclosure. The illustration below shows how the configuration should be cabled. To Cluster 1 Slave Host To Cluster 2 Master Host To Cluster 2 Slave Host To Cluster 1 Master Host Bus B Bus A...
- Page 7 STEP 2. Attach the power cords provided, to the power connectors on each of the two power supplies on the rear of the enclosure. AC Power Connection Mute Insert Power cords into power connectors...
-
Page 8: Section 3: Getting More Information
Section 3: Getting More Information For more information on installing and configuring your ULTRAbloc Series Enclo- sure refer to the “ULTRAbloc 320 JBOD User Guide” (on the documentation CD). To obtain Technical Support for the ULTRAbloc Series contact our World Wide...
