Page 1: Quick Installation Guide
2Gb SANbloc Series Quick Installation Guide SAN bloc Series P/N: MAN-FC2002-QUIK Revision: 1.1 September 2003 Unpacking and Installation Cabling and Configuration Getting More Information... -
Page 2: Section 1: Unpacking And Initial Setup
Section 1: Unpacking and Initial Setup NOTE: Before removing any of the components, ensure that anti-static precautions have been taken. The minimum requirement is an anti-static wrist strap and ground- ing wire. STEP 1. Remove all the components from the packaging and place on an anti-static surface until you are ready to use them. -
Page 3: Section 2: Cabling And Configuration
Section 2: Cabling and Configuration Each of the fourteen disk drive slots of the 2Gb SANbloc Series has a unique iden- tifier assigned to it. This identifier is assigned using a combination of the Slot number and the enclosure ID. - Page 4 The fourteen disk drive slots (0 to 13), will be assigned an identifier based on the enclosure ID and the slot number as shown in the following table. Disk Drive Identifier Table Enclosure Drive Slot Slot 0 Slot 1 Slot 2 Slot 3 Slot 4 Slot 5...
- Page 5 WARNING: Only the following APPROVED cables must be used with the 2Gb SAN- bloc Series enclosures. This section lists the cables that must be used with the 2GB SANbloc Series enclo- sure. Failure to adhere to these guidelines may cause the enclosure to operater in- correctly.
- Page 6 2Gb SANbloc Series (JBOD) STEP 1. Attach the cables provided with your enclosure. The illustrations below show the configuration for dual fibre channel loop systems. Daisy chaining configurations is also shown. To HBA To HBA Connecting Dual FC Loop Mode...
- Page 7 STEP 2. Attach the power cords provided, to the power connectors on each of the two power supplies on the rear of the enclosure. AC Power Connection Insert Power cords into power connectors...
- Page 8 2 Gb SANbloc Series Quad Loop NOTE: Quad loop configuration requires that the enclosure be configured in split loop mode. To set split loop mode, a jumper must be installed at jumper location JP3 on each LS module in the enclosure. This section describes the procedure for connecting the enclosure in quad loop mode.
- Page 9 STEP 4. Attach the power cords provided, to the power connectors on each of the two power supplies on the rear of the enclosure. AC Power Connection Insert Power cords into power connectors...
-
Page 10: Section 3: Getting More Information
For more information on installing and configuring your enclosure, refer to the “2Gb SANbloc Series Installation Guide” (on the Documentation CD). To obtain Technical Support for the 2Gb SANbloc Series contact our World Wide Support Centre at: Telephone: 321-207-2000 (RAID, FC, External Storage) 408-934-7274 (Hardware) E-mail: ask.adaptec.com...
