General Information

General Information
The next-generation OutBack Mate Micro remote display unit (for the OutBack FLEXmax 30/40 Series Charge Controller) is a
display device that supports both the latest communication protocol and the voltage technology standard of solar controllers.
The OutBack Mate Micro monitors the operational data and working status of the connected charge controller in real-time. Via the
six navigation keys on the OutBack Mate Micro, the user can oversee and modify the charge and discharge control parameters, set
device parameters, and restore the OutBack Mate Micro to its factory default settings.

Features

The OutBack Mate Micro features include:
» Automatic identification and display of the type, model, and relevant parameters of the charge controller.
» Real-time display of operational data and working status of the connected devices in digital, graphic, and textual forms
on a large multifunctional LCD screen.
» Six navigation/function keys.
» Data and power flow on the same lead, eliminating the need for external power.
» Real-time data monitoring and remote load switchover of the controllers, and data browse and modification of device
parameters, charge control parameters and load control parameters.
» Alarm information is displayed via the LCD screen with an accompanying audible alarm.
» Longer communication distance based on RS485.
CAUTION: Equipment Damage
The OutBack Mate Micro is only compatible with the FLEXmax 30/40 Series Charge Controller. Do not
install the OutBack Mate Micro with any other charge controller.
