SERVICE / REPAIR PARTS

20 Gallon (75 Liter) Wet/Dry Vac With Cart
WARNING:
!
In a double-insulated Wet/Dry Vac, two systems of insulation are provided instead of grounding. No grounding means
is provided on a double-insulated appliance, nor should a means for grounding be added. Servicing a double-insulated
Wet/Dry Vac requires extreme care and knowledge of the system, and should be done only by qualified service personnel.
Replacement parts for a double-insulated Wet/Dry Vac must be identical to the parts they replace. Your double-insulated
Wet/Dry Vac is marked with the words "DOUBLE INSULATED" and the symbol
be marked on the appliance.
To reduce the risk of injury, unplug power cord before servicing the Wet/Dry Vac.
Key No.
Part No.
1
841579-1
2
510701
3
510706
4
829719-17
5
841364-1
6
820563-4
7
819260-13
8
510379
9
818961
10
818413
11
315534-1
12
826817
13
510582
14
510567
15
840321
16
820563-5
17
823201-2
18
CMXZVBE38754
19
CMXZVBE38749
20
CMXZVBE38630
21
CMXZVBE38620
22
CMXZVBE38621
23
CMXZVBE37035
24
CMXZVBE38660
25
CMXZVBE38763
26
CMXZVBE38606
27
SP7091
16
Model Number: CMXEVBE176560
Electrical Rating: 120 V~ 12 A 60Hz
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
Description
Switch
Top Handle & Hardware (2 screws)
Motor Cover with Labels
Cord with Terminal
Duct, Exhaust
Screw, Pan Hd Tp "AB" 10 x 3/4" (19 mm) Ser.
Lead Assembly
Motor Assembly
Spacer
Blower Wheel
Washer
Nut, Hex Flange 5/16 -18
Hose Clip Assembly with Screws
Lid / Lid Assembly
Collector
Screw, Pan Hd Tp "AB" 10 x 1-1/4" (31 mm) Ser.
Filter Cage Assembly
Replacement Filter
Disposable Filter Bag
Utility Nozzle
Car Nozzle
Wet Nozzle
Crevice Tool
Diffuser
Hose Assembly
Extension Wand
Instruction Manual
(square within a square) may also
