5
CONNECTING AND MAINTENANCE
Installing the antenna
Installing the outdoor antennas
Keep a minimum of 20 cm (7.9 inch) between the Antenna unit and your body.
Move away from buildings and use the transceiver in areas with an open sky.
Install the outdoor antennas in a place with a clear view of the sky. Make sure that there are no obstacles, such as
buildings or trees, at higher than about 8 degrees around the antenna.
8°
WARNING HIGH RF VOLTAGE! NEVER
WARNING HIGH RF VOLTAGE! NEVER
8°
12
