7. VGA Output- Output connectors for 31 KHz VGA, including 1 15-pin D-type
connector, 1 RGB, H + V (or H)*. V BNC connectors and 2 Audio RCA
connectors. Put the jumper to location 1 for H + V. Put the jumper to location 2
for H. The Preset Value is H+V.
8. DC 12V 800mA- 12 Volt DC input.

Connection and Installation

- Connect your Video camera to the L + R Audio ports. Either connect the device into
the input 1 or input 2 connectors (Number 2/3 on the rear panel).
- Connect your Laser Disc or VCR to the Video or S-Video Input ports. Either connect
the device into the input 1 or input 2 connectors (Number 2/3 on the rear panel).
- Connect your TV monitor to the Video or S-Video Output ports. (Number 4 on the
rear panel).
- Connect your RGB 15k professional apparatus or TV game to the CGA input port
(Number 5 on the rear panel).
- Connect your PC to the VGA input port (Number 6 on the rear panel).
- Connect your PC monitor to the VGA output port (Number 7 on the rear panel).
- Connect your RGB projector or large screen TV to the RGBHV output ports (Number
7 on the rear panel).
- Connect your speakers to the L + R VGA Output ports (Number 7 on the rear panel).
- Connect the power supply to the power supply input port (Number 8 on the rear
panel). Plug it into the power socket and turn the unit on.
