Summary of Contents for Tele System SMART24 SLIM12V
- Page 3 NOTE TELE System Digital Srl communicates that, following any software and/or hardware changes aimed at improving the product, there could be inconsistencies between the content of this manual and the product in your possession.
-
Page 4: Table Of Contents
SMART TV - ENGLISH Index Safety ..............................1 Product description ..........................2 Front .............................. 2 Keyboard ............................2 Connections ........................... 2 Remote control ..........................3 2.4.1 Keys ............................3 2.4.2 Batteries ..........................3 First installation ............................4 Main functions ............................4 Digital TV mode .......................... -
Page 6: Safety
SMART TV - ENGLISH 8 Safety WARNING: TO REDUCE THE RISK OF SHOCK AND AVOID VOIDING THE WARRANTY, DO NOT REMOVE THE BACK COVER OF THE DEVICE COVER! Before connecting the power cable to the mains power supply outlet, make sure that the electric voltage indicated on the appliance corresponds to the one used in your area. -
Page 7: Product Description
12. LAN: Ethernet (RJ45) port for connection to the Internet, necessary for the Smart TV function. 13. Supply: integrated power cable for connecting the television to the 230VAC, 50Hz mains supply. 12V DC input for external AC adapter (for SMART24 SLIM12V model) HDMI3 port is available only for SMART28 LS09 model... -
Page 8: Remote Control
SMART TV - ENGLISH 9.4 Remote control 9.4.1 Keys Power: power on/turn off in Standby. HOME: recall the HOME menu (Smart/connected mode). TV: direct access to TV mode USB: direct access to MULTIMEDIA function (USB) APP: direct access to the list of available applications. 0÷9 numerical keys: direct selection of channels. -
Page 9: First Installation
TELE System 10 First installation Before switching on the television, it is advisable to connect the aerial cable (terrestrial and/or satellite) and the ethernet cable (if available). In this way, thanks to the installation wizard, you can start using your... -
Page 10: Source Selection
SMART TV - ENGLISH If you opt for automatic scanning of digital TV, the TV will propose that you upload a list of Italian satellite default channels with a typical arrangement of the TivùSat platform channels. NOTE • The viewing of the encrypted TivùSat channels requires the use of a dedicated conditional access module (CAM) and card (Smart-card), to be purchased separately. -
Page 11: Main Menu
TELE System 11.3 Main menu From TV source (or from audio-video inputs), press the MENU button to display the main menu and use the t / u arrow buttons to navigate through the menu titles. Press the ENTER button to confirm your... -
Page 12: Advanced Functions
SMART TV - ENGLISH 12 Advanced functions 12.1 TV channels search To perform a channel scan, press the MENU key and access the Channels menu, from which you will have to define the Country where the TV is installed should it be a different one than the one chosen during the initial installation (section 3), and choose the Antenna Type desired between: Digital terrestrial: to search for channels broadcast in terrestrial digital (DVB-T / T2), DVB-C: to search for channels broadcast by cable (DVB-C),... - Page 13 TELE System • The TV is compatible with single universal, multi-satellite DiSEqC 1.0 and multi-user SCR/Uni-cable systems. Motorized antennas (DiSEqC 1.2 and USALS) are not supported. • Incorrect antenna configuration may result in some or all channels not being loaded. If you do not know the characteristics of your antenna system and/or you are not able to configure the receiver yourself, it is advisable to contact a trusted professional installer.
-
Page 14: Menu And Channel Protection
SMART TV - ENGLISH Alternatively, to reduce the channel search to a single transponder (frequency) of a satellite, choose the Manual Scan submenu, where you can also add and/or edit the transponder data, then press ENTER on Start scan to operate the search. 12.2 Menu and channel protection The System Lock menu is password protected;... - Page 15 TELE System NOTE • It is not recommended to avoid using/occupying the TV's internal memory in order to conserve system resources and space for IP applications. • Compatibility with all FAT32 or NTFS formatted USB 2.0 memory devices and all types of codecs/multimedia formats available on the market is not guaranteed.
-
Page 16: Technical Specifications
SMART TV - ENGLISH 13 Technical specifications Model SMART24 SLIM12V SMART28 LS09 Format 23,6” – 16:9 wide (59,9cm) 27,5” - 16:9 wide (69,8cm) Resolution 1366 x 768 (HD ready) Panel Contrast 3000:1 Brightness 180 (cd/m Viewing angle 178°/178° (Horizontal/Vertical) Component... -
Page 17: Troubleshooting
TELE System 14 Troubleshooting Problems Possible Causes What to do Make sure the TV is properly The On / Standby LED on The power cord is not connected powered, then press the q key on the front panel of the TV is to the electrical outlet. - Page 18 SMART TV - ENGLISH Problems Possible Causes What to do Check that there are no obstacles remote control between the remote control and properly aimed at the TV. the front IR sensor of the TV. Replace the batteries (section The remote control does The batteries are dead.
- Page 19 Codice Prodotto 28000156 Codice Prodotto 28000152 Dichiarazione di Conformità EU EU Declaration of Conformity Tele System Digital dichiara sotto la propria Tele System Digital declares, under its own responsabilità che questo prodotto soddisfa i responsibility, that this product meets the...
