Rollei Fotopro FPH-53P Instructions

Thank you for choosing our products. Please read carefully before using.

Construction

Features
1. Locking force and smoothness
have been greately improved.
2. The surface is processed
through oxidation and delicate
workmanship.
3. 360° scale design, suitable for
panoramic shooting.
Service: Rollei Service Germany
Denisstraße 28a, D-67663 Kaiserslautern
Hotline +49 (0)6 31/3 42 84 49
Distribution: Rollei GmbH & Co. KG
Tarpen 40/Gebäude 7b, D-22419 Hamburg
www.rollei.com
Quick release plate
Platform
1. Align the quick
release palte
Ball
Ball housing
Lock knob
Loosen
Base
Scale
3. Make sure that the quick release plate is well
places and that the knob is locked
1. Please lock the ball head before using
2. After using the ball head in a wet, sandy or dusty
environment clean it carefully (with pure alcohol).
3. Do not use it in sea water.
4. Do not inject corrosive materials into the
ball head.
5. Do not use under –20° C and over +70° C.
Model
FHP-53P
Clamp
Anti-slip groove
Vertical shooting spirit level

How to install

Anti-slip groove
Tighten

Attention

Specifications

ø 30 mm 72.5 x 43.5 x 81 mm
*Design and specification are subject to real product.
[EN]
Instructions of
FPH-53P Ball Head
Platform
Lock knob
2. Slant the quick release palte
and press it
Anti-slip srew
Loosen
L x B x H
0.27 kg
Tighten
5 kg
