P/N 126896-01 Rev.A 02/2014
P126896-01
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not
prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This
appliance is not convertible for use with other gases.
WARNING: This appliance is for installation only in
a solid-fuel burning masonry or UL127 factory-built
fireplace, constructed of noncombustible material
and connected to a working flue. (See page 6 for
minimum flue opening.)
WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Installation and Operation Instructions
Astria
TM
PFS
Models
®
US
WARNING: This is a gas-fired heater. It uses air (oxy-
gen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be
provided. Refer to the National Fual Gas Codes, ANSI
Z233.1/NFPA 54, Section 5.3 for Combustion and
Ventilation.
Vented Gas Log Decorative Appliance
Arcadia18MN
Arcadia18MP
Arcadia24MN
Arcadia24MP
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Astria Fireplaces Arcadia18MN
Summary of Contents for Astria Fireplaces Arcadia18MN
- Page 1 Installation and Operation Instructions Astria Vented Gas Log Decorative Appliance P/N 126896-01 Rev.A 02/2014 Models ® Arcadia18MN Arcadia24MN Arcadia18MP Arcadia24MP P126896-01 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not prohibited by local codes.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information ..........2 Specifications ............ 14 Local Codes............4 Wiring Diagram ..........14 Product Identification ........... 5 Troubleshooting ..........15 Unpacking............5 Service Hints ............. 19 Product Features ..........5 Technical Service..........19 Optional Remote Control Accessories ....5 Replacement Parts .......... - Page 3 SAFETY INFORMATION WARNING: Do not use a Continued blower insert, heat exchanger insert or other accessory not ap- WARNING: This product con- proved for use with this log set. tains and/or generates chemicals known to the State of California to cause cancer or birth defects WARNING: Do not allow fans or other reproductive harm.
-
Page 4: Local Codes
SAFETY INFORMATION 8. To reduce the creation of soot, follow the instructions in Cleaning and Maintenance, Continued page 14. You must operate this log set 9. Before using furniture polish, wax, carpet with a fireplace doors or screen cleaner or similar products, turn the log set off. in place and fully closed. -
Page 5: Product Identification
PRODUCT UNPACKING IDENTIFICATION CAUTION: Do not remove the data plates from the grate as- Log Set sembly. The data plates contain Assembly Left important warranty and safety Side information. 1. Remove log set assembly from carton. Note: Do not pick up assembly by logs. This could damage the log set. -
Page 6: Installation
INSTALLATION SPECIFICATIONS (W.C.) FUEL INLET MANIFOLD WARNING: Make sure the PRESSURE PRESSURE Min. Max. selector switch is in the OFF 7" 10.5" 3.5" position before installing log set. 11" 14" 10" Figure 2 - Technical Information Chart WARNING: Before installing in a solid fuel burning fireplace, the Flue Opening Specifications Note: This vented appliance must be installed... - Page 7 INSTALLATION CAUTION: Do not pick up the Continued log set assembly by the logs. The minimum flue sizes shown in Figure 3, page This could damage log set. Only 6, are based on a 6' chimney height using round handle base assembly by grates. pipe.
- Page 8 INSTALLATION CAUTION: Use only new, black Continued iron or steel pipe. Internally-tinned copper tubing may be used in CAUTION: Never connect certain areas. Check your local propane/LP fireplace directly to codes. Use pipe of 1/2" diameter or the propane/LP supply. This log greater to allow proper gas volume set requires an external regula- to the log set.
- Page 9 INSTALLATION CAUTION: Make sure exter- Continued nal regulator has been installed Check your building codes for any special re- between propane/LP supply and quirements for locating equipment shutoff valve log set. See guidelines under to fireplaces. Connecting to Gas Supply, Apply pipe joint sealant lightly to male NPT page 7.
-
Page 10: Operating Appliance
INSTALLATION OPERATING LOG SET Continued FOR YOUR SAFETY 3. Check all joints from gas meter to equipment READ BEFORE LIGHTING shutoff valve for natural gas or propane/LP sup- ply to equipment shutoff valve for propane/LP WARNING: Keep flue open (see Figure 9 or 10). Apply noncorrosive leak when operating unit. - Page 11 OPERATING APPLIANCE 5. Wait five (5) minutes to clear out any gas. Continued Then smell for gas, including near the floor. If you smell gas, STOP! Follow “B” in the LIGHTING safety information, page10. If you don’t INSTRUCTIONS smell gas, go to the next step. 6.
- Page 12 OPERATING APPLIANCE OPTIONAL HAND-HELD Continued REMOTE CONTROL OPERATION 1. After lighting, let pilot flame burn for WARNING: Make sure selec- about one minute. Turn control knob to tor switch is in to OFF position ON position. Adjust flame adjustment knob when you are away from home anywhere between HI and LO.
-
Page 13: Inspecting Burners
INSPECTING BURNERS BURNER FLAME PATTERN Figure 16 shows correct burner flame pattern. Check pilot flame pattern and burner flame pat- terns often. NOTICE: Do not mistake orange flames with yellow tipping. Dirt PILOT FLAME PATTERN or other fine particles are burned Figure 14 shows a correct pilot flame pattern. -
Page 14: Cleaning And Maintenance
CLEANING AND SPECIFICATIONS MAINTENANCE Arcadia18MN • Input Rating: 37,000/54,000 Btu/Hr WARNING: Turn off log set • Fuel: Natural Gas and let cool before cleaning. • Ignition: Electronic • Manifold Pressure: 3.5" W.C. • Inlet Gas Pressure (in. of water): CAUTION: You must keep Max. -
Page 15: Troubleshooting
TROUBLESHOOTING WARNING: Turn off the appliance and let cool before servicing. Only a qualified service person should service and repair log set. CAUTION: Never use a wire, needle or similar object to clean ODS/pilot. This can damage ODS/pilot unit. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY... - Page 16 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY ODS/pilot lights but flame goes 1. Control knob not fully pressed in 1. Press in control knob fully out when control knob is re- 2. Control knob not pressed in 2. After ODS/pilot lights, keep leased long enough control knob pressed in 30...
- Page 17 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Orange flame in burner during 1. Not enough air 1. Check burner for dirt and burner combustion debris. If found, clean burner (see Cleaning and Mainte- nance, page 14) 2. Gas regulator defective 2.
- Page 18 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions.
-
Page 19: Service Hints
ACCESSORIES SERVICE HINTS Purchase these log set accessories from your local When Gas Pressure Is Too Low dealer. If they can not supply these accessories, • pilot will not stay lit call INNOVATIVE HEARTH PRODUCTS at • burners will have delayed ignition 1-800-655-2008 for referral information. -
Page 20: Illustrated Parts Breakdown And Parts List
ILLUSTRATED PARTS BREAKDOWN MODELS ARCADIA18MN AND ARCADIA18MP Log Set, Ceramic Burner and Ramp Pan are Ordered as an Assembly Air Shutter Installation Note: For Natural Gas: Fully Closed For Propane/LP Gas: Fully Open Installed in BTB Models Only www.Astria.US.com 126896-01A... - Page 21 PARTS LIST This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. PART NO. DESCRIPTION QTY. 111808-01 Grate Assembly • • 111794-03 Valve-Bracket Assembly • 111794-04 Valve-Bracket Assembly •...
- Page 22 ILLUSTRATED PARTS BREAKDOWN MODELS ARCADIA24MN AND ARCADIA24MP Log Set, Ceramic Burner and Ramp Pan are Ordered as an Assembly Air Shutter Installation Note: For Natural Gas: Fully Closed For Propane/LP Gas: Fully Open Installed in BTB Models Only www.Astria.US.com 126896-01A...
- Page 23 PARTS LIST This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. PART NO. DESCRIPTION QTY. 111793-01 Grate Assembly • • 111794-01 Gas Train Assembly •...
- Page 24 KEEP THIS WARRANTY Model (located on product or identification tag) _____________________________ Serial No. (located on product or identification tag) __________________________ Date Purchased __________________________ Keep receipt for warranty verification. www.Astria.US.com 126896-01A...
-
Page 25: Warranty Information
Innovative Hearth Products Astria™ Brand Gas Log Set & Outdoor Gas Fire Pit Limited Three Year Warranty THE WARRANTY Innovative Hearth Products Limited Three Year Warranty ("IHP") warrants your Astria™ brand Gas Log Set or Outdoor Gas Fire Pit ("Product") to be free from defects in materials and workmanship at the time of manufacture. - Page 26 NOTES...
- Page 27 NOTES...
- Page 28 1508 Elm Hill Pike, Suite 108 Nashville, TN 37210 126896-01 1-800-655-2008 Rev. A www.IHP.US.com 2/14 P126896-01...
